Instruction for User,
Installation & Servicing
For use in Great Britain and Eire.
600 HD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 600HD and is the answer not in the manual?

Questions and answers

Related Manuals for Infinity 600HD

Summary of Contents for Infinity 600HD

  • Page 1 Instruction for User, Installation & Servicing For use in Great Britain and Eire. 600 HD...

  • Page 2: Table Of Contents

    Contents Instruction for User, Installation & Servicing ........................0 Benchmark Scheme ................................2 Introduction ..................................3 Consumer Protection Information ............................ 3 Lighting the Appliance & General Operation Of Control ....................5 Auto (Thermostatic) Control ............................. 7 Menu features..................................8 Changing The Handset Batteries............................. 8 Cleaning the 600 HD Appliance ............................

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimize safety, efficiency and performance.

  • Page 4: Introduction

    600 HD USERS INSTRUCTIONS Introduction The 600 HD has been designed and tested to the requirements of EN 613 and is suitable for use in Great Britain & Republic of Ireland. 600 HD incorporates a single gas valve which selects ignition pilot, with variable setting between low and high setting and is operated via remote control hand device or optional smart app device.
  • Page 5 600 HD USERS INSTRUCTIONS Important Information The appliance is for use on Natural Gas (G20 @ 20mbar) or LPG (G31 @ 37mbar). The Chimney or flue (unless new or previously used with a gas appliance) shall be swept before installation if been used for solid fuel. In Great Britain, the appliance must be installed by a competent person whose name appears on the gas safe register.

  • Page 6: Lighting The Appliance & General Operation Of Control

    600 HD USERS INSTRUCTIONS Lighting the Appliance & General Operation of Control Display overview Press to awaken the handset from its dormant sleep mode at any time. Fig 1 shows the display neutral, ready to turn on. Turn on (startup). displays an “UNLOCK”...
  • Page 7 600 HD USERS INSTRUCTIONS Flame height adjustment Once the fire has been started (after a period of 10 minutes) the flame height can be decreased by moving your finger clock wise or decreased moving your finger anti-clock wise using the selector wheel. Once the desired flame level is set, remove your finger from the selector wheel to transmit your selection to the receiver.

  • Page 8: Auto (Thermostatic) Control

    600 HD USERS INSTRUCTIONS Note: The handset contains a sensitive temperature measurement device. To achieve the best thermostatic efficiency do not place the handset near the heat source, avoid covering, direct sunlight or near a draft or open window etc. Place the handset at a midpoint in the room or area being heated.

  • Page 9: Menu Features

    600 HD USERS INSTRUCTIONS Menu features The menu can be accessed by pressing and holding the button (approx. 5 seconds) until the menu graphic completes (see fig 6). Use the selector wheel to highlight one of the available options. Press to enter the required option.

  • Page 10: Cleaning The 600 Hd Appliance

    600 HD USERS INSTRUCTIONS Cleaning the 600 HD Appliance Ensure the appliance is cold before proceeding. The outer metal work frame should be cleaned using a damp cloth. To clean the glass panel, remove the four M4 nuts fixing the glass clamp to the glass panel. (See Fig 8).

