5.3.3 SIP Configuration

Click Basic> SIP tab to open the SIP configuration interface.
Figure 5-4 SIP Configuration Interace
Table 5-4 SIP Configuration Parameters
Name
Signaling port
Register server
Proxy server
Backup proxy server
Primary server
heartbeat detect
OPTIONS request
period
User name
Password
Registration period
5 -6
Description
Configure the UDP port for transmitting and receiving SIP messages, with its default value
5060.
If the TGWXE1 is connected directly to the Internet, it's recommended to change the default
port value to prevent hacker attacks.
Note: The signaling port number can be set in the range of 1-9999, but cannot conflict with the
other port numbers used by the equipment.
Configure the address and port number of SIP register server, and the address and port number
are separated by ":". The register server address can be an IP address or a domain name. For
example: 201.30.170.38:5060, register.com:5060. When a domain name is used, it is required to
activate DNS service and configure DNS server parameters on the page of configuring network
parameters.
Configure the IP address and port number of SIP proxy server, and the address and port number
are separated by ":". The proxy server address can be set to an IP address or a domain name.
When a domain name is used, it is required to activate DNS service and configure DNS server
parameters on the page of configuring network parameters. Examples of complete and effective
configuration: 201.30.170.38:5060, softswitch.com:5060.
Configure the IP address and port number of backup proxy server.
Selectthe check box to enable and set the parameter OPTIONS request period, the device
detects the failure condition of the proxy server (primary server) by periodically sending
OPTIONS request to it.
If the gateway does not receive the response to OPTIONS request, it will failover to the backup
proxy server.
After failover to the backup server, the gateway will still send OPTIONS to the primary server
all the same. It switches back to the primary server once the response to the OPTIONS request
is received.
Set the period of sending OPTIONS request to the primary server.
Configure the user name as part of the account for registration.
Password as part of account information is used for authentication by platform.
Valid time of SIP re-registration in second. Its default value 3600.
