3.0 How to operate the Rotator
NOTE!
The load has to be supported
sideways before tilting.

3.3 Handle functions

The control functions of the Rotator are located in the handle (6).
• The functions are dependent on the positions of the handle.
Position A: Drive position
• Drive current on
• Brake deactivated
Position B: Stop/Brake/
Emergency Stop
• Drive current off
• Brake activated
