3D LINER

Functional description

1. 2, 3 or 4 vertical lines (the quantity of lines depend on the model of the instrument), 1 horizontal line, plumb down.
2. Can be used both for operation indoor and outdoor. Use the receiver for outdoor operation up to 40 m.
3. Electronic compensator ensures quicker self-leveling.
4. When the instrument inclines more than ±2 the laser lines automatically gleam.
5. 360° rotating fine adjustment mechanism makes it easier to find objects correctly.
6. When turning off the power, built-in locking system can automatically lock the compensator to avoid vibration during the
transportation.
