DPC-2 CONTROL KIT Manual #50-06

Optional Accessories

The following accessories are available from ITW Dynatec for use with the DPC-2
Control Kit:
Mini Reflective Photo Sensor Assembly, 2ms Response (6' cord)
Reflective Photo Sensor Assembly, 1ms Response (6' cord)
Fiber Optic Photo Sensor Assembly (6' cord)
Foot Switch Assembly (10' cord)
Trigger/Encoder Extension Cable, 10' (may be used with any of the above
photo sensors, foot switch or encoder assembly)
Encoder Assembly, 1200 PPR
Encoder/ Wheel/ Bracket Assembly, includes 15' cable
Encoder/ Wheel/ Bracket Assembly with machine mount bracketry
Adhesive Supply Control Cable (used with "S" and "M" series ASU's or
other melt units that have built in isolation of the 0 to 10 VDC signal and
with Pressure Transducer Assembly, 105754).
0 to 10 Volt Adhesive Supply Control Kit (includes a signal isolator board
and 10' cable). Used with hot melt units that do not possess an isolated 0 to
10 volt control circuit (Dynatec ASU's that pre-date the "S" and "M" series).
Pressure Transducer Assembly, used for control of fluid regulator in cold
glue systems or as input to hot melt piston-pump systems. PN 106609 must
also be ordered.
Sealing Cap, 4-Pin Receptacle (seals unused 4-pin connectors for IP54
integrity)
Sealing Cap, 9-Pin Receptacle (seals unused 9-pin connectors for IP54
integrity)
Single Head Cord, 10' (allows connection of a single applicator to a drive
output, used primarily with cold glue applicators)
Solenoid Cord, RCA(M)/Unterminated, 10' (used with 106006)
Solenoid Cord, RCA(M)/RCA(F), 10' (used with 106006)
Description
Page 2 - 3
Revised 5/09
Part Number
L21746
L21701
L21745
106114
L21747
109076
112433
112435
106609
L21749
105754
106116
106023
106006
340-010-XA
340-010-AA
