DIGITAL MultiSwitch Fast Ethernet Hub
924TX
Installation and Configuration
Part Number: EK-DLMT2-IN. A01
September 1998
This manual describes how to install, cable, and configure the DIGITAL MultiSwitch Fast Ethernet
Hub 924TX when residing in a DIGITAL MultiSwitch 900 (formerly the DEChub 900 MultiSwitch),
DIGITAL MultiSwitch 900-4, a DEChub ONE docking station, or a DEChub ONE-MX docking
station.
Revision Information:
This is a new document.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 924TX and is the answer not in the manual?

Questions and answers

Related Manuals for Cabletron Systems 924TX

Summary of Contents for Cabletron Systems 924TX

  • Page 1 This manual describes how to install, cable, and configure the DIGITAL MultiSwitch Fast Ethernet Hub 924TX when residing in a DIGITAL MultiSwitch 900 (formerly the DEChub 900 MultiSwitch), DIGITAL MultiSwitch 900-4, a DEChub ONE docking station, or a DEChub ONE-MX docking station.
  • Page 2 Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.

  • Page 3: Table Of Contents

    In This Chapter ............1-1 What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX?......1-3 DIGITAL MultiSwitch Fast Ethernet Hub 924TX Features .
  • Page 4 In This Chapter............2-1 Installing DIGITAL MultiSwitch Fast Ethernet Hub 924TX Option Cards....2-2 Required Tools.
  • Page 5 [2] Restart with Current Settings ..........4-6 [3] Show Current Settings .
  • Page 6 In This Appendix ............A-1 DIGITAL MultiSwitch Fast Ethernet Hub 924TX LED States ......A-2 DIGITAL MultiSwitch Fast Ethernet Hub 924TX Problem Solving Using the LEDs .
  • Page 7 In This Appendix ............C-1 Product Specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX ... .C-2 Acoustical Specifications .
  • Page 8 Glossary Overview ............. . Glossary-1 Introduction .

  • Page 9: Preface

    MultiSwitch 900-4, a DEChub ONE docking station or a DEChub ONE-MX docking station. The DIGITAL MultiSwitch Fast Ethernet Hub 924TX is a 24-port 100 Mb/s Fast Ethernet Hub. The 24 100BASE-TX ports can be separated into two banks of 12 ports each or operate as a single 24-port hub.

  • Page 10: Organization

    Provides instructions for installing and cabling the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module. Provides instructions for configuring the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DEChub ONE or a DEChub ONE-MX. Provides instructions for configuring the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900.

  • Page 11: Conventions

    Conventions Conventions This book uses the following conventions. Convention Description Bold Type Indicates user input. Indicates system output. Monospaced Type <Return> Indicates that you press the Return Key.

  • Page 13: Safety

    Safety Overview The cautions that must be observed for the hardware are described in this manual in English, German, French, and Spanish. Any warning or caution that appears in this manual is defined as follows. WARNING Contains information to prevent personal injury. CAUTION Contains information to prevent damage to equipment.
  • Page 14 CAUTION This action deletes all configured settings and replaces them with factory default values. All configuration settings will be lost. ACHTUNG Bei diesem Vorgang werden alle Konfigurationseinstellungen gelöscht und die Werkseinstellungen wieder eingesetzt. Alle Konfigurationsdaten gehen verloren. ATTENTION Cette action supprime tous les paramètres de configuration et les remplace par des valeurs prédéfinies.
  • Page 15 WARNING Some fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port. Always assume the cable is connected to a light source. VORSICHT Bestimmte Lichtleitergeräte können für die Augen gefährliches Laser- oder Infrarotlicht abstrahlen.
  • Page 16 ATTENTION Les charges excessives d'électricité statique peuvent endommager les modules et les composants électroniques. Cabletron Systems conseille l'utilisation d'un bracelet de masse et d'un plan de travail mis à la terre lors de la manipulation des modules. PRECAUCION La electricidad estática puede dañar los componentes electrónicos y los módulos.

  • Page 17: Product Description

    Product Description Overview Introduction This chapter describes the DIGITAL MultiSwitch Fast Ethernet Hub 924TX (also referred to in this manual as the module). It also provides a brief description of the DIGITAL MultiSwitch 900 chassis, the DIGITAL MultiSwitch 900-4, the DEChub ONE docking station and the DEChub ONE-MX docking station.
  • Page 18 Topic Page Management Features 1-14 What is the DIGITAL MultiSwitch 900-4? 1-16 DIGITAL MultiSwitch 900-4 Features 1-16 The Management Agent Module 1-17 What are Docking Stations? 1-18 DEChub ONE and DEChub ONE-MX Docking Stations 1-18 Common Features 1-18 1-2 Product Description...

  • Page 19: What Is The Digital Multiswitch Fast Ethernet Hub 924Tx

    100BufFX MM-100 DIGITAL MultiSwitch Fast Ethernet Hub 924TX The DIGITAL MultiSwitch Fast Ethernet Hub 924TX module can be installed in a DIGITAL MultiSwitch 900, a DIGITAL MultiSwitch 900-4 (Refer to the The Management Agent Module), a DEChub ONE or a DEChub ONE-MX docking station, all of which supply power and mechanical support to the module.

  • Page 20: Digital Multiswitch Fast Ethernet Hub 924Tx Features

    What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX? DIGITAL MultiSwitch Fast Ethernet Hub 924TX Features The DIGITAL MultiSwitch Fast Ethernet Hub 924TX includes the following features: • 24-fixed 100BASE-TX 8-pin MJ crossover ports for 100 Mb/s Fast Ethernet connections and two expansion slots.

