PICOTE DN150 Operating & Safety Manual

Hide thumbs Also See for DN150:

Advertisement

Quick Links

Download this manual
Operating & Safety Manual
Smart Cutter DN150-DN225 / 6"-9" & DN250-DN300/ 10"-12"
for 18mm/¾" Shaft
These instructions are for your personal safety. Always ensure that you
have read and understood these instructions before using any tools of
the Smart Cutter range. Please also read and understand the Maxi Miller
Power Plus manual before using the Smart Cutter Tool.
We now have resellers in the U.S., Europe & Australasia.
Locate your reseller at picotesolutions.com
I
N
S
T
R
U
C
T
I
O
N
S

Advertisement

loading
Need help?

Need help?

Do you have a question about the DN150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PICOTE DN150

Summary of Contents for PICOTE DN150

  • Page 1 Operating & Safety Manual Smart Cutter DN150-DN225 / 6”-9” & DN250-DN300/ 10”-12” for 18mm/¾” Shaft These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using any tools of the Smart Cutter range. Please also read and understand the Maxi Miller Power Plus manual before using the Smart Cutter Tool.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TOPIC PAGE/S SAFETY INFORMATION & SYMBOLS AVAILABLE SIZES & POWER SOURCES BILL OF MATERIALS ASSEMBLY USING THE SMART CUTTER MAINTENANCE & SPARE PARTS PRACTICAL TIPS & SAFETY ADVICE WARRANTY POLICY & PROCEDURE To watch practical demonstration videos, or to download an electronic copy of these in- structions, please visit www.picotesolutions.com.
  • Page 3 SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE SAFETY INFORMATION This section contains important safety information. Failure to comply could result in serious injury or death. Safety Symbols Safety symbols are used throughout this manual to draw attention to potential hazards. Danger risk of serious injury or death by electrocution, follow instructions Danger risk of serious injury or death by electrocution, follow instructions Danger risk of serious injury, follow instructions...
  • Page 4 Improper use can lead to severe injury. The user manual defines proper use of this equipment. Contact Picote if you do not understand any procedure or operation concerning this equipment or the user manual.

  • Page 5: Available Sizes & Power Sources

    CHOOSING YOUR POWER SOURCE The Smart Cutter for the 18mm/¾” diameter shaft has been designed for and can ONLY be operated with the Picote Maxi Miller Power+ machine. The machine should only be connected only to a 380-480 Volt (3-phase) power supp- ly.

  • Page 6: Bill Of Materials

    BILL OF MATERIALS: Smart Cutter DN100/4” The Hub Disc can be changed with the Crusher or Drill Head.
  • Page 7 BILL OF MATERIALS: Smart Cutter DN150/6” The Hub Disc can be changed with the Crusher or Drill Head.
  • Page 8 BILL OF MATERIALS: Smart Cutter DN200-DN225/8”-9” The Hub Disc can be changed with the Crusher or Drill Head. Side grinding panels can be changed to 150x250 for DN250-DN300 pipes.
  • Page 9 BILL OF MATERIALS - DN150/6” Smart Crusher Head...
  • Page 10 BILL OF MATERIALS - DN200/8” Drill Head...

  • Page 11: Assembly

    DN100, DN150 & DN200-DN300/4”, 6” & 8”-12” SMART CUTTER ASSEMBLY & USE First, make sure you have all the required parts. Please see photo parts’ lists on page 5. Please read safety information on page 3 before assembly and use.
  • Page 12 Smart Cutter DN150/6” Assembly Instructions Recommended: Loctite 542 Thread Sealant Step 1. Slide the side grinding panels into their slots. Step 2. Add Hub Disc, Spring Washers and Allen Bolts (M8x30 “light”) and tighten the bolts. Use Loctite 542.
  • Page 13 Smart Cutter DN200-DN300/8”-12” Assembly Instructions Recommended: Loctite 542 Thread Sealant Step 1. Slide the side grinding panels into their slots. Step 2. Add Hub Disc, Spring Washers and Allen Bolts (M8x30 “light”) and tighten the bolts. Use Loctite 542.
  • Page 14 Assembly Instructions—Smart Crasher heads Step 1. Insert the lock washers and hex bolts into their slots. Recommended: Loctite 542 Thread Sealant Step 2. Place the Smart Crusher Blades into their slots. Pay close attention to align- ment as seen on next page.
  • Page 15 Assembly Instructions—Smart Crusher Heads Step 3. Place every second blade in alternative slots of the body. The Smart Crusher can only operate at maximum diameter when the bla- des are inserted correctly. The two opposite blades need to be closer to the centre.
  • Page 16 Assembly Instructions—Smart Crusher Heads Step 4. Insert the mounting bolts and nuts. Tighten bolts. Lock nuts must be used! Recommended: Loctite 542 Thread Sealant Step 5. Place the rest of bolts and locking nuts into their place as per step 4.
  • Page 17 Assembly Instructions—Drill Heads DN200/8” & DN225/9” Step 1. Insert the blades into their slots. Step 2. Place the bolts and nuts in position and tighten them. Locking nuts must be used! Recommended: use Loctite 542 Thread Sealant.
  • Page 18 Assembly Instructions—Drill Heads DN200/8” & DN225/9” Step 3. Insert the other bolts and nuts into their slots. Step 4. Place the Allen Bolts (M8) and locking washers into their slots.

  • Page 19: Using The Smart Cutter

    Using the Smart Cutter NEVER SWITCH ON THE SMART CUTTER OUTSIDE OF THE PIPE! The cutting head needs to fit completely inside the pipe before turning power on and using the tool. Failure to comply could lead to serious injury or death. Before Starting Work Select the correct size tooling and drill head for your job.
  • Page 20 Using the Smart Cutter After Use WARNING: Turn the power off and isolate the supply before you remove the tool from the pipe. There is a risk of serious injury or death! The tool can be very hot. Carefully take the tool out from the pipe.

  • Page 21: Maintenance & Spare Parts

    MAINTENANCE CARING FOR THE FLEXIBLE SHAFT Prior to shipping the flexible shaft is pre-treated with Picote Felible Shaft Lubri- cant and the outer casing replaced. Always inspect the condition and when re- quired apply paraffin oil between the flexible shaft and its outer casing. If neces- sary remove the shaft from its casing to treat.
  • Page 22 3570032016 MAXI MILLER POWER PLUS 18/18 400V In case there is problem that you cannot solve using this manual, please consult your reseller or the Picote Solutions. TRAINING For information about product training and support contact Picote Solutions or your authorized Picote reseller.

  • Page 23: Practical Tips & Safety Advice

    PRACTICAL TIPS & SAFETY ADVICE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury. CUTTING THE FLEXIBLE SHAFT Before use always inspect the flexible shaft. If...

  • Page 24: Warranty Policy & Procedure

    WARRANTY POLICY AND PROCEDURE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with and substantially conform to their published specifications when shipped or otherwise delivered to the End User and for a period of one (1) year, except electric motors for which the warranty...
  • Page 25 Revision number: Rev. 1 Author: Mikko Långvik Accepted: For support support@picotesolutions.com For accessories Your reseller or Manufacturer sales@picotesolutions.com Picote Solutions Oy Ltd +44 (0)7585 116508 Raudoittajantie 4 +1 219 440 1404 06450 Porvoo Finland Technical Support: +1 706 436-1892 www.picotesolutions.com...
