Vehicle connections

The connection information listed below is specific to the 2005 Lincoln LS. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
8 403.FORD1 4.21 2005 Lincoln LS
© 2020-06-02 Directed. All rights reserved.
Description
No Connection
No Connection
No Connection
No Connection
(DATA) HS CAN High [3]
(DATA) HS CAN Low [3]
Relay N.O. (+) 12 Volt Input
Relay COM (+) Ignition Output
Relay N.C. No Connection
Relay N.C. RAP Off Interrupt (vehicle side)
Relay COM RAP Off Interrupt (conn. side)
Relay N.O. No Connection
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(DATA) TX
(DATA) RX
No Connection
Description
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
Ignition Switch, black 8 pin plug, pins 1, 7
Ignition Switch, black 8 pin plug, pin 5
Remote Starter
No Connection
FEM in driver kick, 20 pin plug, pin 8
FEM in driver kick, 20 pin plug, pin 8
No Connection
Ignition Switch, black 8 pin plug, pins 1, 7
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
PATS Transceiver on ignition switch, green 4 pin plug, pin 3
PATS Transceiver on ignition switch, green 4 pin plug, pin 4
No Connection
Connects To
Wire Location
(+/-) Wire Color
Data Gray/Red
Data Blue/Red
+ Red (x2) (common 20A)
+ Green/Black
- N.C. black/yellow
- N.C. black/yellow
+ Red (x2) (common 20A)
(chassis ground)
(+/-) Wire Color
Data White/Red
Data Gray/Red
(+/-) Wire Color
