Table 7. Gigabit Port LEDs
LED
Per-port Link
Per-port Rx
Per-port Tx
Per-port AN
Internet Appliance 1100/1200 Getting Started Guide
• Green – indicates that the port hardware detects a cable plugged
into the port and a good link is established.
• Red (intermittent) – indicates that the port received an error
during operation.
• Red (solid) – indicates that the port hardware detects a cable
plugged into the port, however, a bad link is established.
• Off – indicates that no link from exists with the port.
• Green – indicates when the port's transceiver receives packets.
• Orange – indicates when the port's transceiver receives flow-
control packets.
• Green – indicates when the port's transceiver transmits packets.
• Orange – indicates when the port's transceiver transmits flow-
control packets.
• Green – indicates that the Gigabit port is autonegotiating the
operating mode of the link between full-duplex and half-duplex.
• Orange (intermittent) – indicates that autonegotiation is in
process.
• Orange (solid) – indicates a problem with autonegotiation
configuration.
• Red – indicates an autonegotiation failure. This fault may occur if
the link partner does not support full duplex.
• Off – indicates that autonegotiation has been disabled or the link
is down.
Appendix C: Hardware Specifications
Description
59