  • Page 11: Fuel Bed Layout

    600 HD USERS INSTRUCTIONS Cleaning the fuel bed shapes. (Please refer to customer protection information on page 2 of this booklet before cleaning or replacing any refractory materials). The fuel bed components are delicate and they should be handled with great care. They can be brushed very gently with a soft brush to remove dust or any deposits.
  • Page 12 600 HD USERS INSTRUCTIONS WALNUT FUEL BED LAYOUT Place a single layer of forge embers across the burner plaque. Place bark chippings across the front of the air tray. LT7618 Issue No 1 (06/2018) P a g e | 11...
  • Page 13 600 HD USERS INSTRUCTIONS Position the first three logs as shown above ensuring that log No1 is positioned tight into the corner of the firebox. Tease out some Embaglow into a fine nest and place over the burner ports. As show in the detailed image.
  • Page 14 600 HD USERS INSTRUCTIONS Position logs 4 & 5 as shown above. Position log 5 on its rear location pin. Position logs 6 & 7 on the rear location pins as shown above. LT7618 Issue No 1 (06/2018) P a g e | 13...
  • Page 15 600 HD USERS INSTRUCTIONS Position log 8 on the rear location pin as shown above. LT7618 Issue No 1 (06/2018) P a g e | 14...
  • Page 16 600 HD USERS INSTRUCTIONS SILVER BIRCH FUEL BED LAYOUT Place a single layer of forge embers across the burner plaque. Place bark chippings across the front of the air tray. LT7618 Issue No 1 (06/2018) P a g e | 15...
  • Page 17 600 HD USERS INSTRUCTIONS Position the first three logs as shown above ensuring that log No1 is positioned tight into the corner of the firebox. Tease out some Embaglow into a fine nest and place over the burner ports. As show in the detailed image.
  • Page 18 600 HD USERS INSTRUCTIONS Position logs 4 & 5 as shown above. Position log 5 on its rear location pin. Position logs 6 & 7 on the rear location pins as shown above. LT7618 Issue No 1 (06/2018) P a g e | 17...
  • Page 19 600 HD USERS INSTRUCTIONS Position log 8 on the rear location pin as shown above. LT7618 Issue No 1 (06/2018) P a g e | 18...

  • Page 20: Technical Specification

    600 HD INSTALLATION INSTRUCTIONS Technical Specification Working Injector Country Model Type Pressure Input Class Pilot 600 HD Natural 20 mbar 5.2KW 2900 GB, IE 360A Gross 600 HD 37 mbar 4.3KW GB, IE Gross 9264 Note: The efficiency of the appliance has been measured as specified in BS7977-1 2009+ A1:2013 and the net efficiency rate is 80% for natural gas and 75.9% for LPG the gross calorific value of the fuel has been used for this efficiency calculation.

  • Page 21: Siting The Appliance

    600 HD INSTALLATION INSTRUCTIONS Packaging Check List 1 x Glass Panel 1 x Air Tray Assembly 1 x Boxed Fuel Bed 1 x Transformer Plug 1 x Emergency Power Battery Adaptor 1 x RF Handset 4 x AAA 1.5V Batteries Siting the Appliance Regulation and warnings This appliance must only be installed in Great Britain and Eire.
  • Page 22 600 HD INSTALLATION INSTRUCTIONS Prior to installation ensure that the local distribution conditions (identification of the type of gas and pressure) and adjustment of the appliance are compatible G20 @ 20 mbar or G31@ 37mbar. The front of the fire act as a dress guard, conforming to BS 1945 (1971) and satisfies the heating appliance regulations (1991).
  • Page 23 600 HD INSTALLATION INSTRUCTIONS Builder’s opening aperture size when fitted in conjunction with a four sided trim 50mm Min from Floor level Builder’s opening aperture size when fitted with a 50mm rebated fireplace 600 HD LT7618 Issue No 1 (06/2018) P a g e | 22...
  • Page 24 600 HD INSTALLATION INSTRUCTIONS Open the firebox aperture as of the sizes stipulation in the section (50mm rebated surround). Please note the fire box height from the floor may well vary dependent on the fireplace surround design. Check the fireplace details first. Slide the fire box back into the catchment area and secure the fire box against the front face of the chimney breast.
  • Page 25 600 HD INSTALLATION INSTRUCTIONS A- B-C / Builder’s opening aperture size when fitting hole in the wall plaster edge, slips. 600 HD A-Hole in the wall using none combustible slips. LT7618 Issue No 1 (06/2018) P a g e | 24...
  • Page 26 600 HD INSTALLATION INSTRUCTIONS Using rawl plugs and wood screws retain the fire box via the 6mm holes within the slip brackets. None combustible slips can now be fitted up to the edge of the fire place frame. B-Dry lined hole in the wall. LT7618 Issue No 1 (06/2018) P a g e | 25...
  • Page 27 600 HD INSTALLATION INSTRUCTIONS Open the aperture size to accommodate the fire box as out lined at the beginning of the section. With the height of the opening established and support for the fire box in place, take out a further area of the plaster board lining to expose the inner brick work face of the chimney breast as out lined in Fig 1.
  • Page 28 600 HD INSTALLATION INSTRUCTIONS Installation with a flexible liner The 600 HD is designed for installation within the masonry chimney with or without a flexible line. If the flexible liner option is required the following two methods should be followed. Method 1 A 125mm minimum diameter liner conforming to BS 715 may be used.
  • Page 29 600 HD INSTALLATION INSTRUCTIONS Offer the fire box assembly within the masonry aperture at the same time guiding the gather hood within the guides situated on the top of the fire box (Please see Fig 2). Engage the hood studs within the slotted holes and secure using the three M4 nuts provided within the gather hood kit.

