MINI CLEANER
BATTERY MINI CLEANER 8/16
BATTERY MINI CLEANER 8/16 | BATTERY MINI CLEANER +C 8/16
MINI MILLER 8/16 | MINI MILLER +C 8/16
OPERATION & SAFETY MANUAL
These instructions are for your personal safety. Always ensure that you
have read and understood these instructions before using the machinery.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PICOTE BATTERY MINI CLEANER 8
Summary of Contents for PICOTE BATTERY MINI CLEANER 8
- Page 1 MINI CLEANER BATTERY MINI CLEANER 8/16 BATTERY MINI CLEANER 8/16 | BATTERY MINI CLEANER +C 8/16 MINI MILLER 8/16 | MINI MILLER +C 8/16 OPERATION & SAFETY MANUAL These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using the machinery.
-
Page 2: Table Of Contents
To watch practical demonstration videos, take a course, or to download an electronic copy of these Instructions, please visit www.picoteinstitute.com. Please note that videos and courses are not intended as a replacement or alternative to this operating and safety manual, but only as an additional learning tool. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 3: Safety Information
Suitable respirator to prevent any dust or fumes being inhaled or consumed, which could cause occupational asthma or dermatitis. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 4: General Machine Safety Information
Do not stand on the machine. 12. Only use this machine with the accessories and spare parts offered by the Picote Solutions. Accessories and spare parts should only be used in the manner intended and as described by Picote Solutions. -
Page 5: Environment, Transport, Storage & Disposal
Outer casing of the shaft and the camera plastic supports can be disposed of as plastic waste. Always follow local waste handling rules and regulations. Recycle Li-ion batteries according to local regulations. Do not dispose of in fire! Do not puncture! Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 6: General Information
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE When in use always lay the machine down horizontally on the ground. When not in use some non-hazardous Picote Flexible Shaft Lubricant might leak from the hand guard. Picote Solutions Oy Ltd... -
Page 7: Technical Data
1. Cleaning and unblocking pipes, drains and sewers by grinding. 2. Descaling pipes. 3. Opening lateral connections. 4. Internal pipe coating using the Picote Brush Coating™ System and the Mini Coating Pump. AVAILABLE TOOLING Always follow the Picote Solutions instructions when installing and using the machine with accessories. -
Page 8: Packages Included
Side Grinding Panel 30x50 DN40 (1½") Package 1381084040 Cleaning Chain DN40 (1½") 1300212025 Front Drill Head 25mm for DN50 (2") pipes Check out the overall list of the available tools and spare parts from page 21. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 9: Voltage & Power Supply
The machine is operated by foot pedal (Operator Presence Control or ‘OPC’). When the control is not held down, the machine stops. Never place any kind of object on the pedal in place of a foot (such as a brick). Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 10: Noise Levels, Vibrations & Emissions
Hand vibration levels depend on the distance from the tool head to the user and working conditions. The vibration levels detailed below have been measured at the Picote training facilities in Finland. Vibration has been determined according to ISO-5349 and EU-directive 2002/44/EG. -
Page 11: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE We Picote Solutions Oy Ltd as the responsible manufacturer, declare that the following Picote Solutions Oy Ltd drain cleaning machine: Battery Mini Cleaner Model No: 8/16 Battery Mini Cleaner +C... -
Page 12: Operating Instructions
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Before operation: - Before installing Picote tools, always make sure that the machine is fully turned off and the battery charger unplugged. - Always round off the sharp edges of the shaft to avoid cuts and to make it easier to insert the shaft into the tool or for a leader to be used. -
Page 13: Attaching Tools
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE ATTACHING TOOLS TIGHTENING THE SET SCREWS When you add a tool always tighten the screws starting from the screw furthest away from the end of the flexible shaft (where applicable). Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 14: Rotation Speed Dial
The speed dial can be found on the control box (see below image). Set the speed by rotating the knob. Check the corresponding rotation speed from table below. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 15: Navigating Dn32-Dn50 / 1¼" -2" Knuckle Bends
Move the tool constantly back and forth in the pipe. The special spring outer casing in the Battery Mini Cleaner and Battery Mini Cleaner +C can melt because of the friction heat created if the tooling is kept in the same place for long periods of time. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 16: Navigating Through Dn50/2" P-Traps
Step 2. Move tool constantly back and forth in the pipe. The special spring outer casing in the Battery Mini Cleaner/ Battery Mini Cleaner +C can melt because of friction heat created by tooling being kept in the same place over long periods of time. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 17: Maintenance Programme & Warranty Periods
I: Inspect, fix or replace if needed. P: Perform, replace if needed. R: Replace WARRANTY PERIODS Picote Solutions Oy Ltd grants limited warranty for certain machines, equipment & components. Read more detailed information on page 31 (Picote Warranty Policy and Procedure). 3 months 6 months... -
Page 18: Maintenance
Do not pour or spray water on the machine! Use a damp cloth with mild soap solution to clean the surfaces. REPLACING THE FLEXIBLE SHAFT To replace the flexible shaft on the Battery Mini Cleaner or Battery Mini Cleaner +C pull out the shaft from the reel and remove hand guard. Picote Solutions Oy Ltd www.picoteinstitute.com... - Page 19 SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Next loosen the set screws on the shaft socket. Pull out the shaft from the socket. Unscrew the strain relief from the outer casing. Remove the shaft completely. Reassemble in reverse order. Picote Solutions Oy Ltd www.picoteinstitute.com...
