Operating & Safety Manual
Twister+ DN150, DN 200 & DN225 / 6", 8" & 9" for 18mm/¾" Shaft
These instructions are for your personal safety. Always ensure that you
have read and understood these instructions before using any tools of
the Twister+ range. Please also read and understand the Maxi Miller Pow-
er+ manual before using the Twister+ tool.
We now have resellers in the U.S., Europe & Australasia.
Locate your reseller at picotesolutions.com
I
N
S
T
R
U
C
T
I
O
N
S

Advertisement

loading
Need help?

Need help?

Do you have a question about the Twister+ DN150 and is the answer not in the manual?

Questions and answers

Related Manuals for PICOTE Twister+ DN150

Summary of Contents for PICOTE Twister+ DN150

  • Page 1 Operating & Safety Manual Twister+ DN150, DN 200 & DN225 / 6”, 8” & 9” for 18mm/¾” Shaft These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using any tools of the Twister+ range.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TOPIC PAGE/S SAFETY INFORMATION & SYMBOLS AVAILABLE SIZES & POWER SOURCES BILL OF MATERIALS ASSEMBLY & USE PRACTICAL TIPS & SAFETY ADVICE MAINTENANCE & SPARE PARTS WARRANTY POLICY & PROCEDURE To watch practical demonstration videos, or to download an electronic copy of these In- structions, please visit www.picotesolutions.com.

  • Page 3: Safety Information & Symbols

    SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE SAFETY INFORMATION This section contains important safety information. Failure to comply could result in serious injury or death. Safety Symbols Safety symbols are used throughout this manual to draw attention to potential hazards. Danger risk of serious injury or death by electrocution, follow instructions Danger risk of serious injury or death by electrocution, follow instructions Danger risk of serious injury, follow instructions...
  • Page 4 Improper use can lead to severe injury. The user manual defines proper use of this equipment. Contact Picote if you do not understand any procedure or operation concerning this equipment or the user manual.
  • Page 5 Using lidded boxes which are fastened and stored on the bottom of a van is recommen- ded. Never transport machine with tool attached to the shaft. If using pick-up or trailor to transport Picote machine or tools, cover the products to protect them from raining water and dust. STORAGE It is recommended that tools are stored indoors protected from rain and sunlight and in constant ambient temperature.

  • Page 6: Available Sizes & Power Sources

    CHOOSING YOUR POWER SOURCE The Twister+, with the 18mm/¾” diameter shaft, has been designed for and can ONLY be operated with the Picote Maxi Miller Power+ machine. The machine should only be connected to a 380-480 Volt (3-phase) power supply.

  • Page 7: Bill Of Materials

    BILL OF MATERIALS DN 150/6”...
  • Page 8 BILL OF MATERIALS DN200/8”...
  • Page 9 BILL OF MATERIALS DN225/9”...
  • Page 10 BILL OF MATERIALS - Smart Crusher Head...
  • Page 11 BILL OF MATERIALS - Drill head DN200...

  • Page 12: Assembly & Use

    First, make sure you have all the required parts. Please see photo parts’ lists on page 5-8. Please read safety information on page 3 before assembly and use. Twister DN150/6” Twister DN200/8” Twister DN225/9” 1230130150 Twister+ DN150/6” for 18mm/¾” Shaft 1230130200 Twister+ DN200/8” for 18mm/¾” Shaft 1230130225 Twister+ DN225/9” for 18mm/¾” Shaft...
  • Page 13 Assembly Instructions—the Smart Crusher Heads Step 1. Insert the lock washers and hex bolts into their slots. Recommended: Loctite 542 Thread Sealant Step 2. Place the Smart Crusher blades into their slots. Pay close attention to alignment as seen on the next page.
  • Page 14 Smart Crusher Heads Step 3. Place every second blade in alternative slots of the body. The Smart Crusher can only operate at maximum diameter when the bla- des are inserted correctly. The two opposite blades need to be closer to the centre.
  • Page 15 Smart Crusher Heads Step 4. Insert the mounting bolts and nuts. Tighten bolts. Locking nuts must be used! Recommended: Loctite 542 Step 5. Place the rest of bolts and locking nuts into their place as per step 4.
  • Page 16 Drill Heads DN200 & DN225/8” & 9” Step 1. Insert the blades into their slots. Step 2. Place the bolts and nuts in position and tighten them. Locking nuts must be used! Recommended: use Loctite 542 Thread Sealant.
  • Page 17 Drill heads DN200 & DN225/8” & 9” Step 3. Insert the other bolts and nuts into their slots. Step 4. Place the Allen Bolts (M8) and locking washers into their slots.
  • Page 18 Attaching the Drill Head to the Twister+ body.
  • Page 19 Using the Twister+ products Before starting work Select the correct size tooling and drill head for your job. Ensure water is flowing in the pipe or the vacuum extraction is ready (dry cleaning). Ventilate the working area properly. Ensure that all me- tallic drain pipes are grounded/earthed.
  • Page 20 Using Twister products After use WARNING: Turn the power off and isolate the supply before you remove the tool from the pipe. There is a risk of serious injury or death! The tool can be very hot. Carefully take the tool out from the pipe Check out the condition of the tooling and shaft.
  • Page 21 MAINTENANCE CARING FOR THE FLEXIBLE SHAFT Prior to shipping the flexible shaft is pre-treated with paraffin oil and the outer casing replaced. Always inspect the condition and when required apply paraffin oil between the flexible shaft and its outer casing. If necessary remove the shaft from its casing to treat.
  • Page 22 Maxi Power+ spare shaft 20.5m 1312021180011 Maxi Power+ extension shaft 11m 93212520180SB Sleeve for 18mm outer casing MILLER 3570032016 MAXI MILLER POWER PLUS 18/18 400V TRAINING For information about product training and support contact Picote Solutions or your authorized Picote reseller.

  • Page 23: Practical Tips & Safety Advice

    PRACTICAL TIPS & SAFETY ADVICE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury. CUTTING THE FLEXIBLE SHAFT Always inspect the flexible shaft before each use.

  • Page 24: Warranty Policy & Procedure

    WARRANTY POLICY AND PROCEDURE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with and substantially conform to their published specifications when shipped or otherwise delivered to the End User and for a period of one (1) year, except electric motors for which the warranty...
  • Page 25 Date: 6 Nov. 2019 Date: 6 Nov.. 2019 Rev. 1 Author: Mikko Langvik Please Contact: Your Reseller / Salesperson or Picote Accepted: Dawn Greig www.picotesolutions.com International Offices Production & R&D Technical Support Finland. United Kingdom. USA. Jake Saltzman Raudoittajantie 4...
