PICOTE MINI ROLLER Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MINI CLEANER
MINI CLEANER
MINI MILLER 8/16 | MINI MILLER +C 8/16
MINI MILLER 8/16 | MINI MILLER +C 8/16
These instructions are for your personal safety. Always ensure that you
have read and understood these instructions before using the equipment.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MINI ROLLER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PICOTE MINI ROLLER

Summary of Contents for PICOTE MINI ROLLER

  • Page 1 MINI CLEANER MINI CLEANER MINI MILLER 8/16 | MINI MILLER +C 8/16 MINI MILLER 8/16 | MINI MILLER +C 8/16 These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using the equipment. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
  • Page 2 TABLE OF CONTENTS SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE TOPIC PAGE SAFETY INFORMATION & SYMBOLS AVAILABLE SIZES & POWER SOURCES DESCRIPTION ASSEMBLY & USE MAINTENANCE & ACCESSORIES TRAINING TRANSPORT, FASTENING & DISPOSAL WARRANTY POLICY & PROCEDURE To watch practical demonstration videos, or to download an electronic copy of these Instructions, please visit www.picotegroup.com.

  • Page 3: Safety Information & Symbols

    SAFETY INFORMATION SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE This section contains important safety information. Failure to comply could result in serious injury or death. Safety Symbols Safety symbols are used throughout this manual to draw attention to potential hazards. Danger risk of serious injury, follow instructions.

  • Page 4: Available Sizes & Power Sources

    SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE AVAILABLE SIZES & POWER SOURCES The Picote Mini Roller range has been designed for wetting out of short and medium-size Cured-in-Place (CIPP) liners. Available for the rehabilitation of pipe sizes from DN50 (2”) to DN150 (6”).
  • Page 5 DESCRIPTION & GENERAL INFORMATION SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE...
  • Page 6 SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE A properly wet out liner is a key for a successful installation. The use of the Mini Roller ensures that the resin is evenly distributed throughout. The Picote Mini Roller has been developed to impregnate short liners.
  • Page 7 WETTING OUT THE LINER SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Step 2. Attach the power drill onto the power transmission axle. Place liner into Mini Roller. Step 3. Dispense the resin in accordance with the liner manufacturers instructions. To push the bulk resin through the Mini Roller, first open the two Index Plungers (showed below) and lift up the Upper Roller.
  • Page 8 WETTING OUT THE LINER SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Step 4. Once the Upper Roller is opened, move the resin lump through the opening. Step 5. Adjust the opening by turning the adjustment wheel if needed.
  • Page 9 Index Plungers holding the Upper Assembly if needed to make this step easier. Vacuum out the air in the liner. Power up the Mini Roller and carefully spread the resin throughout the liner to fully wet out it. Adjust the roller gap when needed. Change the position of the liner to ensure there are not any dry places left. Be careful not to suck the resin into the vacuum pump.

  • Page 10: Training

    Visually inspect the machine for any signs of damage and replace any damaged parts immediately. Cleaning: Easiest way to keep the Picote Mini Roller operational is to keep it clean. Wipe away any drops of resin from the machine while still wet. Immediately replace broken parts with Picote Original replacement parts.

  • Page 11: Warranty Policy & Procedure

    SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with, and substantially conform to their published specifications when shipped or otherwise...
  • Page 12 Please Contact: Your Reseller / Salesperson or Picote www.picotegroup.com Production & R&D International Offices Technical Support Pienteollisuustie 24 Finland. United Kingdom. USA. support@picotesolutions.com 06450 Porvoo, Finland support@picotesolutions.com E-Learning Claims Authorised Resellers: Free Connection Collar 2.0 - Equipment claims@picotesolutions.com www.picotesgroup.com/resellers 101 E-learning course is available at:...

This manual is also suitable for:
