Standard tool bar

The standard tool bar is shown in Figure 14. The meanings of the icons are listed below:
1 CREATE A NEW PROJECT
2 CHANGE USER PARAMETERS (name, company, etc)
3 SAVE THE ACTUAL PROJECT
4 LOAD AN EXISTING PROJECT (FROM THE PC)
5 PRINT THE PROJECT SCHEMATIC
6 PRINT PREVIEW
7 PRINTING AREA
8 SNAP TO GRID
9 RESOURCES ALLOCATION
10 PRINT THE PROJECT REPORT
11 UNDO (CANCEL THE LAST COMMAND)
12 REDO (RESTORE THE LAST CANCELLATION)
13 VALIDATE THE PROJECT
14 CONNECT TO MZERO
15 SEND PROJECT TO MZERO
16 DISCONNECT FROM MZERO
17 DOWNLOAD AN EXISTING PROJECT (FROM MZERO)
18 MONITOR (Real time I/O status - graphic)
19 MONITOR (Real time I/O status - textual)
20 DOWNLOAD LOG FILE
21 SHOW SYSTEM CONFIGURATION
22 DOWNLOAD ERRORS LOG
23 DELETE ERRORS LOG
24 SCHEMATIC SIMULATION
25 GRAPHIC SIMULATION
26 CHANGE PASSWORD
27 HELP ON-LINE
28 PASSWORD RECOVERY (only with the unlock file, see
8541403 • 19/07/2021 • Rev.1
STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
Figure 14
Level 2 password)
