Technical Data; Front Panel And Enclosure; Keyboard - Bosch Rexroth IndraControl VCP 02.2 Project Planning Manual

R911310375 / 02 | Rexroth IndraControl VCP 02

Technical Data

4 Technical Data
4.1

Front Panel and Enclosure

Front Panel and Enclosure
Enclosure
Front Panel
Front Panel Cover
Seal
Mounting Cutout
Mounting Depth
Degrees of Protection
Total Weight
4.2

Keyboard

Keyboard
Type
Number of Keys
Key Area (Raised)
Actuator Travel
Actuating Force
Switching Cycles
Lifetime (Min.)
Display Elements
Electric Drives and Controls | Bosch Rexroth AG
Steel Sheet, Galvanized
Aluminum, anodized natural finish
96 mm x 144 mm x 5 mm (3.78" x 5.669" x 0.196") - (H x
W x D)
Polyester Foil
Circumferential Rubber Seal on the Rear
82 mm x 136 mm (3.228" x 5.354") - (H x W)
About 58 mm (2.283")
Front: IP65
Rear: IP20
About 500 g
Membrane Keyboard
11
10 mm (0.393") - (H x W)
0.3 mm (0.011")
3 N
Approx. 3 millions under the following conditions:
Pressing Element: Test Plunger (DIN 42115)
Pressing Force: 10 N
Pressing Frequency: 1 Hz
2 Million Switching Cycles
6 Status LEDs
4-1