  • Page 30: Installation Of The Appliance

    600 HD INSTALLATION INSTRUCTIONS Installation of the Appliance Optional Wi-Fi Kit Installation The Kit contains the following components: • 1 x Wi-Fi Dongle. • 5 x self-adhesive aluminum clips. • 1 x Wi-Fi lead. • 2 x M3 nuts and washers Remove the 2 off screws retaining the ECU cover from the LH side of the burner carrier.
  • Page 31 600 HD INSTALLATION INSTRUCTIONS With the dongle connected to the lead, locate the unit within the two M3 studs position on the left hand side of the fire box. When positioning the Wi-Fi unit it is important to have the cable socket facing the rear of the fire box.
  • Page 32 600 HD INSTALLATION INSTRUCTIONS Gas supply routing. Check the gas run to assess that the gas supply is capable of providing the required amount of gas and is in accordance with the rules in force. Soft copper pipe can be used to install the appliance. Soldered joints can be used only externally of the appliance.
  • Page 33 600 HD INSTALLATION INSTRUCTIONS Power lead routing The power supply for this appliance is provided via AC power adaptor 230 VAC. The main cable terminates the rear Right hand side of the fire box. The length of the cable provided with the appliance is 1.65 meters.
  • Page 34 600 HD INSTALLATION INSTRUCTIONS The battery manual override option is a backup supply in case of a power failure / power cut to the property. The battery holder and adaptor lead are provide within the packing of the appliance. (Please note that the “C” cell batteries are not included). It is good practice to demonstrate the battery option to the customer during the commissioning process.
  • Page 35 600 HD INSTALLATION INSTRUCTIONS Important When fitting the fireplace frame the studs need to be fully engaged to the top of the keyhole slot (as shown). If this is not fully engaged, it may cause ignition and outing issues Keyhole slot must be fully engaged to maintain the 10mm clearance between the glass fixing bracket and the bottom internal edge of the fireplace frame...
  • Page 36 600 HD INSTALLATION INSTRUCTIONS Four sided trim Please note when installing the appliance using this method it is very important to maintain a gap of 50mm from the underside of the fire box base to the floor. Failure to do this will result in damage to the operating components.

  • Page 37: Commissioning The Appliance

    600 HD INSTALLATION INSTRUCTIONS Commissioning the Appliance Checking gas soundness and running pressure. Turn on the supply to the appliance and check for soundness in accordance with the current codes of practice. Turn off the gas supply at the external isolation valve. Remove the pressure test point screw from the inlet elbow and connect the pressure gauge.
  • Page 38 600 HD INSTALLATION INSTRUCTIONS Fuel Bed Layout. Fuel bed layout should be fitted using the guidance stipulated on pages 9-15 of the User Instruction section. Fit Glass Panel. Due to transit protection, the glass panel is packed with a protective sleeve within the packed appliance.
  • Page 39 600 HD INSTALLATION INSTRUCTIONS Slide the glass in front of the frame and push in to place making sure that the glass is pushed in to the glass channel properly and sits in the bottom of it and that the inner frame is still central. Push the glass in to place so it sits flat against the frame...
  • Page 40 600 HD INSTALLATION INSTRUCTIONS Run the match along the edge of the inlet air channel. All smoke must be drawn into the inlet channel if the spillage test is satisfactory. If spillage occurs wait a further five minutes and repeat the test. Repeat the test with doors open and with any extractor fans in other rooms in operation.