  • Page 21: Digital Multiswitch Fast Ethernet Hub 924Tx Management

    What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX? DIGITAL MultiSwitch Fast Ethernet Hub 924TX Management The DIGITAL MultiSwitch Fast Ethernet Hub 924TX is managed using clearVISN MultiChassis Manager. For module management procedures, refer to the clearVISN User’s Guide. Port Group Switching The port group switching feature allows network managers to allocate bandwidth and avoid bottlenecks.

  • Page 22: Mib Support

    For information on how to access DIGITAL MIBs, follow the procedures in the Release Notes for this product. Remote Monitoring (RMON) The DIGITAL MultiSwitch Fast Ethernet Hub 924TX supports sophisticated Ethernet monitoring with the Remote Network Monitoring Information Base (RMON-MIB). The following RMON features and options are available: •...

  • Page 23: Digital Multiswitch Fast Ethernet Hub 924Tx Front Panel

    What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX? DIGITAL MultiSwitch Fast Ethernet Hub 924TX Front Panel Figure 1-2 shows the location of the DIGITAL MultiSwitch Fast Ethernet Hub 924TX front panel components and Table 1-1 describes these components. For detailed information about the LEDs, refer to Appendix A.
  • Page 24 What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX? Table 1-1: DIGITAL MultiSwitch Fast Ethernet Hub 924TX Front Panel Features Item Icon Name Description Power OK LED Indicates that the module has sufficient power. Module OK LED Indicates that the module passed self-test.

  • Page 25: Digital Multiswitch Fast Ethernet Hub 924Tx Back Panel

    What Is the DIGITAL MultiSwitch Fast Ethernet Hub 924TX? DIGITAL MultiSwitch Fast Ethernet Hub 924TX Back Panel Figure 1-3 shows the location of the DIGITAL MultiSwitch Fast Ethernet Hub 924TX back panel components and Table 1-2 describes these components. Figure 1-3: DIGITAL MultiSwitch Fast Ethernet Hub 924TX Back Panel...

  • Page 26: Network Topologies For Class Ii Hubs

    Figure 1-4 shows a single Class II hub configuration with a switch (1) connected to a DIGITAL MultiSwitch Fast Ethernet Hub 924TX module (2). This connection is made using 100Mb/s Fast Ethernet MM-100 Cards. The combinations for connecting these...

  • Page 27: 100Buffx Uplink Configuration

    100BufFX Uplink Configuration The 100BASE-FX and 100BufFX MMIs are based on the100BASE-FX standards. When installed in a DIGITAL MultiSwitch Fast Ethernet Hub 924TX, the 100BufFX MM-100 option card will operate in full-duplex mode only. The switch must be manually configured to operate in 100BASE-FX, full-duplex mode.

  • Page 28: User Support In A Class Ii Environment

    User Support in a Class II Environment Figure 1-6 shows user support for four different configurations (A, B, C, D) using uplinks (1) with DIGITAL MultiSwitch Fast Ethernet Hub 924TX modules (2). Figure 1-6: Various Class II Hub Configurations Fast Ethernet...

  • Page 29: What Is The Digital Multiswitch 900

    What is the DIGITAL MultiSwitch 900? What is the DIGITAL MultiSwitch 900? The DIGITAL MultiSwitch 900, shown in Figure 3-4, supports multiple network technologies and uses industry standard protocols. It uses advanced technology to provide complete backward compatibility with the DEChub 90 network modules. The DIGITAL MultiSwitch 900, with a complement of network modules installed, becomes an integral part of any distribution subsystem within a structured wiring environment.

  • Page 30: Management Features

    What is the DIGITAL MultiSwitch 900? Feature Description Redundant If a single power supply module provides enough power for the Power DIGITAL MultiSwitch 900, and you add a second power supply module, then the DIGITAL MultiSwitch 900 has redundant (N+1) power.
  • Page 31 What is the DIGITAL MultiSwitch 900? • Calculates the power available to network modules • Displays the power status and available power to its LCD display • Allocates power to network modules • Deallocates power from network modules when there is a power system failure in a non-redundant power configuration For additional information about the DIGITAL MultiSwitch 900, refer to the DIGITAL MultiSwitch 900 Owner’s Manual.

  • Page 32: Digital Multiswitch 900-4 Features

    What is the DIGITAL MultiSwitch 900-4? What is the DIGITAL MultiSwitch 900-4? The MultiSwitch 900-4 is a versatile four-slot chassis that provides multitechnology integration. It supports Ethernet, Fast Ethernet, FDDI, ATM, and VNbus technologies. The chassis accommodates any combination of MultiSwitch 900 and MultiSwitch 600 modules.

  • Page 33: The Management Agent Module

    What is the DIGITAL MultiSwitch 900-4? Feature Description Redundant Has an optional power supply available to provide the Power MultiSwitch 900-4 with a redundant source of power. If a single power supply module provides enough power for the DIGITAL MultiSwitch 900-4, and you add a second power supply module, then the DIGITAL MultiSwitch 900-4 has redundant (N+1) power.

  • Page 34: What Are Docking Stations

    What are Docking Stations? What are Docking Stations? Docking Station are single-slot units that provide power for a DIGITAL MultiSwitch 900 full-height module. The DIGITAL MultiSwitch Fast Ethernet Hub 924TX supports the following two types of docking stations: • DEChub ONE (shown in Figure 3-4) •...

  • Page 35: Installing A Modular Media Interface

    For detailed information on the available option cards, refer to the 100 Mb/s Fast Ethernet Modular Media Interface Cards Installation manual. In This Chapter Topic Page Installing DIGITAL MultiSwitch Fast Ethernet Hub 924TX Option Cards Required Tools Removing the Dust Cover Installing the MM-100...