-
Page 20: Servicing Flexible Shaft
SERVICING THE FLEXIBLE SHAFT & ITS OUTER CASING The flexible shaft is pre-treated with Picote Flexible Shaft Lubricant and the casing replaced prior to shipping. Always inspect the condition of the shaft and its outer casing regularly. Also, inspect at least once a week that the shaft is well attached under the hand guard at the machine end. -
Page 21: Accessories & Spare Parts
ACCESSORIES & SPARE PARTS SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Only use Picote Solutions accessories and attachments with the machine described in this operation manual. The use of other accessories or attachments could present a risk of injury or death. - Page 22 ACCESSORIES & SPARE PARTS SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Only use Picote Solutions accessories and attachments with the machine described in this operations manual. The use of other accessories or attachments could present a risk of injury or death. The accessories or attachments should only be used in the proper and intended manner, and always follow Picote Solutions instructions.
-
Page 23: Practical Tips & Safety Advice
PRACTICAL TIPS & SAFETY ADVICE SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury. - Page 24 PRACTICAL TIPS & SAFETY ADVICE SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury.
-
Page 25: Mini Cleaner +C
1. Tool for inspecting pipes before, during and after work (Navigates through DN50 (2”) bends and P-traps) 2. Working inside pipes; the CCTV is fitted with an integrated Sonde (512hz) Always follow Picote Solutions instructions when installing and using the machine with accessories. Picote Solutions Oy Ltd... -
Page 26: Mini Cleaner +C: Camera Kit Instructions
SD card into SD card slot. Connect DVR to camera reel with included cable SD-Card STARTING & USING THE MACHINE DVR Icons: SD Card Battery level Image Reverse Image Reverse & Mirror Image Mirror Timestamp LED Brightness Record Meter Counter Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 27: Mini Cleaner +C: Camera Function Guide
3. Playback menu Press to enter playback mode to browse through the files Press to confirm the selection and preview media files to preview previous/next file Press to playback video Press to enter the play settings Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 28: Mini Cleaner +C: Technical Data
30 m or 100 ft Meter Counter Single Charge Work Time 6 Hours Charging time 8 Hours Language English, German, French, Spanish, Italian, Chinese, Japanese, Russian, Portuguese Tool Box Size 380x260x150 mm (15x10x6 in.)(L x W x H) Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 29: Mini Cleaner +C: Spare Parts
SPARE PARTS 900001760 Battery Mini Cleaner +C Camera Head 900001688 +C Charger EU 900001691 +C Charger US 900001689 +C Charger UK 900001805 Battery Mini Cleaner +C Camera Rod 900001758 Electric cable +C 900001755 Monitoring Box +C Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 30: Troubleshooting Flowchart
Change shaft if necessary. Did it help? Battery Mini Cleaner is OK! If there is problem that you cannot resolve with this manual, please consult your Picote Reseller or Picote Solutions at claims@picotesolutions.com. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 31: Warranty Policy & Procedure
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with, and substantially conform to their published specifications when shipped or otherwise... - Page 32 Revision number: Rev. 1 Date: MAY 2021 Author: Ville Hukkanen Please Contact: Accepted: Dawn Greig 14.05.21 Your Reseller / Salesperson or Picote www.picotesolutions.com Production & R&D International Offices Technical Support support@picotesolutions.com Finland. United Kingdom. USA. Pienteollisuustie 24 06450 Porvoo, Finland Claims support@picotesolutions.com...
