Infinity 800 HD UBL Instruction For User, Installation & Servicing

With under bed lighting
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction for user,
Installation & Servicing
800 HD
With Under Bed
Lighting
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 800 HD UBL and is the answer not in the manual?

Questions and answers

Related Manuals for Infinity 800 HD UBL

Summary of Contents for Infinity 800 HD UBL

  • Page 1 Instruction for user, Installation & Servicing 800 HD With Under Bed Lighting Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR EXTENDED FIVE YEAR PARTS WARRANTY ........1 PARTS WARRANTY Benchmark Scheme ..............1 Introduction ................2 Consumer Protection Information .......... 2 Lighting the Appliance & General Operation Of Control ..4 In order to validate your extended 5 years parts warranty please Auto (Thermostatic) Control ...........

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance.

  • Page 4: Introduction

    Introduction The 800 HD with Under Bed Light has been designed and tested to the requirements of EN 613 and is suitable for use in Great Britain. 800 HD with UBL incorporates a single gas valve which selects ignition pilot, with variable setting between low and high setting and is operated via remote control hand device or optional smart app device.
  • Page 5 800 HD with UBL USERS INSTRUCTIONS Important Information The appliance is for use on Natural Gas (G20 @ 20mbar) or LPG (G31 @ 37mbar). The Chimney or flue (unless new or previously used with a gas appliance) shall be swept before installation if been used for solid fuel.

  • Page 6: Lighting The Appliance & General Operation Of Control

    800 HD with UBL USERS INSTRUCTIONS Lighting the Appliance & General Operation Of Control Handset up video Display overview Press to awaken the handset from its dormant sleep mode at any time. Fig 1 shows the display neutral, ready to turn on. Turn on (start up).
  • Page 7 800 HD with UBL USERS INSTRUCTIONS Flame height adjustment Once the fire has been started (after a period of 10 minutes) the flame height can be decreased by moving your finger clock wise or decreased moving your finger anti-clock wise using the selector wheel.

  • Page 8: Auto (Thermostatic) Control

    800 HD with UBL USERS INSTRUCTIONS Note: The handset contains a sensitive temperature measurement device. To achieve the best thermostatic efficiency do not place the handset near the heat source, avoid covering, direct sunlight or near a draft or open window etc. Place the handset at a midpoint in the room or area being heated. Allow 5-10 minutes for the handset to stabilize if subjected to extremes of temperature.

  • Page 9: Menu Features

    800 HD with UBL USERS INSTRUCTIONS Menu features The menu can be accessed by pressing and holding the button (approx. 5 seconds) until the menu graphic completes (see fig 6). Use the selector wheel to highlight one of the available options.
  • Page 10 800 HD with UBL USERS INSTRUCTIONS Under Bed Light Feature The Under Bed Light feature offers multiple lighting features to enhance a flame effect or provide lighting effects whilst the appliance heat output is not required. The Under Bed Light feature can be operated whilst the fire is on or off. Press to awaken the handset from its dormant sleep mode at any time.

  • Page 11: Changing The Handset Batteries

    800 HD with UBL USERS INSTRUCTIONS Notes: ▪ If no command is entered within 15 seconds whilst in the ‘LIGHT’ function the handset will return to the main operating screen. ▪ Brightness alternative on/off switch. 0% = lights off, any value greater than 0% will turn lights on for the effect selected.

  • Page 12: Cleaning The 800 Hd With Ubl Appliance

    800 HD with UBL USERS INSTRUCTIONS Cleaning the 800 HD with UBL Appliance Ensure the appliance is cold before proceeding. The outer metal work frame should be cleaned using a damp cloth. To clean the glass panel, remove the four M4 nuts fixing the glass clamp to the glass panel. (See Fig 8).

  • Page 13: Fuel Bed Layout

    800 HD with UBL USERS INSTRUCTIONS Cleaning the fuel bed shapes. (Please refer to customer protection information on page 3 of this booklet before cleaning or replacing any refractory materials). The fuel bed components are delicate and they should be handled with great care. They can be brushed very gently with a soft brush to remove dust or any deposits.
  • Page 14 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 12...
  • Page 15 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 13...
  • Page 16 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 14...
  • Page 17 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 15...
  • Page 18 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 16...

  • Page 19: Silver Birch Fuel Bed

    800 HD with UBL USERS INSTRUCTIONS Silver Birch Fuel Bed LT 7941 Issue No 3 (04/22) P a g e | 17...
  • Page 20 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 18...
  • Page 21 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 19...
  • Page 22 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 20...
  • Page 23 800 HD with UBL USERS INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 21...
  • Page 24 800 HD with UBL USERS INSTRUCTIONS Technical Specification Model Working Front Rear Country Type Pressure Injector Injector Input Class Pilot 800 HD Natural 7.7 KW 2900 GB, IE mbar 220A Gross 800 HD 7.1 KW GB, IE Mbar Gross 9264 Efficiency Class 1 Gas Inlet Connection Size 8mm Handset Replacement Batteries 4 x AAA 1.5V...

