English
APPLICATION
Laser cross level is a type of laser levels. With ADA 3D LINER 2V / 4V Green
you can take horizontal and vertical marking. You can use the instrument
inside and outside.

SPECIFICATIONS

Laser beam .......................................................2V/4V1H1D
Light sources ................................................... 532nm/floor point 650nm
Laser safety class ............................................ Class 2, <1mW
Accuracy ........................................................... ±0.2mm/1m
Self-leveling range .......................................... ±3°
Operating range
with/without receiver
Power source .................................................. Li-ion batteery 3.7 V 3200 mАh /4
Rotation/Fine adjustment ..........................360°
Tripod thread .................................................. 5/8"
Operating temperature ................................. -10°C +40°C
Weight ............................................................... 0,9 kg
*depends on illumination

FUNCTIONAL DESCRIPTION

1. 2 or 4 vertical lines (the quantity of lines depends on the model of the
instrument), 1 horizontal line, plumb down.
2. Can be used both for operation indoor and outdoor. Use the receiver
for outdoor operation up to 70 m.
3. Electronic compensator ensures quicker self-leveling within range
±3° .
4. When the instrument inclines more than ±3° the laser lines
automatically gleam.
5. 360° rotating fine adjustment mechanism makes it easier to
aim the vertical beam.
6. When turning off the power, built-in locking system can automatically
lock the compensator to avoid vibration during the transportation.
........... 70/40 m
AA batteries / charger