  • Page 36: Installing Digital Multiswitch Fast Ethernet Hub 924Tx Option Cards

    Installing DIGITAL MultiSwitch Fast Ethernet Hub 924TX Option Cards The DIGITAL MultiSwitch Fast Ethernet Hub 924TX has two expansion slots that accept option cards (Figure 2-1). The table following the the figure identifies the option cards. The following sections provide instructions for installing and removing an option card.

  • Page 37: Required Tools

    Installing DIGITAL MultiSwitch Fast Ethernet Hub 924TX Option Cards Required Tools We recommend the use of, but do not supply, the following tools to install the cards: • Phillips-head screwdriver • Antistatic grounding strap To prepare to install the card into the module, complete the following steps:...

  • Page 38: Removing The Dust Cover

    Removing the Dust Cover Removing the Dust Cover To remove the dust cover from the expansion slot (Figure 2-2), perform the following steps. Figure 2-2: Dust Cover Removal NPB-0863-97F Step Action Using a Phillips-head screwdriver, loosen the two captive screws on the dust cover.

  • Page 39: Installing The Mm-100

    Installing the MM-100 Installing the MM-100 Complete the following steps to install an MM-100 into the module (Figure 2-3). Figure 2-3: Installing the MM-100 NPB-0869-97F Depending on the type of connectors used on the card, there will be differences in the way cables are attached and removed.
  • Page 40 Installing the MM-100 Step Action Hold the card by the edges of the bezel and position it so that it is parallel with the slot opening. Insert the card into the slot opening and slide the card along the card guides until the card’s bezel is flush with the module.

  • Page 41: Module Installation And Setup Port Cabling

    900. In This Chapter Topic Page Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Task 1: Compare the Power Ratings Task 2: Seat the Module in the DIGITAL MultiSwitch 900 Task 3: Verify Initial LED Operation...

  • Page 42: Installing The Digital Multiswitch Fast Ethernet Hub 924Tx In A Digital Multiswitch

    Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 The DIGITAL MultiSwitch Fast Ethernet Hub 924TX hot-swap feature allows you to install the module into the DIGITAL MultiSwitch 900 without turning off power. If you are using an MM-100, you may install it in the module before or after installing the module in the DIGITAL MultiSwitch 900 because MM-100s are hot-swappable.

  • Page 43: Task 1: Compare The Power Ratings

    Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Task 1: Compare the Power Ratings Compare the DIGITAL MultiSwitch Fast Ethernet Hub 924TX power ratings (1) with the available power value shown in the DIGITAL MultiSwitch 900 Manager Status display (2) (see Figure 3-1).

  • Page 44: Task 2: Seat The Module In The Digital Multiswitch 900

    Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Task 2: Seat the Module in the DIGITAL MultiSwitch 900 Complete the following steps to seat the module in a DIGITAL MultiSwitch 900 as shown in Figure 3-2.

  • Page 45: Task 3: Verify Initial Led Operation

    Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Task 3: Verify Initial LED Operation Verify that the power LED and the OK LED on the module light within one minute. The following table describes the LEDS as shown in Figure 1-2.

  • Page 46: Task 4: Connect The Setup Port Cables To The Digital Multiswitch 900

    Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Task 4: Connect the Setup Port Cables to the DIGITAL MultiSwitch 900 Before you perform this task, make sure that you have installed and cabled the MM-100 according to the instructions provided in Chapter 2.
  • Page 47 Installing the DIGITAL MultiSwitch Fast Ethernet Hub 924TX in a DIGITAL MultiSwitch 900 Figure 3-4: Setup Port Cabling it c iS w u lt DEChub ONE DIGITAL MultiSwitch 900 DEChub ONE-MX H8571-J BN24H H8575-A NPG-0020-95F Item Description OBM port Setup port...

  • Page 48: Connecting Cables To The 100Base-Tx Ports On The Module

    Module This section describes how to connect cables to the 100BASE-TX ports on the DIGITAL MultiSwitch Fast Ethernet Hub 924TX. The 100BASE-TX fixed-ports on the module have crossover port connectors. Use the appropriate cable type (crossover or straight-through) to ensure that the module’s transmit and receive signals connect correctly to the connected device.
  • Page 49 Connecting Cables to the 100BASE-TX Ports on the Module Figure 3-5: 100BASE-TX Cable Connection on the Module NPB-0859-97F Step Action Align the release tab (1) on the cable plug with the connector (2) on the module’s 100BASE-TX port connector. Insert the plug into the connector (2) until the release tab snaps into the locked position.

  • Page 51: Configuring The Module In A Digital Multiswitch 900

    NOTE The module must be installed and cabled prior to configuration. After configuring the DIGITAL MultiSwitch Fast Ethernet Hub 924TX, you can manage the module in the DIGITAL MultiSwitch 900 using clearVISN MultiChassis Manager. For module management procedures, refer to the clearVISN User’s Guide.
  • Page 52 This section describes how to configure the module in a DIGITAL MultiSwitch 900. The following screen is an example of the DIGITAL MultiSwitch 900 INSTALLATION MENU when the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module is installed in a DIGITAL MultiSwitch 900.

  • Page 53: Start Redirect Mode

    Type the slot number in which the DIGITAL MultiSwitch Fast Ethernet Hub 924TX resides. Slot number (8) is used in the following example. After you enter the module’s slot number, the console is redirected to that slot.

  • Page 54: Using The Module's Menus

    Using the Module’s Menus Using the Module’s Menus This section describes the options that are available from the MS FE Hub 924TX INSTALLATION MENU. When your module is installed in a DIGITAL MultiSwitch 900, the slot number in which the DIGITAL MultiSwitch Fast Ethernet Hub 924TX is installed appears at the top of the menu.

