Processing Mode
CODEC
RELAY
SEND180
SEND183
HIDE
Table 5-11 Routing Destination
Destination
ROUTE NONE
ROUTE ISDN
ROUTE IP
5.5.2 Application Examples of Routing Table
Application requirements
Ta d ira n Te le c o m
Description and Example
Designate the use of codec, such as PCMU/20/16, where PCMU denotes G.711, /20 denotes
RTP package interval of 20 milliseconds, and /16 denotes echo cancellation with 16
milliseconds window. PCMU/20/0 should be used if echo cancellation is not required to
activate.
Example:
IP 6120 CODEC
PCMU/20/16 codec will be applied to calls from IP with called party number starting with
6120.
Insert prefix of called party number when calling out. The inserted prefix number follows
behind REPLAY.
Example:
IP 010 RELAY
For calls from IP with called party number starting with 010, digit stream 17909 will be
outpulsed before the original called party number is being sending out.
Force send 180 on ring back
Example: IP CPN2 SEND180
CPN number start with 2, always send 180 on ring back.
Force send 183 on ring back.
Example: IP CPN3 SEND183
CPN number start with 3, always send 183 on ring back (voice cut through).
Calling party number presentation.
Example:
IP[61.2.44.53:5060] CPNX HIDE
Any call from 61.2.44.53:5060, calling party number presentation restriction is applied.
Note: The hiding of the calling party number can be enabled only when the operator can
provide the corresponding support as well.
Description and Example
Calling barring.
Example:
IP CPN[1,3-5] ROUTE
Bar all calls from IP, of which the calling numbers start with 1, 3, 4, 5.
Route a call to ISDN.
IP 8621 ROUTE
IP CPN8620 ROUTE
call has 8621 prefix, route to ISDN span 1
calling party number started with 8620, route to ISDN span 2
Route a call to the IP platform.
Example:
FXS 021 ROUTE IP 228.167.22.34:5060
228.167.22.34:5060 is the IP address of the platform.
ISDN 021 ROUTE
ISDN 020 ROUTE
Indicates that the call from the PSTN, with the called party number starting with 021 will be sent
to the platform with the IP address of 228.167.22.34; the call with the called party number
starting with 020 will be sent to the platform with the IP address of 61.234.67.89.
PCMU/20/16
17909
NONE
ISDN 1
ISDN 2
IP 228.167.22.34:5060
IP 61.234.67.89:5060
