Hisense LCD Monitor
RSAG2.025.7186SS B Version
Website: www.hisense.cn
User Manual
Read the User Guide thoroughly before
using Hisense LCD monitor and keep it
properly for future reference.
HME8C55S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HME8C55S and is the answer not in the manual?

Questions and answers

Related Manuals for Hisense HME8C55S

Summary of Contents for Hisense HME8C55S

  • Page 1 HME8C55S Hisense LCD Monitor User Manual Read the User Guide thoroughly before using Hisense LCD monitor and keep it properly for future reference. RSAG2.025.7186SS B Version Website: www.hisense.cn...

  • Page 2: Preface

    Read the User Guide thoroughly before using the LCD monitor and keep it properly for future reference. Hisense shall not be liable for any accidents arising from violations of the safety precautions and use instructions of the User Guide.

  • Page 3: Safety Information And Precautions

    It is recommended that you use the specified accessories of the LCD monitor, which can be used only with the spare parts and accessories that are manufactured or specified by Hisense. Before the operation, test and verify the equipment and completed settings.
  • Page 4 Safety Information and Precautions rise. In this case, turn on the monitor after the condensation disappears; otherwise, the monitor will be damaged.  Do not cover or block any ventilation holes on the device housing. When the monitor is installed in a closet or other closed environments, keep a certain gap between the monitor and sides of the closet.
  • Page 5 The information in this document is subject to change without notice.  This document provides instructions on correctly installing and using the LCD monitor. Please keep it properly. If it is lost, contact Hisense.  See the monitor certificate label for its production date.

  • Page 6: Table Of Contents

    Contents Preface ..............................I Safety Information and Precautions ....................II Contents .............................. 1 Overview ............................. 2 Features ............2 Technical Specifications ..........3 Accessories ............4 Installation ............................5 Mounting and Installing the Monitor ........5 Input Port Connection ..........7 Output Port Connection ..........

  • Page 7: Overview

    Overview Thank you for choosing Hisense LCD. This product is an LED-backlit color LCD monitor for professionally trained medical personnel to accurately display a variety of images during surgeries. Features  Hisense HME8C55S is a 55-inch professional high-definition operating room monitor that supports display with 8-megapixel resolution, fully complying with the DICOM standard and meeting the high-precision requirements for medical imaging.

  • Page 8: Technical Specifications

    Overview Technical Specifications Model HME8C55S Name LCD monitor Size 55 inches Panel type Color LCD panel Diagonal length 139 cm Backlight Screen size 1209.6 mm x 680.5 mm Screen ratio 16:9 monitor Resolution 3840x2160 panel Max. display colors 1.07 billion colors Pixel pitch 0.315 mm (horizontal) x 0.315 mm (vertical)

  • Page 9: Accessories

    Standard Note In case of missing or damaged components, please contact Hisense or our designated distributors in time. Please keep the original package. If you need to send this product back, please use the original packaging. Do not press heavy articles on this product during transportation. Do not place any heavy...

  • Page 10: Installation

    To mount the equipment on a wall, ensure security during installation and use of the equipment.  Hisense assumes no responsibility for any damage or personal injury caused by improper use or incorrect installation. Installation instruction Mounting arms and brackets that comply with the VESA standard are applicable for the monitor.
  • Page 11 Installation Hanger and accessory (excluded) 1. Before installing the wall-mounted bracket, place the monitor on a firm, clean, and padded table top. Make sure that the table for installation is firm and reliable to withstand the weight of the monitor. 2.

  • Page 12: Input Port Connection

    Installation Input Port Connection Connect one or more video sources to the corresponding video input interface of the monitor: ① 1. HDMI IN: ③ 2. SDI IN: ⑤ 3. DVI: ⑦ 4. DP: ⑨ 5. SOG: ② 6. VGA: Output Port Connection Connect one or more available video receivers to the corresponding video output interface of the monitor: 1.

  • Page 13: Power Supply Connection

    Installation Power Supply Connection Connect the AC power line delivered with the monitor to the AC power supply interface of the monitor. Protective Grounding Use an AWG18 wire (with the maximum cable length approved by national regulations) to connect the protective grounding pin to the grounding socket to ground the monitor.

  • Page 14: Monitor Components And Connectors

    Monitor Components and Connectors Monitor Front View  Button Description Power It is used to turn on or off the monitor. switch Press and hold the button for 3s for locking or unlocking. The default value is LOCK restored upon restart. The lock function is available for all buttons.

  • Page 15: Monitor Input And Output Interfaces

    Monitor Components and Connectors INPUT2 Press this button to configure signal sources for each window. Press this button to select the signal source of a window. When a single window is displayed, the signal source shortcut menu is INPUT1 displayed. When multiple windows are displayed, the window selection menu is displayed.
  • Page 16 Monitor Components and Connectors SDI signal input interface SDI IN signal output SDI OUT interface HDMI signal input HDMI IN interface HDMI signal output HDMI OUT interface signal input SOG 1 and SOG 2 interface Type-B USB debugging USB 1 and USB 2 interface RS485 Note...

