Hisense LCD Monitor
RSAG2.025.6167SS E Edition
Hisense website:
www.hisense.cn
User Manual
Read the User Guide thoroughly before
using Hisense LCD monitor and keep it
properly for future reference.
HME8C32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HME8C32 and is the answer not in the manual?

Questions and answers

Related Manuals for Hisense HME8C32

Summary of Contents for Hisense HME8C32

  • Page 1 HME8C32 Hisense LCD Monitor User Manual Read the User Guide thoroughly before using Hisense LCD monitor and keep it properly for future reference. RSAG2.025.6167SS E Edition Hisense website: www.hisense.cn...

  • Page 2: Preface

    Read the User Guide thoroughly before using the LCD monitor and keep it properly for future reference. Hisense shall not be liable for any accidents arising from violations of the safety precautions and use instructions of the User Guide.

  • Page 3: Safety Information And Precautions

    The LCD monitor contains hazardous high voltage inside, so do not disassemble it by yourself. This device must be maintained by qualified personnel. If the device has any error, please contact Hisense or our authorized distributors. ...
  • Page 4 Safety Information and Precautions temperature and moved into a room or the room where it is located experiences fast temperature rise. Turn on the monitor only when the condensation disappears. Otherwise, the monitor may be damaged.  Do not cover or block any ventilation holes on the device housing. When the monitor is installed in a closet or other closed environments, keep a certain gap between the monitor and sides of the closet.
  • Page 5 The information in this document is subject to change without notice.  This document provides instructions on correctly installing and using the LCD monitor. Please keep it properly. If it is lost, contact Hisense.  See the monitor certificate label for its production date.

  • Page 6: Table Of Contents

    Contents Preface ..................................I Safety Information and Precautions ........................II Contents .................................. 1 Overview ................................. 2 Features ................................2 Technical Specifications ..........................3 Packing List ..............................4 Monitor Components and Connectors ......................... 5 Monitor Front View ............................5 Monitor Rear View ............................6 Monitor Connector View ..........................

  • Page 7: Overview

    Overview We appreciate that you choose Hisense LCD monitor. This product is a 32-inch LED-backlight color LCD. It is designed for trained medical personnel and can accurately display various images during operation. Features  Real-time picture enhancement (RPE) It optimizes the definition and contrast of dynamic videos frame by frame to improve the reality and presence of the videos.

  • Page 8: Technical Specifications

    Overview Technical Specifications Model HME8C32 Name LCD monitor 32 inches (813 mm) Size Panel type Color LCD panel Backlight Resolution 3840 (H) x 2160 (V) 708 (H) x 399 (V) (mm) Display area Pixel pitch 0.1845 (H) x 0.1845 (V) (mm)

  • Page 9: Packing List

    Note  In case of missing or damaged components, please contact Hisense or our designated distributors in time. Please keep the original package. If you need to send this product back, please use the original packaging. Do not press heavy articles on this product during transportation. Do not place...

  • Page 10: Monitor Components And Connectors

    Monitor Components and Connectors Monitor Front View Power indicator Power switch Breath indicator  Button Description Power switch It is used to turn on or off the monitor. MODE It is used to select different display modes. Select different real-time images to enhance the effect. INPUT1 Select a signal source from the primary channel.

  • Page 11: Monitor Rear View

    Monitor Components and Connectors  Power switch It is used to power on and off the LCD monitor.  Power Indicator Description When the power switch is turned on, the monitor indicator color is green. When the power switch is turned off, the monitor indicator is off.

  • Page 12: Monitor Connector View

    Monitor Components and Connectors Monitor Connector View Equipote ntial power terminal supply Interface Role Connector Description Remarks AC power supply AC power supply Connect to an equipotential Equipotential terminal plug RS485 RS485 debugging interface monitor loopthrough output DVI OUT Single link DVI interface Interface for ISP debugging DEBUG 1, 2...

  • Page 13: Definition Of Monitor Connector Pins

    Monitor Components and Connectors Definition of Monitor Connector Pins  Simple HDMI illustration HDMI Port Definition Table: HDMI pin definition Definition Definition Definition TMDS Data2+ TMDS Data0 Shield SCL (I C Serial Clock for DDC) TMDS Data2 SDA (I C Serial Data Line for TMDS Data0- Shield DDC)
  • Page 14 Monitor Components and Connectors  Simple DP interface illustration DP Port Definition Table: DP pin definition Name Definition Name Definition ML_Lane 3 (n) Lane 3 (negative) 11 Ground Ground 12 ML_Lane 0 (p) Lane 0 (positive) ML_Lane 3 (p) Lane 0 (positive) 13 CONFIG1 Connected to Ground ML_Lane 2 (n) Lane 2 (negative) 14...