  • Page 55: Restart With Factory Defaults

    Memory (NVRAM) parameters to be cleared and reinitialized to factory default values. If you need to reboot the module and retain the current settings, choose option [2] Restart with Current Settings from the MS FE Hub 924TX INSTALLATION MENU. Allow approximately one minute for the module to reboot and complete self-test.

  • Page 56: Restart With Current Settings

    Allow approximately one minute for the module to restart. The following example shows the dialog associated with this option. Enter selection: 2 MS FE Hub 924TX - slot 8 ================================================================= RESTART WITH CURRENT SETTINGS This selection will reset your system with the current configuration settings.
  • Page 57 The hardware ID and ROM (boot) code versions are displayed. The following example shows the display associated with this option. Entries in this display are defined following the screen. Enter selection : 3 MS FE Hub 924TX - slot 8 ==================================================================== MS FE Hub 924TX, HW=B,RO=V1.0,SW=V1.0 SysUpTime...
  • Page 58 [3] Show Current Settings Line Field Description SNMP Read/Write The SNMP Read/Write Community name is Community: public98 used for read/write access control. SNMP Trap This is the address where the module sends Addresses: SNMP trap addresses. 16.7.88.156 Status of Last Provides details about the last firmware Downline Upgrade: upgrade.

  • Page 59: Configure Ip

    [4] Configure IP This option provides you with IP configuration selections. The following example shows the dialog associated with this menu: Enter selection : 4 MS FE Hub 924TX - slot 8 ========================================================= IP CONFIGURATION Set SNMP Read/Write Community Add SNMP Trap Addresses...

  • Page 60: Set Snmp Read/Write Community

    The following example shows the dialog associated with this option: Enter selection : 1 MS FE Hub 924TX - slot 8 ================================================================ SET SMNP READ/WRITE COMMUNITY Format: The format for a community name is a string, consisting...

  • Page 61: Add Snmp Trap Addresses

    This option prompts you to enter IP addresses to which the DIGITAL MultiSwitch Fast Ethernet 924TX module sends SNMP traps. You can enter up to eight trap addresses. If one or more SNMP trap addresses were previously configured, the screen displays those addresses.

  • Page 62: Delete Snmp Trap Addresses

    The following example shows the dialog associated with this option: Enter selection : 3 MS FE Hub 924TX - slot 8 ================================================================ DELETE SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...

  • Page 63: Set In-Band Interface Ip Address

    The factory default setting is no in-band address. The following example shows the dialog associated with this option: Enter selection : 4 MS FE Hub 924TX - slot 8 ============================================================ IN-BAND INTERFACE IP ADDRESS CONFIGURATION Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...

  • Page 64: Enable/Disable Bootp

    ENABLED. The following example shows the dialog associated with this option: Enter selection : 5 MS FE Hub 924TX - slot 8 ========================================================= ENABLE/DISABLE BOOTP BOOTP is the IP bootstrap protocol.

  • Page 65: Dump Error Log

    Firmware upgrades are also recorded in the error log. The following example shows the display associated with this option: Enter selection : 6 MS FE Hub 924TX - slot 8 ========================================================= DUMP ERROR LOG CURRENT RESET COUNT: 18...

  • Page 66: Downline Upgrade

    Step Action Select the Configure IP option (option 4) from the MS FE Hub 924TX INSTALLATION MENU. Select the Set In-Band Interface IP Address option (option 4) from the IP Configuration menu. Enter the IP address, subnet mask, default gateway and press Return.

  • Page 67: Using The Dlu Process

    Do not turn off power to the unit or perform any action that can cause the unit to lose power during Stage 3 of the DLU process. When you select this option from the MS FE Hub 924TX INSTALLATION MENU, the initial setup screen display appears. This screen identifies the option and alerts the user not to interrupt power during the downline load.

  • Page 68: Initializing The Process

    [6] Downline Upgrade Initializing the Process To initiate the DLU process, complete the following steps: Step Action Example Press Return. <Return> If the file is in the default TFTP directory, DLMT2100.BIN enter the firmware image file name and <Return> press Return. (The TFTP load host conventions specify the format of the firmware image file name).

  • Page 69: The Dlu Process Stages

    [6] Downline Upgrade The DLU Process Stages The DLU process consists of four stages: Stage Description Transferring the image to the module’s temporary storage buffer Verifying the image Writing the new image into nonvolatile flash memory Module reset and self-test Table 4-1 explains what happens during each stage of the DLU process.
  • Page 70 • Module can respond to management requests • LED display – normal operation • Hub Manager display – MS FE Hub 924TX unknown • Setup screen display – DLU Process Started! ........When the series of dots ends, the screen displays the following message: Transfer Completed.
  • Page 71 Module can respond to management requests • LED display – normal operation • Hub Manager display – MS FE Hub 924TX unknown The DLU process transfers the new image from the module’s temporary storage buffer to the nonvolatile flash memory, overwriting the old image.
  • Page 72 DLU process. — Port State LED 6 lights green for failure in the completion of the DLU process. • Hub Manager display – MS FE Hub 924TX unknown • Setup screen display – Module Removed! Connection closed! These messages are normal and indicate the module is not manageable.

  • Page 73: If The Process Does Not Complete

    — Port State LEDs flash indicating various subroutines are running (standard self-test pattern). • Hub Manager display – MS FE Hub 924TX unknown This message is normal and indicates the module is not manageable. If the Process Does not Complete...

  • Page 74: When The Dlu Process Is Complete

    Step Action Select Option [3] Show Current Settings from the MS FE Hub 924TX INSTALLATION MENU. Verify that the correct firmware version has been loaded. Press <Return> for the Main Menu. 4-24 Configuring the Module in a DIGITAL MultiSwitch 900...

