PICOTE Smart Cutter DN100 Operating & Safety Manual page 10

DN100, DN150 & DN200-DN300 / 4", 6" & 8"-12" SMART CUT-
TM
TER ASSEMBLY & USE
First, make sure you have all the required parts. Please see photo parts' lists on page 5.
TM
Smart Cutter DN100/4"
TM
Smart Cutter DN200-DN300/8"-12"
1001250100A
1001870150A
1021800200
Smart Cutter
TM
Smart Cutter DN100 12mm, 6-panel hub, aluminum
TM
Smart Cutter DN150 hub 18mm, 6-panel, aluminum
TM
Smart Cutter DN200-225 18mm, 8-panel, aluminum
Please read safety information on
page 3 before assembly and use.
TM
DN150/6"