  • Page 41: Annual Service Requirement

    600 HD SERVICE / FAULT FINDING INSTRUCTIONS Annual Service Requirement. General Servicing should be carried out annually by competent person whose name appears on the gas safe register. All Gas Safe engineers should possess an ID carrying the logo below. Before commencing any service or replacement of part, turn off the gas supply to the fire.
  • Page 42 600 HD SERVICE / FAULT FINDING INSTRUCTIONS Remove the rear panel from within the fire box. Finally remove the eight screws from the inner and outer inspection covers. (Please see figure 1) With the covers removed. The catchment area at the rear of the fire box can now be inspected for debris.

  • Page 43: Fault Finding Charts

    Fault Finding Charts LT7618 Issue No 1 (06/2018) P a g e | 42...

  • Page 44: Wiring Diagram

    600 HD SERVICE / FAULT FINDING INSTRUCTIONS Wiring Diagram Attach to the valve LT7618 Issue No 1 (06/2018) P a g e | 43...

  • Page 45: Maintenance

    600 HD MAINTENANCE INSTRUCTIONS Maintenance To Remove the Burner Carrier Assembly Remove the glass panel as described on page 8 of the user’s instruction section. Remove the Loose shapes and the air tray assembly. Remove the four screws retaining the gas inlet plate and the ECU cover. (Please see Fig 1) Shut off the restrictor elbow and disconnect the 8mm inlet nut.
  • Page 46 600 HD MAINTENANCE INSTRUCTIONS Replacement of the Gas Valve Follow the sequence to remove the burner carrier assembly. Disconnect the thermocouple from the rear of the gas valve. Undo the three compression nuts securing the pipes to the gas valve and remove the two M4 nuts fixing the valve to the valve mounting brackets.
  • Page 47 600 HD MAINTENANCE INSTRUCTIONS Replacement of the burner Assembly Remove the glass panel as described on page 9 of the user’s instruction section. Remove the Loose shapes and the air tray assembly. Undo the two fixing screws retaining the burner assembly with the carrier. Lift the burner clear of the silencer and injector tip.

  • Page 48: Short Spares List

    600 HD MAINTENANCE INSTRUCTIONS Short Spares List Component Part No Burner Bar 7648 Injector Mk 360 A Natural Gas 6226 ODS Unit/oxy pilot Natural Gas 7280 Injector MK 99 LPG 8130 ODS Unit/oxy pilot LPG 2703 Control Valve 6590 Electrical Control Unit (ECU) 7150 Ignition Lead 6646...

  • Page 49: Your Fire Years Parts Extended Warranty

    Charlton and Jenrick Ltd. The registration form must be returned within 1 months of purchase. For further information please contact the Infinity help desk on 0845 5195991 or visit our web site www.CharltonandJenrick.co.uk. Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase.

  • Page 50: Four Year Service Log Details

    The following information must be completed to support by receipts as part of the conditions of the extended five year parts warranty and the appliance must be registered by completing and return the registration document (last page of this booklet) to Infinity Fires. Date...

  • Page 51: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 52: Register Your 12 Month Warranty With Us Today

    Register Your 12 Month Warranty with Us Today Simply detach this sheet from this booklet, complete and return it in a stamped addressed envelope to the address www.charltonandjenrick.co.uk. below. The other alternative is to register on line at Charlton and Jenrick Ltd Unit D Stafford Park 2 Telford...
  • Page 53 LT7618 Issue No 1 (06/2018) P a g e | 52...
  • Page 54 LT7618 Issue No 1 (06/2018) P a g e | 53...
  • Page 55 LT7618 Issue No 1 (06/2018) P a g e | 54...
  • Page 56 Infinity 600 HD Packing List A-0693 – Glass liners fitted 600 HD Pre- Fix A-0699 – Brick liners fitted A-0700 – Vermiculite liners fitted A-0780 – Glass liners fitted 600 HD Pre- Fix A-0781 – Brick liners fitted A-0782 – Vermiculite liners fitted...
