Textual tool bar

Optionally the textual tool bar shown below is also available (drop down).

Create a new project (configure the MZERO system)

•
Select icon CREATE (Figure 14) from the standard tool bar to start a new project. The user
authentication window is displayed (Figure 16).
•
Next the MZD displays a window showing the MZERO controller on the right-bottom angle.

Change user parameters

The change of user parameters is obtained with the icon
The dialog user identification request appears (Figure 17). To accomplish this operation is not
necessary to Log out from MZERO. Generally it serves when the user must create a new project
(even using a previously created).
26
STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
Figure 15
Figure 16
Figure 17
.
