HME8C55E
Hisense LCD Monitor
User Manual
Read the User Guide thoroughly before
using Hisense LCD monitor and keep it
properly for future reference.
RSAG2.025.7401SS B Version
Website: www.hisense.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HME8C55E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense HME8C55E

  • Page 1 HME8C55E Hisense LCD Monitor User Manual Read the User Guide thoroughly before using Hisense LCD monitor and keep it properly for future reference. RSAG2.025.7401SS B Version Website: www.hisense.cn...
  • Page 2: Preface

    Read the User Guide thoroughly before using the LCD monitor and keep it properly for future reference. Hisense shall not be liable for any accidents arising from violations of the safety precautions and use instructions of the User Guide.
  • Page 3: Safety Information And Precautions

    It is recommended that you use the specified accessories of the LCD monitor, which can be used only with the spare parts and accessories that are manufactured or specified by Hisense. Before the operation, test and verify the equipment and completed settings.
  • Page 4 Safety Information and Precautions rise. In this case, turn on the monitor after the condensation disappears; otherwise, the monitor will be damaged.  Do not cover or block any ventilation holes on the device housing. When the monitor is installed in a closet or other closed environments, keep a certain gap between the monitor and sides of the closet.
  • Page 5 The information in this document is subject to change without notice.  This document provides instructions on correctly installing and using the LCD monitor. Please keep it properly. If it is lost, contact Hisense.  See the monitor certificate label for its production date.
  • Page 6: Table Of Contents

    Contents Preface ..................................I Safety Information and Precautions ........................II Contents ..................................1 Overview ................................... 2 Features ................................2 Technical Specifications ........................... 3 Accessories ............................... 4 Installation ................................5 Mounting and Installing the Monitor ........................ 5 Input Port Connection ............................7 Output Port Connection ............................
  • Page 7: Overview

    Overview Thank you for choosing Hisense LCD. This product is an LED-backlit color LCD monitor for professionally trained medical personnel to accurately display a variety of images during surgeries. Features  This monitor has a safety backup design with dual power supplies to ensure seamless connection of the two power supplies and real-time processing, thereby ensuring high reliability during operation and realizing trouble-free and safe display.
  • Page 8: Technical Specifications

    Overview Technical Specifications Model HME8C55E Name LCD monitor Size 55 inches Panel type Color LCD panel Diagonal 139 cm length Backlight Screen size 1209.6 mm x 680.5 mm Screen ratio 16:9 Resolution 3840x2160 Max. monitor display 1.07 billion colors panel colors Pixel pitch 0.315 mm (horizontal) x 0.315 mm (vertical)
  • Page 9: Accessories

    Note  In case of missing or damaged components, please contact Hisense or our designated distributors in time. Please keep the original package. If you need to send this product back, please use the original packaging. Do not press heavy articles on this product during transportation. Do not place...
  • Page 10: Installation

    To mount the equipment on a wall, ensure security during installation and use of the equipment.  Hisense assumes no responsibility for any damage or personal injury caused by improper use or incorrect installation. Installation instruction Mounting arms and brackets that comply with the VESA standard are applicable for the monitor.
  • Page 11 Installation Hanger and accessory (excluded) 1. Before installing the wall-mounted bracket, put the whole machine on a firm, clean, and padded table. The whole machine is heavy, so ensure that the installation table is firm and reliable. 2. Remove the screws from the mounting holes in the rear shell. 3.
  • Page 12: Input Port Connection

    Installation Input Port Connection Connect one or more video sources to the corresponding video input interface of the monitor: ⑪/⑬/⑮ ⑥ 1. HDMI IN: ③/ ⑨/ 2. SDI IN: ⑤ 3. DVI: ⑦ 4. DP: ② 5. VGA: Output Port Connection Connect one or more available video receivers to the corresponding video output interface of the monitor: 1.
  • Page 13: Power Supply Connection

    Installation Power Supply Connection Connect the AC power line delivered with the monitor to the AC power supply interface of the monitor. Protective Grounding Use an AWG18 wire (with the maximum cable length approved by national regulations) to connect the protective grounding pin to the grounding socket to ground the monitor.
  • Page 14: Monitor Components And Connectors