  • Page 75: Configuring The Module In A Dechub One Or Dechub One- Mx

    Chapter 5 Configuring the Module in a DEChub ONE or DEChub ONE-MX Overview Introduction This chapter describes how to configure the module as a standalone module with a DEChub ONE or DEChub ONE-MX docking station. For installation procedures refer to the DEChub ONE-MX Installation or DEChub ONE-MX Installation manual. NOTE The module must be installed and cabled prior to configuration.

  • Page 76: Configuring The Module

    Configuring the Module This section describes how to configure your DIGITAL MultiSwitch Fast Ethernet Hub 924TX when the module is installed in a DEChub ONE or DEChub ONE-MX as a standalone device. For cabling and setup port information refer to Chapter 3.

  • Page 77: Restart With Factory Defaults

    Memory (NVRAM) parameters to be cleared and reinitialized to factory default values. If you need to reboot the module and retain the current settings, choose option [2] Restart with Current Settings from the MS FE Hub 924TX INSTALLATION MENU. Allow approximately one minute for the module to reboot and complete self-test.

  • Page 78: Restart With Current Settings

    Allow approximately one minute for the module to restart. The following example shows the dialog associated with this option. Enter selection: 2 MS FE Hub 924TX ================================================================= RESTART WITH CURRENT SETTINGS This selection will reset your system with the current configuration settings.

  • Page 79: Show Current Settings

    The following example shows the display associated with this option. Entries in this display are defined following the screen. Enter selection : 3 MS FE Hub 924TX ==================================================================== MS FE Hub 924TX, HW=B,RO=V1.0,SW=V1.0 Last Firmware Upgrade D1.0.17 -> D1.0.18 @18 resets...
  • Page 80 [3] Show Current Settings Line Field Description SNMP Read/Write The SNMP Read/Write Community name is Community: public98 used for read/write access control. SNMP Trap This is the address where the module sends Addresses: SNMP trap addresses. 16.7.88.156 Status of Last Provides details about the last firmware Downline Upgrade: upgrade.

  • Page 81: Configure Ip

    [4] Configure IP This option provides you with IP configuration selections. The following example shows the dialog associated with this menu: Enter selection : 4 MS FE Hub 924TX ========================================================= IP CONFIGURATION Set SNMP Read/Write Community Add SNMP Trap Addresses...

  • Page 82: Set Snmp Read/Write Community

    The following example shows the dialog associated with this option: Enter selection : 1 MS FE Hub 924TX ================================================================ SET SMNP READ/WRITE COMMUNITY Format: The format for a community name is a string, consisting...

  • Page 83: Add Snmp Trap Addresses

    This option prompts you to enter IP addresses to which the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module sends SNMP traps. You can enter up to eight trap addresses. If one or more SNMP trap addresses were previously configured, the screen displays those addresses.

  • Page 84: Delete Snmp Trap Addresses

    The following example shows the dialog associated with this option: Enter selection : 3 MS FE Hub 924TX ================================================================ DELETE SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...

  • Page 85: Set In-Band Interface Ip Address

    The factory default setting is no in-band address. The following example shows the dialog associated with this option: Enter selection : 4 MS FE Hub 924TX ================================================================ IN-BAND INTERFACE IP ADDRESS CONFIGURATION Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...

  • Page 86: Set Out-Of-Band Interface Ip Address

    To enable out-of-band management, you need to assign an OBM IP address and select an OBM port speed from the MS FE Hub 924TX Installation MENU. See DEChub ONE Installation or DEChub ONE-MX Installation manuals for OBM port cabling information.

  • Page 87: Enable/Disable Bootp

    The factory default setting is DISABLED. If BootP is enabled, the word DISABLED shown in the following dialog is replaced with the word ENABLED. The following example shows the dialog associated with this option: Enter selection : 6 MS FE Hub 924TX ========================================================= ENABLE/DISABLE BOOTP BOOTP is the IP bootstrap protocol.

  • Page 88: Dump Error Log

    Firmware upgrades are also recorded in the error log. The following example shows the display associated with this option: Enter selection : 6 MS FE Hub 924TX - slot 8 ========================================================= DUMP ERROR LOG CURRENT RESET COUNT: 18...

  • Page 89: Downline Upgrade

    Step Action Select the Configure IP option (option 4) from the MS FE Hub 924TX INSTALLATION MENU. Select the Set In-Band Interface IP Address option (option 4) from the IP Configuration menu. Enter the IP address, subnet mask and default gateway and press Return.

  • Page 90: Using The Dlu Process

    Do not turn off power to the unit or perform any action that can cause the unit to lose power during Stage 3 of the DLU process. When you select this option from the MS FE Hub 924TX INSTALLATION MENU, the initial setup screen display appears. This screen identifies the option and alerts the user not to interrupt power during the downline load.

  • Page 91: Initializing The Process

    [6] Downline Upgrade Initializing the Process To initiate the DLU process, complete the following steps: Step Action Example Press Return. <Return> If the file is located in the default TFTP DLMT2100.BIN directory, enter the firmware image file <Return> name and press Return. (The TFTP load host conventions specify the format of the firmware image file name).

  • Page 92: Dlu Process Stages

    [6] Downline Upgrade DLU Process Stages The DLU process consists of four stages: Stage Description Transferring the image to the module’s temporary storage buffer Verifying the image Writing the new image into nonvolatile flash memory Resetting module and self-test Table 5-1 explains what happens during each stage of the DLU process: Table 5-1: DLU Process Description Stage Description...
  • Page 93 [6] Downline Upgrade Stage Description The module verifies that the firmware image is correct. This stage normally takes 10 seconds to complete. The following states indicate that this stage is in progress: • Module status – cannot respond to management requests •...

