Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Hood Pin
D2D Port
(-) Hood Pin Input
(-) Ground
(+) 12V Input
(-) Factory Alarm Arm Output
(-) Factory Alarm Disarm Output
(programmed for double pulse)
(+) Brake Input
(-) Parking Lights Output
(AC) Tach Input
(+) Accessory 1,2,3 Outputs
(-) Trunk/Hatch Release Output
(+) Starter Output
(+) Ignition Output
6 403.FORD1 4.21 2005 Lincoln LS
© 2020-06-02 Directed. All rights reserved.
Driver
Door Trigger
Cut
OR
Connect to vehicle
Go to
www.directechs.com
for more information
on vehicle-specific
wiring connections.
HS CAN High: Gray/Red, pin 6
1
9
HS CAN Low: Blue/Red, pin 14
HS CAN High: Orange/Green: 5
HS CAN Low: Orange/Brown: 6
(+)12V Input: Brown: 7
(+) Ignition Output: Yellow: 8
RAP Off Interrupt (veh. side): Orange/Red: 10
RAP Off Interrupt (conn. side): Yellow/Red: 11
TX: Yellow/Black: 10
RX: Orange/Black: 11
RX: Gray/Red, pin 4
TX: White/Red, pin 3
).
XKD2D65
OBDII Diagnostic Connector,
8
under Driver Dash
(connector side view)
16
9: Pink: (+) Ignition Input
4
3
2
1
PATS Transceiver
(black conn.
on ignition switch)
