TGWxE1 G a te w a y S e rie s U s e r M a n u a l

5.2 Buttons Used on Gateway Management Interface

Submit buttonsare at the bottom of the configuration screens. It is used to submit configuration
information. Users click Submit button after completion of parameter configuration on a page. A success
prompt will appearif configuration information is accepted by the system; if a "The configuration takes
effect after the system is restarted"dialog box appears, it means that the parameters are valid only after a
system restart; it is recommended that userspress the Restartbutton on the Toolpageto enablethe
configuration after changingall parameters to be modified.

5.3 Basic Configuration

5.3.1 Network Configuration

Click Basic > Network tab to open the configuration interface.
Figure 5-2 Network Configuration Interface
Table 5-1 Network Configuration Interface
Name
Host name
MAC address
5 -2
Description
This is the equipment name of a configuration gateway. The default value is TGWXE1. Users
can set a different name for each gateway to distinguish from each other according to the
deployment plan.
A host name can be a maximum of 48 characters, either letters (A-Z or a-z), numbers (0-9) and
minus sign (-). It may not be null or space and it must start with a letter.
Display the MAC address of gateway.
