This NVR supports two 3.5" or 2.5" SATA hard disk drives.
CAUTION: DO NOT install or remove the hard disk drive while the device power is turned ON.
The installation procedure of 3.5" and 2.5" are slightly different. Please see the installation details as follows:
a) Connect the data and power cables to the two hard disk
drives and place the hard disk drives on the NVR case.

Install the Hard Disk Drive(s)

2.5" HDD
3.5" HDD
b) Carefully flip the NVR case and secure the hard disk drives
to the NVR with the eight (8) screws.
2.5" HDD
3.5" HDD
