TGWxE1 G a te w a y S e rie s U s e r M a n u a l
Table 1-3 Pinouts of Ethernet Ports
RJ45 Pin-out
Description
Table 1-4 Pinouts of T1/E1 Module
RJ45 Pin-out
Description
Figure 1-2 Back Panel
Table 1-5 Description of Back Panel
Description
#
①
AC power socket, 100-240 VAC voltage input.
②
Ground pole.
1.3.2 CON Port
The TGWXE1 provides one configuration interface (CON) of RJ45 interface for local management and
debugging.
Table 1-6 Standard Table for Lead Wire of Pin at Configuration Port (CON)
Pin number of RJ45 plug
Description
Pairing connection with DB9
female plug
Pairing connection with DB25
male plug
The configured interface is connected to the RS232 port on the PC, allowing the PC to establish the
connection with the TGWXE1 by configuring a terminal emulator. The configured interface of TGWXE1
is in a 3-wire configuration: one TXD (data transmission terminal), one RXD (data reception terminal),
and one GND (ground terminal).
Please use a RJ45 to RS232 serial cable as shown in Figure 1 -3 for connecting the CON port on
TGWXE1 side and the RS232 port on PC side. If the connection is established between TGWXE1 and
the mobile PC with no RS232 ports, please use the cable together with USB to RS232 converter cable as
1 -4
1
2
TX+
TX-
1
2
3
RXRing
RXTip
NC
1
2
NC
NC
3
RX+
4
5
TXRing
TXTip
3
4
5
TXD
GND
GND
2
5
3
7
6
RX-
6
7
8
NC
NC
NC
6
7
RXD
NC
3
2
Ta d ira n Te le c o m
8
NC
