Enterasys SecureStack B2 B2G124-48P Hardware Installation Manual page 77

Using LANVIEW
Table 4-4 LANVIEW LED Diagnostic Indications (continued)
LED Color
Link/ Off
Activity
(RJ45 PoE
ports 1–48)
Green
Amber
B2G124-48P ONLY
Link/ Off
Activity
(MGBIC
ports 45–48)
Green
4-6 Troubleshooting
State
1. No link.
2. No activity or port in standby.
3. The port is deactivated because the
Mini-GBIC port with the same port number
is linked. This applies only to the
B2G124-48P.
Solid. Port is linked, but the interface is not
receiving any traffic. PoE power is available.
Blinking. Port is linked and traffic is being
received or transmitted by the interface. PoE
power is available.
Solid. Port is linked, but traffic is not being
received or transmitted by the interface. PoE
power has failed.
PoE power may have been deactivated
because of excessive power requirement or
deactivated by configuration.
Power Supply failed.
Blinking. Port is linked and traffic is being
received or transmitted by the interface. PoE
power has failed.
PoE power may have been deactivated
because of excessive power requirement or
deactivated by configuration.
Power supply failed.
1. No link.
2. No activity or port in standby.
3. The port is deactivated because the RJ45
port with the same port number is linked.
Solid. Port is linked, but the interface is not
receiving any traffic.
Blinking. Port is linked and traffic is being
received or transmitted by the interface.
Recommended Action
None.
None.
None.
None.
None.
1. Check the attached powered device
to see if it is defective.
2. Internal power supply failed, contact
Enterasys Networks for technical
support.
1. Check the attached powered device
to see if it is defective.
2. Internal power supply failed, contact
Enterasys Networks for technical
support.
None.
None.
None.
None.
None.