  • Page 94: If The Process Does Not Complete

    [6] Downline Upgrade Stage Description The module resets, runs self-test, and then begins executing the new firmware image. This stage normally takes 1 minute to complete. The following states indicate that this stage is in progress: • Module status – not functional or manageable. •...

  • Page 95: Verifying The Upgrade

    Step Action Select Option [3] Show Current Settings from the MS FE Hub 924TX INSTALLATION MENU. Verify that the correct firmware version has been loaded. Press <Return> for the Main menu. Configuring the Module in a DEChub ONE or DEChub ONE-MX 5-21...

  • Page 96: Configure Out-Of-Band Port

    Set port speed • Enable or disable Request to Send (RTS) The following example shows the dialog associated with this option: Enter selection : 7 MS FE Hub 924TX ========================================================= [1] Set Port Speed [2] Enable/Disable RTS [3] Return to Main Menu ========================================================= Enter selection number: n <Return>...

  • Page 97: Set Port Speed

    The port speeds at both ends of the communications link must be identical. The following example shows the dialog associated with this option: Enter selection : 1 MS FE Hub 924TX ================ ========================================= SET OUT-OF-BAND (OBM) PORT SPEED [1] 2400 baud...

  • Page 98: Enable/Disable Rts

    Disabled. The following example shows the dialog associated with this option if RTS is disabled: Enter selection : 2 MS FE Hub 924TX ========================================================= ENABLE/DISABLE OUT-OF-BAND PORT RTS Enable/Disable request to send (RTS) option allows additional control to modem communications.

  • Page 99: Removing A Module And Option Cards

    Topic Page Removing Modules from the DIGITAL MultiSwitch 900 (Hot- Swappable) Removing Cables from the 100BASE-TX Fixed Ports Removing the MM-100 Replacing the Dust Cover on the DIGITAL MultiSwitch Fast Ethernet Hub 924TX Removing a Module and Option Cards 6-1...

  • Page 100: Removing Modules From The Digital Multiswitch 900

    Removing Modules from the DIGITAL MultiSwitch 900 (Hot-Swappable) Removing Modules from the DIGITAL MultiSwitch 900 (Hot-Swappable) To remove the module from the DIGITAL MultiSwitch 900, complete the following steps (see Figure 6-1). Figure 6-1: Removing the Module from a DIGITAL MultiSwitch 900 NPG-0008-95F Step Action...

  • Page 101: Removing Cables From The 100Base-Tx Fixed Ports

    Removing Cables from the 100BASE-TX Fixed Ports Removing Cables from the 100BASE-TX Fixed Ports Complete the following steps to remove 100BASE-TX cables from the module as shown in Figure 6-2. Figure 6-2: 100BASE-TX Cable Removal on the Module NPB-0858-97F Step Action Push in on the release tab (1) and remove the connector (2) from the module’s 100BASE-TX port.

  • Page 102: Removing The

    Removing the MM-100 Removing the MM-100 Complete the following steps to remove an MM-100 from the module (Figure 6-3). Figure 6-3: Removing the MM-100 NPB-0869-97F Depending on the type of connectors used on the card, there will be differences in the way cables are removed.
  • Page 103 Removing the MM-100 Step Action Use a Phillips-head screwdriver to loosen the two captive screws that hold the card in place. Grasp the captive screws and disconnect the card from the host module by pulling on the screws. Gently slide the card out of the slot. Replace the dust caps on the card, if necessary.

  • Page 104: Replacing The Dust Cover On The Digital Multiswitch Fast Ethernet Hub 924Tx

    Replacing the Dust Cover on the DIGITAL MultiSwitch Fast Ethernet Hub 924TX Replacing the Dust Cover on the DIGITAL MultiSwitch Fast Ethernet Hub 924TX Figure 6-4 shows dust cover location and the table describes how to replace the cover. Figure 6-4: Dust Cover Replacement...

  • Page 105: A Problem Solving

    For detailed information about modular media interface LEDs, refer to the 100 Mb/s Fast Ethernet Modular Media Cards Installation manual. In This Appendix Topic Page DIGITAL MultiSwitch Fast Ethernet Hub 924TX LED States DIGITAL MultiSwitch Fast Ethernet Hub 924TX Problem Solving Using the LEDs Problem Solving A-1...
  • Page 106 DIGITAL MultiSwitch Fast Ethernet Hub 924TX LED States Table A-1 describes the states indicated by the module’s LEDs (shown in the following illustration). MultiSwitch Fast Ethernet Hub 924TX NPB-0922-97F Table A-1: DIGITAL MultiSwitch Fast Ethernet Hub 924TX LED States LED(s) Green On Green Yellow On...
  • Page 107 DIGITAL MultiSwitch Fast Ethernet Hub 924TX LED States LED(s) Green On Green Yellow On Yellow Blinking Blinking NOTE If one group is selected (all 24 ports are in one collision domain), LED1 will blink when LAN1 (Groups A, B, C, and D) is active. If two groups are selected, LED1 will blink when LAN1 (Group A and B) is active and LED2 will blink when LAN2 (Group C and D) is active.
  • Page 108 Solving Using the LEDs A problem is often indicated by the combined states of the DIGITAL MultiSwitch Fast Ethernet Hub 924TX’s LEDs. Table A-2 lists the states of the LEDs for various error conditions, the probable causes, and corrective action to take.
  • Page 109 DIGITAL MultiSwitch Fast Ethernet Hub 924TX Problem Solving Using the LEDs Table A-2: Typical Combined States of LEDs Symptom Probable Cause Corrective Action Power LED is off. The module is not Check the power status on the receiving +5Vdc. module, or DIGITAL MultiSwitch 900.
  • Page 110 DIGITAL MultiSwitch Fast Ethernet Hub 924TX Problem Solving Using the LEDs Symptom Probable Cause Corrective Action The module OK A non-fatal error Power off and on. If the problem LED is blinking, occurred. persists, either replace the module but continues to...