    Monitor Components and Connectors Monitor Front View  Button Description Power It is used to turn on or off the monitor. switch Press and hold the button for 3s for locking or unlocking. The default value is LOCK restored upon restart. The lock function is available for all buttons.
  • Page 15 Monitor Components and Connectors When two or three windows are displayed with no menu, press this button to exchange signal sources. When four windows are displayed with no menu, this button is unavailable. Display Press this button to display the Display Mode menu, and select a multi-window Mode mode.
  • Page 16: Monitor Input And Output Interfaces

    Monitor Components and Connectors Monitor Input and Output Interfaces Power switch Interface Function Connector Description Software upgrade interface Select upgrade 1 or upgrade 2 for different chips. DVI signal input interface DVI1 and DVI2 DP signal input interface DP (DisplayPort 1.2) VGA signal input interface SDI signal input interface SDI IN...
  • Page 17: Definition Of Monitor Connector Pins

    Monitor Components and Connectors Definition of Monitor Connector Pins  Simple HDMI illustration HDMI definition table HDMI pin definition Definition Definition Definition TMDS Data2+ TMDS Data0 Shield SCL (I C Serial Clock for DDC) SDA (I C Serial Data Line for TMDS Data2 Shield TMDS Data0- DDC)
  • Page 18 Monitor Components and Connectors DDC Clock +5 V Power TMDS Clock Shield DDC Data Ground (for +5 V) TMDS Clock+ Hot Plug Detect TMDS Clock-  Simple DP interface illustration DP definition table DP pin definition Definition Definition ML_Lane 3 (n) ML_Lane 0 (p) ML_Lane 3 (p) CONFIG1...
  • Page 19 Monitor Components and Connectors SDI definition SDI pin definition Pin Definition RXD/TXD  Simple illustration for type-B USB interface Definition of type-B USB interface B-type interface pin definition Pin Definition Pin Definition +5 VDC Data+ Data-...
  • Page 20: Operational Instructions And Function Adjustment

    Operational Instructions and Function Adjustment Power-on/off Power-on: Move the IO power switch to I. Then, the power is turned on and the monitor is powered on. Power-off: Move the IO power switch to O. Then, the power is turned off and the monitor is powered off.
  • Page 21: Basic Menu Operations

    Operational Instructions and Function Adjustment User1 Compliant with Gamma, with support for custom parameter settings User2 Compliant with Gamma, with support for custom parameter settings User3 Compliant with Gamma, with support for custom parameter settings User4 Compliant with Gamma, with support for custom parameter settings User5 Compliant with Gamma, with support for custom parameter settings User6...
  • Page 22: Detailed Operation Description

    Operational Instructions and Function Adjustment DVI1 DVI2 Language Chinese and English OSD Settings Upper Left, Bottom Left, Upper Right, Bottom Right, and Menu Location Center Time-out 10s, 20s, 30s, 60s, and 120s SDI(4K) Setting Square Division and 2 Sample Interleave HDMI Output 1920x1080P 60 Hz and 3840x2160P 60 Hz...
  • Page 23 Operational Instructions and Function Adjustment Picture Image mode Factory Backlight Gamma color temperature Brightness Contrast Saturation Sharpness Color Gamut Management Return Select Windows  Image mode This menu is used to switch image modes for system storage, as well as to switch image parameters. Adjustment options: Preset, DICOM, Hybrid GAMMA, User1, User2, User3, User4, User5, and User6.
  • Page 24 Operational Instructions and Function Adjustment It is used to adjust the contrast of the displayed image. The value range is 0-100.  Saturation Adjust the image saturation. Adjustment range: 0-100.  Sharpness Adjust the image resolution. Adjustment range: 0-10.  Color Gamut Management This menu is used to switch the color gamut range of images.
  • Page 25 Operational Instructions and Function Adjustment Display Settings Display Mode Four Window Swap PIP Setting Image Freezing Image Rollovers Image Rotating Full Scale VGA Auto Adjust Select Return Windows  Display Mode This menu is used to adjust the multi-window mode of the monitor. Adjustment options: Single Window, PIP, Fill PBP, Level PBP, Three Window1, Three Window2, and Four Window Note...
  • Page 26 Operational Instructions and Function Adjustment  Flip Pattern It is used to switch the image flip mode. Options are Normal, Mirror, and Rotation. Note  Rotation is used to rotate the image by 180° along the horizontal direction.  Mirror is used to rotate the image by 180° along the vertical direction. ...
  • Page 27 Operational Instructions and Function Adjustment Signal Input Adjustment steps:  Press MENU to call out the User menu. Press the ▲ UP or ▼ DOWN button to select  , and press the MENU button to access the Signal Input menu. Press the ▲...
  • Page 28 Operational Instructions and Function Adjustment OSD Settings Language Chinese Upper Right Menu Location Time-out Select Return Windows  Language It is used to set the display language of the OSD menu. Adjustment options: Chinese and English  Menu Location It is used to set the display position of the User menu. Options are Upper Left, Bottom Left, Upper Right, Bottom Right, and Center.
  • Page 29 This menu is used to adjust the resolution type for HDMI output. Adjustment options: 1920x1080P 60Hz and 3840x2160P 60Hz  Logo Set It is used to set whether to display the Hisense LOGO upon power-on. Options are Enable and Disable. Note  The default value is Enable.
  • Page 30 Operational Instructions and Function Adjustment  Monitor Info View the information about the local monitor. Available options: Model, SN, Panel Resolution, Product Usage Time, and Backlight Usage Time.  Mode Rename It is used to rename the User mode. Note ...
  • Page 31: Troubleshooting

