6-2 Bosch Rexroth AG | Electric Drives and Controls
Display and Operating Components
6.1.2

Character Attributes

6.1.3

Fonts

6.2

Keyboard

6.2.1

Editing Keys

6.2.2

Navigation Keys

The following character attributes can be displayed on the operating
device:
– Flashing
– Underline
– Foreground/background color
You can use Windows fonts. Windows and unicode character sets are
possible.
The keys are positioned under an environmental-proof polyester foil.
You project the operating principle of the keys in the programming soft-
ware.
To activate the edit mode, you must press the data release key at first.
After the status LED „data release" lights up an input with the edit keys
is possible.
The key Minus is used to enter negative values within the editor. In the
increment editor, the variable value is decreased by 1. When the key is
held down, the function is repeated at an automatically increasing rate
of repetition.
The key Plus is used to enter positive values within the editor. In the in-
crement editor, the variable value is increased by 1. When the key is
held down, the function is repeated at an automatically increasing rate
of repetition.
The key Cursor Left can be configured to directly call up any screen. In
the editor, the cursor is moved one character to the left (character se-
lection). This function corresponds to the system variable KeyCursLeft.
Rexroth IndraControl VCP 02 | R911310375 / 02
