Raman Spectroscopy Bundle
Both front ends can be purchased as an imperial version (RSBR1, RSBC1) or a metric version
(RSBR1/M, RSBC1/M). For the purpose of this manual, RSBR1(/M) or RSBC1(/M) refers to
both versions, respectively.
For custom-made solutions, Thorlabs offers the
Thorlabs 60 mm cage system components. Other custom-made front ends can be connected
to the RSB1(/M) using the SM1.5 thread at the input aperture.
For data acquisition and analysis, Thorlabs provides the
(Thorlabs OSA Raman Software). The software is shipped with the RSB1(/M) on an USB flash
drive which also contains all required drivers. For software updates, please see the chapter
Software and Installation
As an excitation light source, Thorlabs recommends the
laser driver. The modular design of the Thorlabs Raman bundle also allows use of alternative
lasers, fulfilling the laser requirements
Attention
Please find all safety information and warnings concerning this product in the chapter
in the Appendix.
Please note that safety of the assembled system is the responsibility of the assembler. This
refers in particular to laser safety for high-power lasers as used for Raman spectroscopy.

1.1 Ordering Codes and Accessories

Base Unit for Raman Spectroscopy (Imperial Threads) with Coded Aperture
RSB1
(CODA Technology) and CMOS-Camera Sensor. Included are a MB1824
Breadboard with BBH1 Lifting Handles, RS2.5P Mounting Posts, CF125C
Clamping Forks, and a USB Stick Carrying the OSA Raman Software and
the Camera Calibration Data for Spectra Reconstruction.
Base Unit for Raman Spectroscopy (Metric Threads) with Coded Aperture
RSB1/M
(CODA Technology) and CMOS-Camera Sensor. Included are a
MB4560/M Breadboard with BBH1 Lifting Handles, RS2.5P/M Mounting
Posts, CF125C/M Clamping Forks, and a USB Stick Carrying the OSA Ra-
man Software and the Camera Calibration Data for Spectra Reconstruction.
Front End for Reflective Measurements of Solid Samples with the RSB1
RSBR1
Base Unit (Imperial Type). Included are a Sample Table for Imperial Sys-
tems with a Stray Light Shield and a RPC Polystyrene Calibration Chip.
Front End for Reflective Measurements of Solid Samples with the RSB1/M
RSBR1/M
Base Unit (Metric Type). Included are a Sample Table for Metric Systems
with a Stray Light Shield and a RPC Polystyrene Calibration Chip.
RSBC1 Front End for Measurements of Liquid Samples in a Cuvette with the RSB1
Base Unit (Imperial Type). Included are a TR1.5 Mounting Post and PH2E
Rev: 1.0, 17-Sep-2021
.
25
stated in this manual.
73
© 2021 Thorlabs
Chapter 1: General Information
RSBA1 adapter to connect the RSB1(/M) to
10
OSA Software, Raman Edition
FPV785M laser with the CLD1015