    Troubleshooting Troubleshooting Before repair, check the following table for possible fault causes. If the fault persists after you follow the instructions in the User Guide, you can consider repair. Fault Symptom Solution  Check whether the power plug is securely connected to the The power indicator does not socket.
  • Page 32: Maintenance Disclaimer

     Hisense or our authorized distributor will not be liable for any damage or loss of data or other information stored in any media or any component of any product after the product is repaired by Hisense or our authorized distributor.
  • Page 33: Safety Information

    Adjust the position or direction of the affected equipment.  Increase the distance between the LCD monitor and the affected equipment.  Consult Hisense.  Please use the power line provided by our company and ground it correctly.  Do not modify or retrofit the LCD monitor by yourself. Failure to comply with cause interference and damage to the LCD monitor.
  • Page 34: Compliance Information

    Compliance Information Intended Use HME8C55E is a monitor for displaying images from cameras or other systems in medical environments. FCC class B This device conforms to requirements of Federal Communications Commission (FCC). Equipment operations are restricted by the following two conditions: (1) This equipment cannot cause harmful interferences, (2)and this equipment must be resistant to any interferences, including interferences that may cause unnecessary operations.
  • Page 35 containing harmful substances.  Environmental-friendly Environmental-friendly service life service life identifier The environment protection service life mark printed on the nameplate and storage box of this product indicates that the environment protection service life of electrical and electronic products is 10 years. Names and content of harmful substances in the LCD monitor Harmful Substance Lead...
  • Page 36: Biological Hazards And Return

    Biological Hazards and Return This device has specific structure, specifications, and manufacturing materials which are easy to wipe and clean, and is suitable for multiple purposes in hospitals and other medical environments where regular cleaning procedures are established. However, to prevent the spread of infectious agents, this device cannot be used in bio-polluted environments.
  • Page 37 Copyright Statement This document is protected by copyright. All rights reserved. Without written permission by Hisense, this document or any part of it shall not be copied in any form or in any method, such as images and electronic or mechanical forms, including photocopying, recording, or information storage and retrieval systems.
  • Page 38: Symbol Description

    Symbol Description Symbols on the Device On the device or power supply, you can see the following symbols (this list may not include all symbols): Indicates that the equipment complies with the requirements of the applicable EC directives. This device meets the requirements of Part 15 of FCC regulations (Class A or Class This device has been certified by Canadian and American UL regulations.
  • Page 39 Symbol Description Direct current (DC). Power-on. Power-off. Grounding device. EU authorized representative information. The terminal of the device places different parts of the system at the same potential. Humidity limit. Atmospheric pressure limit.
  • Page 40: Annex

    Annex Annex A Allowed Signal Formats All-window HDMI SDI(4K) Display Channel 1024 x 768 @ 60 1024 x 768 @ 60 4096 x 2160p 1024 x 768 @ 60 Hz 720/59.94p 1280 x 1024 @ 60 1280 x 1024 @ 60 4096 x 2160p 1280 x 1024 @ 60 Hz 720/60p...
  • Page 41 Annex Appendix B Monitor Size (Unit: mm)
  • Page 42 Qingdao Hisense Medical Equipment Co., Ltd. Address: North, 3F, Outsourcing Center of Software Park, No. 169, Songling Road, Laoshan District, Qingdao, P.R.China Hisense national customer service hotline: 4009940707 Service Supervisor Email of Hisense Group: haixinfuwu@hisense.com...
