1-Key Programming Using Key2Go - Directed DB3 Installation Manual

1-Key programming using Key2GO

Do NOT connect other harnesses to the DB3 module.
1
Connect the module to your computer using the XKLoader.
Open an Internet Explorer browser (version 6 or higher), and go to
2
www.directechs.com. The detail of the platform and firmware that is currently saved on
the interface module will be indicated in the top left corner of the page.
3
Flash your module with the firmware corresponding to FORD1 Key2GO.
Connect the module wiring to the vehicle first, and only then, plug the harnesses to the
4
DB3 without pressing the programming button. The LED turns ON solid red.
Insertthe key andthen turn the ignition ON and OFF twice. The LEDnow
flashesorange.
5
If the transponder programming was skipped, the LED turn ON solid orange 3 seconds
then shuts OFF. The programming is now complete.
Remove the module from the vehicle and reconnect it to your computer. The web site
6
will automatically recognize that you are moving onto the second phase of the
programming sequence.
7
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED flashes orange
8
once, turns ON solid green for 3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
15
403.FORD1 4.21 2005 Lincoln LS
© 2020-06-02 Directed. All rights reserved.
