Sliding the Cable Clip over-top of the Pole
Slide the Arm Shoulder over-top of the Pole, sliding it down
10.
into position.
Turn the Locking Lever on the Arm Shoulder clock-wise,
11.
securing the Arm Shoulder into place.
Note: The Locking Lever may require multiple turns in
order to properly secure the Arm Shoulder in place.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
