MZERO 16.4 PINOUT

TERMINAL SIGNAL
1 24VDC
2 24VDC
3 NC
4 0VDC
5 OSSD1_A
6 OSSD1_B
7 RESTART_FBK1
8 OUT_STATUS1
9 OSSD2_A
10 OSSD2_B
11 RESTART_FBK2
12 OUT_STATUS2
13 OSSD3_A
14 OSSD3_B
15 RESTART_FBK3
16 OUT_STATUS3
17 OSSD4_A
18 OSSD4_B
19 RESTART_FBK4
20 OUT_STATUS4
21 OUT_TEST1
22 OUT_TEST2
23 OUT_TEST3
24 OUT_TEST4
25 INPUT1
26 INPUT2
27 INPUT3
28 INPUT4
29 INPUT5
30 INPUT6
31 INPUT7
32 INPUT8
33 INPUT9
34 INPUT10
35 INPUT11
36 INPUT12
37 INPUT13
38 INPUT14
39 INPUT15
40 INPUT16
8541403 • 19/07/2021 • Rev.1
STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
TYPE DESCRIPTION
- 24VDC power supply
- 24VDC power supply
-
- 0VDC power supply
Output
Static output 1
Output
Input Feedback/Restart 1
Output SIL 1/PL c output
Output
Static output 2
Output
Input Feedback/Restart 2
Output SIL 1/PL c output
Output
Static output 1
Output
Input Feedback/Restart 1
Output SIL 1/PL c output
Output
Static output 2
Output
Input Feedback/Restart 2
Output SIL 1/PL c output
Short circuit detection output
Output
Short circuit detection output
Output
Short circuit detection output
Output
Short circuit detection output
Output
Input Digital input 1
Input Digital input 2
Input Digital input 3
Input Digital input 4
Input Digital input 5
Input Digital input 6
Input Digital input 7
Input Digital input 8
Input Digital input 9
Input Digital input 10
Input Digital input 11
Input Digital input 12
Input Digital input 13
Input Digital input 14
Input Digital input 15
Input Digital input 16
Table 2
-
Input (type 2) according to EN 61131-2
Input (type 2) according to EN 61131-2
Input (type 2) according to EN 61131-2
Input (type 2) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
Input (type 3) according to EN 61131-2
OPERATION
-
-
-
-
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
