FUNCTIONAL DESCRIPTION

1. Emitting a horizontal and vertical laser line.
2. Quick self-leveling: when line accuracy is out of the range the laser line
flashes and the warning sound is produced.
3. Compensator locking system for safe transportation.
4. Intermediate compensator locking system for slope operation.
5. Indoor and outdoor performance function.

SAFETY REQUIREMENTS AND CARE

Follow safety requirements! Don't face and stare at laser beam!
Line laser is an accurate laser tool, which should be stored and used with
care. Avoid shaking and vibrations! Store the Instrument and It's accesso-
ries only In the carrying case. In case of high humidity and low tempera-
ture, dry out the Instrument and clean It after the usage. Do not store the
line laser at a temperature below -20°C and above 50°C, otherwise the
Instrument can be out of action.
Don't put the line laser Into the carrying case If the Instrument or case are
wet. To avoid moisture condensation Inside the Instrument- dry out the case
and laser line laser ! Check regularly line laser adjustment! Keep the lens
clean and dry. To clean the line laser use a soft cotton napkin!

OPERATION

Cube 3D GREEN is a reliable and convenient line laser . It will be irreplaceable
line laser for many years. Open battery compartment. Insert batteries into
the battery compartment. Observe the polarity. Close the battery compart-
ment. Take out batteries if you are not going to use the tool for a long time.
-Place the line laser on the working surface or mount it on the tripod/pillar
or wall mount.
Switch on the line laser. Turn the compensator switch (3) to the position
"ON" (the line laser is turned off in the position OFF). Visual alarm (blinking
line) and audible signal indicate that the device was not installed within the
compensation range ±3º. To properly work align the unit in a horizontal plane.
At that compensator of the instrument will be in free position (it will be blocked
in the position OFF). When switching on, one horizontal and one vertical
lines will be projected. Press button (6) to turn on additional vertical line.