  • Page 15: Installation

    Installation Base Installation  To install a base for the monitor, please use the base delivered with the Hisense monitor instead of bases of other brands.  Install the Base  Lay a cloth (or a soft material) on a flat table that can bear enough weight and area to prevent damage to the LCD monitor.

  • Page 16: Vesa Bracket Installation

    Installation Rear view Side view The base can adjust the tilting angle by 15° VESA Bracket Installation  The monitor is suitable for the standard VESA 100 x 100 mm mounting arm frame. CAUTION Use support arms authenticated by VESA. Caution: Use a supporting arm that can bear a weight of at least 12 kg.

  • Page 17: Removing And Installing The Connector Cover Plate

    Installation Removing and Installing the Connector Cover Plate  Dismantling: 1. Rotate the fixing screws counterclockwise to loosen them. 2. Slide the connector cover up and remove it. (The installation process is the opposite.) Cover plate Cover plate...

  • Page 18: Input Port Connection

    Installation Input Port Connection Connect one or more video sources to the corresponding video input interface of the monitor: 1. HDMI: ③ 2. SDI: ④/⑨/⑪/⑬/⑮ ⑥ 3. DVI IN: ⑦ 4. DP: power supply...

  • Page 19: Output Port Connection

    Installation Output Port Connection Connect one or more available video receivers to the corresponding video output interface of the monitor: 1. DVI OUT: ② 2. SDI: ⑤/⑩/⑫/⑭/⑯ power supply AC power supply Power Supply Connection Connect the AC power line delivered with the monitor to the AC power supply interface of the monitor.
  • Page 20 Installation Grounding terminal...

  • Page 21: Operational Instructions And Function Adjustment

    Operational Instructions and Function Adjustment Power-on/off Turn on the power switch: Press the IO power button. When the button is in the I state, the power switch is turned on, and the monitor is powered on. Turn off the power switch: Press the IO power button.
  • Page 22 Operational Instructions and Function Adjustment User4 Compliant with Gamma, with support for custom parameter settings User5 Compliant with Gamma, with support for custom parameter settings User6 Compliant with Gamma, with support for custom parameter settings Adjustment Procedure  Press the MODE button to display the MODE menu.
  • Page 23 Operational Instructions and Function Adjustment Note In Dual mode, if a window has signal, the screen of the window without signal turns black. When the INPUT1 or INPUT2 button is operational, the SWAP, UP, and DOWN buttons are all operational with the green light, and other buttons are locked with the white light. INPUT1 or INPUT2 button cannot be used to select the same signal source.
  • Page 24 Operational Instructions and Function Adjustment Press ▲UP or ▼DOWN to select different options.   Continue to press the SWAP button to cycle through the focuses in the menu list and switch in real time to the function corresponding to the focus. ...

  • Page 25: Main Menu Operation

    Operational Instructions and Function Adjustment Main Menu Operation  Main Menu Operation Description Menu operation method Display Settings 1) Press the MENU button to activate the menu Display Mode Factory window. Backlight 2) Press the ▲ UP or ▼ DOWN button to browse the main Gamma Color Temp.
  • Page 26 Operational Instructions and Function Adjustment Main Menu Item Submenu Submenu and Item Display Settings Preset, DICOM, User1, User2, User3, User4, User5, and Display Mode User6 Backlight 0-100 Gamma1.8, Gamma2.0, Gamma2.2, Gamma2.4, Gamma Gamma2.6, and Yc Color Temp. 6500K, 7500K, 8500K, 9300K, User 1, and User 2 Brightness 0-100 Contrast...

  • Page 27: Detailed Operation Description

    Operational Instructions and Function Adjustment Detailed Operation Description Display Settings In the boot state, display parameters in some modes can be modified for the monitor. Adjustment Procedure Press MENU to call out the User menu. Press the ▲ UP or ▼ DOWN button to select , and press the MENU button to access the Display Settings menu.
  • Page 28 Operational Instructions and Function Adjustment It is used to adjust the brightness of the displayed image. The value range is 0-100.  Contrast It is used to adjust the contrast of the displayed image. The value range is 0-100.  Saturation Adjust the image saturation.
  • Page 29 Operational Instructions and Function Adjustment  Adjust the RPE effect of image display. Adjustment options: Off, Level1, Level2, and Level3. Note  You can use the shortcut button to adjust this function.  Color Gamut Management Adjust the color gamut range. Adjustment options: BT709 and BT2020.
  • Page 30 Operational Instructions and Function Adjustment Option Definition The image is displayed in full screen mode. Full The image may be deformed due to the difference between the image resolution and screen resolution. (120%) Zoom in the image to 120% of the original size. (150%) Zoom in the image to 150% of the original size.
  • Page 31 Operational Instructions and Function Adjustment INPUT1 INPUT2 PIP/PBP Upper Right PIP Position SWAP Select Return  INPUT1 Select a signal source from the primary channel. Adjustment options: Auto, HDMI, SDI(4K), SDI, DP, and DVI Note  For precautions, see Shortcut Menu Operation-Signal Input Selection. ...
  • Page 32 Operational Instructions and Function Adjustment Multi-window Display Mode Selection.  The PIP Position parameter can be adjusted only when you choose Large PIP, Medium PIP, or Small PIP. OSD Settings Adjustment Procedure  Press MENU to call out the User menu. Press ▲UP or ▼DOWN to select ...
  • Page 33 This parameter is used for PQ Demo of some image quality functions for the customer. Adjustment options: On and Off.  Logo Set It is used to set whether to display the Hisense LOGO upon power-on. Adjustment options: Enable and Disable. Note ...
  • Page 34 Operational Instructions and Function Adjustment  Mode Rename It is used to rename the User mode. Note  Only the name of User1 to User6 can be renamed.  Only a name containing eight characters, including English letters, numbers, and spaces is supported.