  • Page 25: Siting The Appliance

    800 HD with UBL INSTALLATION INSTRUCTIONS Packaging Check List 1 x Glass Panel 1 x Air Tray Assembly 1 x Boxed Fuel Bed 1 x Transformer Plug 1 x Battery Holder 1 x Emergency Power Battery Adaptor 1 x RF Handset 4 x AAA 1.5V Batteries Siting the Appliance Regulation and warnings...
  • Page 26 800 HD with UBL INSTALLATION INSTRUCTIONS Prior to installation ensure that the local distribution conditions (identification of the type of gas and pressure) and adjustment of the appliance are compatible G20 @ 20 mbar or G31 @ 37 mbar. The front of the fire act as a dress guard, conforming to BS 1945 (1971) and satisfies the heating appliance regulations (1991).
  • Page 27 800 HD with UBL INSTALLATION INSTRUCTIONS Open the firebox aperture as of the sizes stipulated in the previous section (50mm rebated surround). Please note the fire box height from the floor may well vary dependent on the fireplace surround design. Check the fireplace details first. Slide the fire box back into the catchment area and secure the fire box against the front face of the chimney breast.
  • Page 28 800 HD with UBL INSTALLATION INSTRUCTIONS A- B-C / Builder’s opening aperture size when fitting hole in the wall boarded edge or slips. A-Hole in the wall using none combustible slips. LT 7941 Issue No 3 (04/22) P a g e | 26...
  • Page 29 800 HD with UBL INSTALLATION INSTRUCTIONS Using rawl plugs and wood screws retain the fire box via the 6mm holes within the slip brackets. None combustible slips can now be fitted up to the edge of the fire place frame. B-Dry lined hole in the wall.
  • Page 30 800 HD with UBL INSTALLATION INSTRUCTIONS Open the aperture size to accommodate the fire box as out lined at the beginning of the section. With the height of the opening established and support for the fire box in place, take out a further area of the plaster board lining to expose the inner brick work face of the chimney breast as out lined in Fig 1.
  • Page 31 800 HD with UBL INSTALLATION INSTRUCTIONS Checking the flue fire opening and fire opening. Check that the chimney conforms to the required specification as previously stated. Examine the condition and carry out any remedial work including removing any debris from the base. If the flue has been used for solid fuel it should be swept prior to installation.
  • Page 32 800 HD with UBL INSTALLATION INSTRUCTIONS Offer the fire box assembly within the masonry aperture at the same time guiding the gather hood within the guides situated on the top of the fire box (Please see Fig 2). Engage the hood studs within the slotted holes and secure using the three M4 nuts provided within the gather hood kit.
  • Page 33 800 HD with UBL INSTALLATION INSTRUCTIONS Gas supply routing. Check the gas run to assess that the gas supply is capable of providing the required amount of gas and is in accordance with the rules in force. Soft copper pipe can be used to install the appliance. Soldered joints can be used only externally of the appliance.
  • Page 34 800 HD with UBL INSTALLATION INSTRUCTIONS Power lead routing The power supply for this appliance is provided via AC power adaptor 230 VAC. The main cable terminates at the rear Right hand side of the fire box. The length of the cable provided with the appliance is 1.65 metres.
  • Page 35 800 HD with UBL INSTALLATION INSTRUCTIONS The battery manual override option is a backup supply in case of a power failure / power cut to the property. The battery holder and adaptor lead are provide within the packing of the appliance.
  • Page 36 800 HD with UBL INSTALLATION INSTRUCTIONS Important When fitting the fireplace frame the studs need to be fully engaged to the top of the keyhole slot (as shown). If this is not fully engaged, it may cause ignition and outing issues Keyhole slot must be fully engaged to maintain the 10mm clearance between the glass fixing bracket and the bottom internal edge of the...

