Figure 5-25 System Startup Interface
5.7.5 Manage Log
Click the label of Logs > Manage Log to open this interface. Log files can be downloaded through this
interface.
Figure 5-26 Manage Log Interface
Table 5-23 Manage Log Parameters
Name
Log level
System log server
Local log port
Log server
Procedure for downloading the log:
Step1 Click Download, the gateway begins to assemble the logs.
Step2 After a few seconds, the interface of log saving will appear.
5 -3 4
Description
Select the log file level of gateway, default is 4. The higher the level goes, the more details the
log file will be.
Note: log level should be set to be 4 or lower when gateway is used in normal operation,
avoiding influencing the system performance.
Set the IP address of system log server.
The port for sending system logs.
IP address of debugging log server.