  • Page 17: Definition Of Monitor Connector Pins

    Monitor Components and Connectors Definition of Monitor Connector Pins  Simple HDMI illustration HDMI definition table HDMI pin definition Definition Definition Definition TMDS Data2+ TMDS Data0 Shield SCL (I C Serial Clock for DDC) TMDS Data2 SDA (I C Serial Data Line for TMDS Data0- Shield DDC)
  • Page 18 Monitor Components and Connectors DP Port Definition Table: DP pin definition Definition Definition 1 ML_Lane 3 (n) 11 ML_Lane 0 (p) 3 ML_Lane 3 (p) 13 CONFIG1 5:4 ML_Lane 2 (n) 14 CONFIG2 AUX CH (p) 6 ML_Lane 2 (p) 16 7 ML_Lane 1 (n) 17 AUX CH (n) Hot Plug...

  • Page 19: Operational Instructions And Function Adjustment

    Operational Instructions and Function Adjustment Power-on/off Power-on: Move the IO power switch to I. Then, the power is turned on and the monitor is powered on. Power-off: Move the IO power switch to O. Then, the power is turned off and the monitor is powered off.

  • Page 20: Basic Menu Operations

    Operational Instructions and Function Adjustment User1 Compliant with Gamma, with support for custom parameter settings User2 Compliant with Gamma, with support for custom parameter settings User3 Compliant with Gamma, with support for custom parameter settings User4 Compliant with Gamma, with support for custom parameter settings Note In Hybrid GAMMA mode, it only works on RGB images with an input resolution of 3840 x 2160 pixels.
  • Page 21 Operational Instructions and Function Adjustment Sharpness 0-10 Color Gamut BT709 and BT2020 Management Off, Level1, Level2, and Level3 OSD Settings Language Chinese and English Upper Left, Bottom Left, Upper Right, Bottom Right, and Menu Location Center Time-out 10s, 20s, 30s, 60s, and 120s System Settings HDMI Output 1920x1080P 60 Hz...

  • Page 22: Troubleshooting

    Troubleshooting Troubleshooting Before repair, check the following table for possible fault causes. If the fault persists after you follow the instructions in the User Guide, you can consider repair. Fault Symptom Solution  Check whether the power plug is securely connected to the The power indicator does not socket.

  • Page 23: Maintenance Disclaimer

     Hisense or our authorized distributor will not be liable for any damage or loss of data or other information stored in any media or any component of any product after the product is repaired by Hisense or our authorized distributor.

  • Page 24: Safety Information

    Adjust the position or direction of the affected equipment.  Increase the distance between the LCD monitor and the affected equipment.  Consult Hisense.  Please use the power line provided by our company and ground it correctly.  Do not modify or retrofit the LCD monitor by yourself. Failure to comply with cause interference and damage to the LCD monitor.

  • Page 25: Compliance Information

    Compliance Information Intended Use HME8C55S is a monitor for displaying images from cameras or other systems in medical environments. FCC class B The monitor complies with Part 15 of Federal Communications Commission (FCC) regulations. Equipment operations are restricted by the following two conditions: (1) This equipment cannot cause harmful interferences, (2)and this equipment must be resistant to any interferences, including interferences that may cause unnecessary operations.

  • Page 26: Environmental Protection Information

    Environmental Protection Information Environmental Protection Information Chinese Mainland RoHS  The LCD monitor meets the environmental protection requirements of the Administrative Measures for Limiting the Use of Hazardous Substances in Electrical and Electronic Products.  During its environmental-friendly service life, the LCD monitor does not cause leakage and precipitation of harmful substances and other problems affecting the health of users in the process of use, so it can be used safely.

  • Page 27: Biological Hazards And Return

    Biological Hazards and Return This device has specific structure, specifications, and manufacturing materials which are easy to wipe and clean, and is suitable for multiple purposes in hospitals and other medical environments where regular cleaning procedures are established. However, to prevent the spread of infectious agents, this device cannot be used in bio-polluted environments.
  • Page 28 All trademarks and registered trademarks are owned by their owners. Copyright Statement This document is protected by copyright. All rights reserved. Without written permission by Hisense, this document or any part of it shall not be copied in any form or in any method, such as images and electronic or mechanical forms, including photocopying, recording, or information storage and retrieval systems.

  • Page 29: Symbol Description

    Symbol Description Symbols on the Device On the device or power supply, you can see the following symbols (this list may not include all symbols): Indicates that the equipment complies with the requirements of the applicable EC directives. This device meets the requirements of Part 15 of FCC regulations (Class A or Class B). This device has been certified by Canadian and American UL regulations.
  • Page 30 WARNING Refer to the user manual. Marked according to the EU Waste Electrical and Electronic Equipment (WEEE) Directions. Direct current (DC). Power-on. Power-off. Grounding device. EU authorized representative information. The terminal of the device places different parts of the system at the same potential. Humidity limit.

  • Page 31: Annex

    Annex Annex A Allowed Signal Formats All-window Display HDMI Channel 1024 x 768 @ 60 Hz 1024 x 768 @ 60 Hz 1024 x 768 @ 60 Hz 720/59.94p 1280 x 1024 @ 60 Hz 1280 x 1024 @ 60 Hz 1280 x 1024 @ 60 Hz 720/60p 1600 x 1200 @ 60 Hz...
  • Page 32 Annex Appendix B Monitor Size (Unit: mm)
  • Page 33 Qingdao Hisense Medical Equipment Co., Ltd. Address: North, 3F, Outsourcing Center of Software Park, No. 169, Songling Road, Laoshan District, Qingdao, P.R.China Hisense national customer service hotline: 4009940707 Hisense Group service supervision email: haixinfuwu@hisense.com...