  • Page 111: In This Appendix

    Introduction This appendix shows the pin assignments of the connectors, cables, and adapters that are part of, or can be used with, the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module and DIGITAL MultiSwitch 900. For detailed information about Modular Media Interface (MM-100) connectors, refer to the 100 Mb/s Fast Ethernet Modular Media Cards Installation manual.

  • Page 112: Digital Multiswitch Fast Ethernet Hub 924Tx Connectors And Pin Assignments

    Pin Assignments 100BASE-TX (8-pin MJ) Port Connector All 24 fixed port connectors on the DIGITAL MultiSwitch Fast Ethernet Hub 924TX are 100BASE-TX, 8-pin MJ, crossover connectors. Table B-1 defines the 8-pin MJ connector pin assignments. Figure B-1 shows their location.

  • Page 113: Digital Multiswitch 900 Connectors And Pin Assignments

    DIGITAL MultiSwitch 900 Connectors and Pin Assignments DIGITAL MultiSwitch 900 Connectors and Pin Assignments OBM Port (9-Pin) Connector Table B-2 describes the OBM connector pin assignments used on the DIGITAL MultiSwitch 900 and Figure B-2 shows their location. Figure B-2: OBM Port (9-Pin) Connector NPG-0299-95F Table B-2: OBM Port (9-Pin) Connector Pin Assignments Pin No.

  • Page 114: Dechub One And Dechub One-Mx Connectors And Pin Assignments

    DEChub ONE and DEChub ONE-MX Connectors and Pin Assignments DEChub ONE and DEChub ONE-MX Connectors and Pin Assignments 10BaseT (8-pin MJ) Port Connector Figure B-3 shows the 8-pin MJ (straight-through) connector and its pin assignments. Table B-3 describes the 8-pin MJ (straight-through) connector and its pin assignments used on the DEChub ONE and DEChub ONE-MX.

  • Page 115: Aui (15-Pin D-Sub) Port Connector

    DEChub ONE and DEChub ONE-MX Connectors and Pin Assignments AUI (15-pin D-Sub) Port Connector Figure B-4 shows the shielded 8-pin MJ Twisted Pair 15-pin AUI connector and its pin assignments. Table B-4 describes the shielded 8-pin MJ Twisted Pair 15-pin AUI connector and its pin assignments used on the DEChub ONE and DEChub ONE-MX.

  • Page 116: Obm Port (9-Pin) Connector

    DEChub ONE and DEChub ONE-MX Connectors and Pin Assignments OBM Port (9-Pin) Connector Table B-5 describes the OBM connector pin assignments used on the DIGITAL MultiSwitch 900 and Figure B-5 shows their location. Figure B-5: OBM Port (9-Pin) Connector NPG-0299-95F Table B-5: OBM Port (9-Pin) Connector Pin Assignments Pin No.

  • Page 117: Adapters

    Adapters Adapters The following adapters are used with the DIGITAL MultiSwitch 900 or a device such as a PC or terminal. H8571-J Adapter Figure B-6 shows the H8571-J adapter (6-pin MMJ to 9-pin D-Sub connector) can be used when connecting to the OBM port on the DIGITAL MultiSwitch 900. EOS/ESD protection devices are not shown in the illustration.

  • Page 118: Internal And External Crossover Configurations

    (3) and crossover (4) types of devices. The module uses crossover connectors. Figure B-8: Crossover Configurations Internal Crossover Configuration: MultiSwitch Device (switch) (BN25G FE Hub 924TX External Crossover Configuration: MultiSwitch MultiSwitch (BN24F) FE Hub 924TX FE Hub 924TX NPB-0919-97F If screened cabling is required, use BN26M.

  • Page 119: C Product Specifications

    Appendix C Product Specifications Overview Introduction This appendix lists product and acoustical specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX, and connectors used with these products. In This Appendix Topic Page Product Specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX...

  • Page 120: Product Specifications For The Digital Multiswitch Fast Ethernet Hub 924Tx

    Product Specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX Product Specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX Table C-1 lists the product specifications for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX. Table C-1: Product Specifications for the DIGITAL MultiSwitch Fast...

  • Page 121: Acoustical Specifications

    DIGITAL MultiSwitch Fast Ethernet Hub 924TX + DEChub DLMT2-MA + DEFHU DIGITAL MultiSwitch Fast Ethernet Hub 924TX + DEChub ONE-MX DLMT2-MA + DEF1H Current values for specific configurations are available from Cabletron Systems representatives. 1 B = 10 dBA. Product Specifications C-3...
  • Page 122 DIGITAL MultiSwitch Fast Ethernet Hub 924TX + DEChub ONE DLMT2-MA + DEFHU DIGITAL MultiSwitch Fast Ethernet Hub 924TX + DEChub ONE-MX DLMT2-MA + DEF1H Aktuelle Werte für spezielle Ausrüstungsstufen sind über die Cabletron Systems Vertretungen erhältlich. 1 B = 10 dBA.