  • Page 35: Troubleshooting

    Troubleshooting Troubleshooting Before repair, check the following table to see if you can identify the cause of the fault. If the fault persists after you follow the instructions in the User Guide, you can consider repair. Fault Symptom Solution  Check whether the power plug is securely connected to the socket.

  • Page 36: Maintenance Disclaimer

    Maintenance Disclaimer  Qingdao Hisense Medical Equipment Co., Ltd. guarantees that within three years from the date of purchase of this product, if the original purchaser encounters a failure when using the product according to this manual, for example, the equipment is faulty, a component is damaged, or the monitor brightness fails to reach that recommended in the manual, we will repair or replace the product based on our judgment.

  • Page 37: Safety Information

    EMC level (IEC 60601-1-2): Group I Class B Compliance Information Intended Use HME8C32 is a monitor for displaying images from cameras or other systems in medical environments. FCC class B This device conforms to requirements of Federal Communications Commission (FCC). Equipment...
  • Page 38 (1) This equipment cannot cause harmful interferences, (2)and this equipment must be resistant to any interferences, including interferences that may cause unnecessary operations. According to the test result, this equipment complies with the restrictions on Class B digital equipments in Part 15 of the FCC regulations. These restrictions are intended to provide reasonable protection against harmful interference when the device is used in residential installation environments.

  • Page 39: Environmental Protection Information

    Environmental Protection Information Environmental Protection Information  Chinese Mainland RoHS  The LCD monitor meets the environmental protection requirements of the Administrative Measures for Limiting the Use of Hazardous Substances in Electrical and Electronic Products.  During the Environmentally Friendly Use Period (EFUP), there will be no leakage or precipitation of harmful substances that affect your health during use, so you can use it at ease.

  • Page 40: Biological Hazards And Return

    Biological Hazards and Return This device has specific structure, specifications, and manufacturing materials which are easy to wipe and clean, and is suitable for multiple purposes in hospitals and other medical environments where regular cleaning procedures are established. However, to prevent the spread of infectious agents, this device cannot be used in bio-polluted environments.
  • Page 41 This document is protected by copyright. All rights reserved. Without written permission by Hisense, this document or any part of it shall not be copied in any form or in any method, such as images and electronic or mechanical forms, including photocopying, recording, or information storage and retrieval systems.

  • Page 42: Symbol Description

    Symbol Description Symbols on the Device On the device or power supply, you can see the following symbols (this list may not include all symbols): Indicates that the equipment complies with the requirements of the applicable EC directives. This device meets the requirements of Part 15 of FCC regulations (Class A or Class B). This device has been certified by Canadian and American UL regulations.
  • Page 43 Symbol Description Power-on. Power-off. Grounding device. EU authorized representative information. The terminal of the device places different parts of the system at the same potential. Indicates the humidity restriction. Atmospheric pressure limit.

  • Page 44: Annex

    Annex Annex A Allowed Signal Formats All-window Display HDMI SDI(4K) Channel 1024 x 768 @ 60 Hz 1024 x 768 @ 60 Hz 1024 x 768 @ 60 Hz 720/59.94p 4096 x 2160p 30 1280 x 1024 @ 60 Hz 1280 x 1024 @ 60 Hz 1280 x 1024 @ 60 Hz 720/60p 4096 x 2160p 50 1600 x 1200 @ 60 Hz 1600 x 1200 @ 60 Hz 1600 x 1200 @ 60 Hz 720/50p 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1080/59.94i 4096 x 2160p 60...
  • Page 45 Annex Appendix B Monitor Size (Unit: mm)
  • Page 46 Qingdao Hisense Medical Equipment Co., Ltd. Address: North, 3F, Outsourcing Center of Software Park, No. 169, Songling Road, Laoshan District, Qingdao, P.R.China Hisense national customer service hotline: 4009940707 Service Supervisor Email of Hisense Group: haixinfuwu@hisense.com...
