3.0 How to operate the Rotator

3.2 Use of the Rotator

Insert key (1) and turn clockwise to switch on control current ready for
function activation.
Note!!! Emergency stop (2)
must not be activated.
Condition: The upper edge of the forks is lifted between 400 and 900 mm.
The load can be rotated 360º with one adjustable stop in every side.
Note!: If you want rotation to continue, it is necessary to release/press the rotation
switch on the remote control again.
To lower the forks fully or to lift higher than 900 mm, the forks have to be placed in
horizontal position.
Soft acceleration / deceleration
The Rotator has soft acceleration / deceleration with the following benefits:
• The rotation stops precisely
• The gear is protected, because sudden start / stop are minimised
10
1 2