  • Page 123: D Ordering Options

    Appendix D Ordering Options Overview Introduction This appendix describes the ordering information for the DIGITAL MultiSwitch Fast Ethernet Hub 924TX. In This Appendix Topic Page Ordering Options Ordering Options D-1...
  • Page 124 Ordering Options Ordering Options Option Part Number DIGITAL MultiSwitch Fast Ethernet Hub 924TX, fixed 24- DLMT2-MA port 100 Mb/s Hub Expansion Slot MM-100 Options: • 100BASE-FX DEXYM-AA • 100BufFX DEXYM-BA Straight-through Cable BN25G-xx Crossover Cable BN24Q-xx Adapter H8571-J (Used when connecting to the OBM port on the DIGITAL...

  • Page 125: E Associated Documentation

    Appendix E Associated Documentation Overview Introduction This appendix describes the associated documentation, how to order additional documentation, and correspondence. In This Appendix Topic Page Documentation Accessing Online Information Associated Documentation E-1...

  • Page 126: Documentation

    Documentation Documentation The following documents provide information relating to the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module. To order any of the following documents, refer to the section titled How to Order Additional Documentation. Title and Order Description Number DIGITAL...
  • Page 127 Documentation Title and Order Description Number DIGITAL Provides installation, use, security, and troubleshooting MultiSwitch 900 information for the DIGITAL MultiSwitch 900. Owner’s Manual EK-DH2MS-OM DEChub Network Describes the functions and features of DIGITAL’s HUB- Modules 900-Series based 900-Series switching products. Switch Reference EK-SWTCH-HR OPEN DECconnect...

  • Page 128: Accessing Online Information

    Accessing Online Information Accessing Online Information Documentation Comments If you have comments or suggestions about this document, send them to TechWriting@cabletron.com Online Services To locate product-specific information, refer to one of the following World Wide Web sites: Americas: http://www.networks.digital.com http://www.cabletron.com/ Europe http://www.networks.europe.digital.com Asia Pacific...

  • Page 129: F Accessing And Configuring Rmon Groups

    Appendix F Accessing and Configuring RMON Groups Overview Introduction This appendix describes how to access the four RMON groups and how to configure the Alarms and Events groups. In This Appendix Topic Page What Is RMON? Groups Supported How to Access RMON Groups Accessing and Configuring RMON Groups F-1...

  • Page 130: What Is Rmon

    What Is RMON? What Is RMON? RMON is a Remote Network Monitoring Management Information Base (RMON MIB). RMON gathers a wide variety of statistical information about network operation. A typical network consists of multiple network segments with one RMON agent connected to each segment. RMON gathers this information by examining each packet passed on a network segment.

  • Page 131: Groups Supported

    Groups Supported Groups Supported The four RMON groups supported by this module are Statistics, History, Alarms, and Events. The following table defines these four groups: This group... Allows you to... Statistics Obtain an array of operational statistics including: • Packets •...

  • Page 132: How To Access Rmon Groups

    How to Access RMON Groups How to Access RMON Groups This section provides you with procedures that describe how to access the RMON Groups. RMON Group To Access/Use these Groups ... Statistics and History Use the clearVISN MultiChassis Manager Alarms and Events Use any SNMP network manager Accessing Statistics and History To access the Statistics and History groups, you must use the clearVISN MultiChassis...

  • Page 133: Alarm And Event Table Entries

    How to Access RMON Groups The RMON Alarms and Events MIB objects eventDescription, alarmOwner, and eventOwner support up to 127 characters. MIB object eventCommunity supports up to 32 characters. The maximum number of entries that can be placed in the alarmTable is 20.
  • Page 134 How to Access RMON Groups Table F-1: Alarm Table Entry Fields Alarm Table Entry Fields Definition alarmIndex An index that uniquely identifies an entry (see note below). alarmInterval The interval, in seconds, over which the data is sampled and compared with the rising and falling threshold.

  • Page 135: How Traps Work

    How to Access RMON Groups Table F-2: Event Table Entries Event Table Entry Fields Definition eventIndex An index that uniquely identifies an entry (see note below). eventDescription A comment describing this event. eventType The type of notification that will occur when the threshold is being reached.

  • Page 137: Glossary

    Glossary Overview Introduction This glossary lists and defines terms used in the DIGITAL MultiSwitch Fast Ethernet Hub 924TX module documentation. In This Glossary Topic Page Terms Glossary-2 Glossary-1...

  • Page 138: Terms

    Terms This manual uses the following terms Terms Descriptions Ethernet Local Area Network (LAN) compatible with the ISO 802-3 ANSI/IEEE 802.3 standards and the Ethernet standards for Carrier Sense Multiple Access with Collision Detection (CSMA/CD) local area networks (LANs). Fast Ethernet A 100 Mb/s extension to Ethernet, also referred to as 100BaseT.
  • Page 139 Terms Descriptions DEChub ONE-MX A 90 watt power supply, setup port, OBM and AUI ports, and Fiber Optic, FDDI or Ethernet LAN connection for a functional module. DEChub ONE A 81.1 watt power supply and setup port interface, OBM and AUI ports for functional module. dedicated Ethernet 10Base2 coaxial cable 10 Mb/s Ethernet connection.

  • Page 141: Index

    900 Features 1-13 Alarms and Events F-4 900 management agent 1-14 Statistics and History F-4 Fast Ethernet Hub 924TX Back Panel 1-9 Accessing and Configuring RMON Groups F-1 Fast Ethernet Hub 924TX Connectors and Acoustical Specifications C-3 Pin Assignments B-2...
  • Page 142 MM-100 6-4 What Is the DIGITAL MultiSwitch Fast Ethernet Replacing the Dust Cover on the DIGITAL Hub 924TX? 1-3 MultiSwitch Fast Ethernet Hub 924TX Restart with Current Settings 4-6 Restart with Factory Defaults 4-5 RMON Alarm and Event Table Entries F-5...

Table of Contents
