TGWxE1 G a te w a y S e rie s U s e r M a n u a l
shown in Figure 1 -4 .
Figure 1-3 RJ45 to RS232 serial cable
Table 1-7 Attributes of CON Port
Attributes
Connector
Interface count
Interface standard
Baud rate
Data bit
Parity
Stop bit
Traffic control

1.3.3 Specifications

Table 1-8 Specifications
Item
Basic
Ethernet
E1/T1Interface
SD Interface
CON Interface
System Memory
System Flash
Processor
DSP
Power
Power Consumption
Size (H×W×D)
Weight
Environment Requirements
Operating Environment
Ta d ira n Te c h n o lo g ie s , In c .
Description
RJ45
1
RS232
115200
8
No
1
No
Description
RJ45, 4×10/100/1000M Base-T, self-adaptive
4, 120 simultaneous VoIP calls
1
RJ45
256MB
32MB
TI AM3352
TI C5509
~100-240V, 50/60Hz, 1A
18 W (M a x )
44×440×300 mm,1Uformfactor
net weight:3 kg gross weight(with box):5 kg
0 to 40℃, Non-Condensing Humidity 10 to 95%
Figure 1-4 USB to RS232 converter cable
1 -5
