MAINTENANCE
CARING FOR THE FLEXIBLE SHAFT
Prior to shipping the flexible shaft is pre-treated with Picote Felible Shaft Lubri-
cant and the outer casing replaced. Always inspect the condition and when re-
quired apply paraffin oil between the flexible shaft and its outer casing. If neces-
sary remove the shaft from its casing to treat. When the casing has been re-
placed, manually rotate the shaft for even coverage.
FASTENER SCREWS
Replace the fastener screws immediately if you are unable to fully tighten them due to worn out
hex socket heads. Otherwise, a panel could detach from the hub during the cutting operation and
fall into the pipe.
SPARE PARTS
1313001812
Specialized Shaft Connector 18/12
1200100100
Side Grinding Panel with Wedge 100x100 for 6 panel hub
1000200050
HUB Disc 0x50x3 XL (6-panel)
1200150150
Side Grinding Panel 150x150
1000200070
HUB Disc 0x70x3 XL (6-panel)
1200150200
Side Grinding Panel 150x200
1200150250
Side Grinding Panel 150x250
1000200100
HUB Disk 0x100x3 XL (8-panel)
1300215085
Front Drill Head DN100 85mm
1300215130
Front Drill Head DN150 130mm
1300215175
Front Drill Head DN200 175mm
1300215200
Front Drill Head DN225 200mm
900000694
Front Drill Head Blade DN200 4pcs/package
900000716
Front Drill Head Blade DN225 4pcs/package
15