  • Page 37: Commissioning The Appliance

    800 HD with UBL INSTALLATION INSTRUCTIONS Commissioning the Appliance Checking gas soundness and running pressure. Turn on the supply to the appliance and check for soundness in accordance with the current codes of practice. Turn off the gas supply at the external isolation valve. Remove the pressure test point screw from the inlet elbow and connect the pressure gauge.
  • Page 38 800 HD with UBL INSTALLATION INSTRUCTIONS Spillage Test Procedure. Light the appliance on maximum setting. Close all the doors and windows. After five minutes fit the smoke match within match holder and position as illustrated in Figure 13 with the head of the match just inside the inlet air channel. Run the match along the edge of the inlet air channel.
  • Page 39 800 HD with UBL INSTALLATION INSTRUCTIONS Non reflective glass option. The non-reflective glass has no print on the glass due to this there is an inner frame provided to be fitted before the glass panel. Slide the inner frame into the glass channel and push in to place ensuring the tabs are sitting on top of the firebox(see below) ensure the frame is central and there is an even gap either side of the frame (between the side of the firebox and the tabs of the frame) Make sure that the gap...
  • Page 40 800 HD with UBL INSTALLATION INSTRUCTIONS Advise The Customer. The glass front of this fire acts as a dress guard conforming to BS 1945 (1997) and satisfies the heating appliance regulations (1991) however; a fireguard conforming to BS6539 (1997) must be used to protect young children, the elderly, or infirm.

  • Page 41: Annual Service Requirement

    800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS Annual Service Requirement. General Servicing should be carried out annually by competent person whose name appears on the gas safe register. All Gas Safe engineers should possess an ID carrying the logo below.
  • Page 42 800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS With the covers removed. The catchment area at the rear of the fire box can now be inspected for debris. With the aid of a mirror via the back of the box check the path of the flue for any restrictions.

  • Page 43: Fault Finding Charts

    800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS Charts Fault Finding LT 7941 Issue No 3 (04/22) P a g e | 41...
  • Page 44 800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 42...
  • Page 45 800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS LT 7941 Issue No 3 (04/22) P a g e | 43...

  • Page 46: Wiring Diagram

    800 HD with UBL SERVICE / FAULT FINDING INSTRUCTIONS Wiring Diagram Attach to the Oxy Pilot LT 7941 Issue No 3 (04/22) P a g e | 44...

  • Page 47: Maintenance

    800 HD with UBL MAINTENANCE INSTRUCTIONS Maintenance To Remove The Burner Carrier Assembly Remove the glass panel as described on page 9 of the users instruction section. Remove the Loose shapes. Remove the four screws retaining the gas inlet plate and the ECU cover. Shut off the restrictor elbow and disconnect the 8mm inlet nut.
  • Page 48 800 HD with UBL MAINTENANCE INSTRUCTIONS Replacement of the Gas Valve Follow the sequence to remove the burner carrier assembly. Disconnect the thermocouple from the rear of the gas valve. Undo the three compression nuts securing the pipes to the gas valve and remove the two M4 nuts fixing the valve to the valve mounting brackets.
  • Page 49 800 HD with UBL MAINTENANCE INSTRUCTIONS Replacement of the centre burner Assembly Remove the glass panel as described on page 9 of the users instruction section. Remove the Loose shapes. Undo the two fixing screws retaining the burner assembly with the carrier. Lift the burner clear of the silencer and injector tip.
  • Page 50 800 HD with UBL MAINTENANCE INSTRUCTIONS Replacement of the Under Bed Drive Board. Switch off the mains supply from the main supply plug socket. Remove the glass panel as described on page 9 of the users instruction section. Remove the loose shapes. Remove the ECU cover.

  • Page 51: Short Spares List

    800 HD with UBL MAINTENANCE INSTRUCTIONS Replacement Handset Follow the guide stipulated on page 7 of the users instructions “Changing the handset batteries” to load the batteries into the new handset. The replacement handset will need to be paired again to the ECU unit. Press and hold (approx.
  • Page 52 Front Injector Mrk 72 8197 Side Injector Mrk 79 x 2 8198 ODS Unit (oxy Pilot) 7280 Control Valve 6590 Electrical Control Unit 7150 (ECU) LED driver 7835 LED Board 7836 Ignition Lead 6646 9V transformer 7145 Handset RF 7144 Earth lead 6593 LT 7941 Issue No 3 (04/22)
  • Page 53 Glass panel NON-reflective: 7599 Standard: 7475 Rear glass liner 7725 Ceramic liner behind glass: 7723 Side glass liner 7726 Ceramic liner behind glass: 7724 LT 7941 Issue No 3 (04/22) P a g e | 51...
  • Page 54 Register your appliance online today to activate your warranty LT 7941 Issue No 3 (04/22) P a g e | 52...

  • Page 55: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 56: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 57 LT 7941 Issue No 3 (04/22) P a g e | 55...
  • Page 58 LT 7941 Issue No 3 (04/22) P a g e | 56...
  • Page 59 LT 7941 Issue No 3 (04/22) P a g e | 57...
  • Page 60 Infinity 800 HD with UBL Packing List 800 HD A-0709 – Glass liners fitted Pre- Fix with UBL A-0718 – Red Brick liners Fitted A-0719 – Vermiculite liners Fitted 800 HD A-0789 – Glass liners fitted Pre- Fix with UBL A-0790 –...
