The DPC-2 requires an encoder (speed) and sensor (trigger) input to function properly.
The trigger input senses the product to be glued and initiates a countdown within the
Control Unit based upon the programmed pattern. The encoder tracks the machine speed
assuring consistent glue pattern length as machine speed varies. A Servo output is also
available that provides the necessary signals to automatically adjust adhesive output
pressure as speed varies. This helps to ensure consistent glue volume as machine speed is
modified.
A key-actuated system lock is provided on the Controller's front panel. This lock prevents
any unauthorized change to the programming when activated.

Specifications

Operating Temperature:
Storage Temperature:
Maximum Switching Rate:
Number Channels (Drives):
Program Storage Capacity:
Number Events per Program
Maximum Power Output:
Applicator Overload Protection:
Maximum Speed:
Number Encoder Inputs:
Encoder Scaling:
Number Trigger Inputs:
Minimum Trigger Duration:
Servo Output:
Holding Voltage:
Over-Voltage:
Over-Voltage Duration:
Input Voltage:
Input Power:
Power-on Contact Rating:

How to Use this Manual

The following typographic conventions are used throughout this manual:
ALL CAPITALS: Parameter, Button and Knob titles displayed on the DPC-2 Control
Unit Display Panel
Bold: Information found on the DPC-2 Control Unit's LED Display
32 to 113 degrees F (0 to 45 degrees C), 0 to 90% RH, non-condensing
-14 to 140 degrees F (-10 to 60 degees C), 0 to 90% RH, non-condensing
500 cycles per second
2 independently controlled
4
4 (4 delays and 4 glues)
26 Watts, current limited at 1.25 amps per channel
Electronic Sensing
1,500 fpm
1
100 pulses per inch
1
1ms
0 to 10 VDC, 0 to 20 mA, or 4 to 20 mA (operator selectable)
16 VDC
48 VDC
0 to 25.5ms, operator selectable
115 or 230 VAC ± 10%, single phase
60 Watts
10A resistive, 7.5A inductive @ 250 VAC
