Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
890 FL
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 5845 (ISS 15)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 890 FL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinity 890 FL

Summary of Contents for Infinity 890 FL

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions 890 FL Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Introduction (user instructions) ..5 EXTENDED FIVE SECTION TWO Operating the Appliance (users YEAR PARTS WARRANTY instructions) ..............7 SECTION THREE Cleaning (user instructions) .... 10 In order to validate your extended 5 years parts SECTION FOUR Fuel Bed Cleaning and Layout (user warranty please read the Benchmark Scheme on the...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: INFINITY 890 FL Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (User Instructions)

    INTRODUCTION  The 890 FL as been designed and tested to the requirements of EN 613 and is suitable for use in GB (Great Britain) and IE (Ireland). ...
  • Page 6 IMPORTANT INFORMATION  The appliance is for use on Natural Gas (G20 @ 20mbar) or L.P.G. (G31 @ 37mbar)only.  The chimney or flue (unless new or previously used with a gas appliance) shall be swept before installation if it has been used for solid fuel. ...

  • Page 7: Section Two Operating The Appliance (Users Instructions)

    SECTION TWO Operating the Appliance (users instructions) To light the appliance using the remote hand set: a. Press the button. Continue to hold the button for approximately 2 seconds and release. When released a bleep should be heard and the appliance will automatically go through the ignition sequence and the pilot should ignite.
  • Page 8 To Replace Battery In Hand Set (3 aaa type batteries) Remove the cover from the rear of the handset and fit replacement battery. Clock Regulation As soon as the batteries are fitted the timer digits will blink. Using the arrow key increase or decrease the hour, minutes and week`s value.
  • Page 9 Child Lock (Handset) To activate `Child Lock` : Press and hold the Mode Key O button for 5 seconds, this will lock and disable the handset and a “padlock” symbol will appear on the bottom of the screen. This can be done while the fire is “off” or “on”. To deactivate this function press and hold the Mode Key O for 5 seconds and the “padlock”...

  • Page 10: Section Three Cleaning (User Instructions)

    SECTION THREE Cleaning (user instructions) Warning: - Before you clean any part of the appliance ensure that the appliance is turned off and cold. CLEANING: PILOT ASSEMBLY (Before cleaning ensure that the appliance is turned off and cold) In some instances you may experience ignition problems even when the appliance is new.

  • Page 11: Section Four Fuel Bed Cleaning And Layout (User Instructions)

    GLASS CLEANING From time to time it will be necessary to clean the glass panel of your 890 FL. We recommend you use a Ceramic hob cleaner these are available for all leading super markets: - i.e. ASDA, TESCO, SAINSBURY’S Etc.
  • Page 12 Fitting the fire liners Once the firebox is secured into position fit either the vermiculite or brick back liners supplied. Position the 2- piece rear liner behind the 3 lugs located at the bottom rear of the firebox. The vermiculite liner has a vertical joint and the brick back has a horizontal joint.
  • Page 13 SECTION FOUR Fuel Bed Cleaning and Layout (user instructions)  Place air tray within burner shelf assembly and cover the burner plate with a single layer of small bark chippings.  Place a layer of the loose bark shapes along the front edge covering tray...
  • Page 14  Place the two log shapes as shown.  Place the two log shapes as shown.  Place the two log shapes as shown.  Place the two log shapes as shown. LT5845 (ISS 15)

  • Page 15: Section Five General Points (User Instructions)

    Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance. It is advised that a competent person service the 890 FL fire annually. The fire is more likely to provide trouble-free operation.

  • Page 16: Section Six Appliance Data (Installation Instructions)

    SECTION SIX Appliance Data (installation instructions) NATURAL GAS Gas Type: CATEGORY I 2 H CATEGORY I 3 P Gas Pressure: 20 mbar +/- 1.0mbar 37mbar +/- 1.0mbar Pressure Test Point Location: Gas inlet elbow Gas Input: 6.6 kW Gross (Max.) 7.0 kW Gross (Max.) 2.8 kW Gross (Min.) 2.8 kW Gross (Min.)

  • Page 17: Section Seven Regulations And Warnings (Installation Instructions)

    SECTION SEVEN Regulations and Warnings (installation instructions)  This appliance must only be installed in Great Britain or Ireland.  The appliance is suitable for use on natural gas only.  GB (Great Britain) This fire does not normally require purpose build ventilation. ...

  • Page 18: Section Eight Siting The Appliance (Installation Instructions)

    SECTION EIGHT Siting the Appliance (installation instructions)  CLASS ONE That is a conventional brick or stone chimney as used for a solid fuel appliance with an effective cross-sectional dimension of 225 x 225 mm (9” x 9”) or a lined flue with a minimum diameter of 125mm (5”). The chimney must have a minimum effective height of at least 3 metres.
  • Page 19 PREPARING THE OPENING FOR INSTALLATION WITH MARBLE SLIPS 1050min to 1090 This area behind the trim/fascia must be clear of combustible 520 min to 550 max material and be flat for the seal. Floor 350 mm Min Depth The front face and the base of the fire opening must be flat to ensure that a good seal is formed between the rear and base of the appliance and the chimney to avoid any reduction of natural draught.

  • Page 20: Section Nine To Install The Appliance (Installation Instruction)

    CHECKING THE FLUE AND FIRE OPENING  Check that the chimney conforms to the required specifications as previously stated. Examine the condition and carry out any remedial work including removing any debris from the base.  If the flue has been used for solid fuel it should be swept prior to the installation ...
  • Page 21 CHECKING GAS SOUNDNESS AND RUNNING PRESSURE. *Batteries must be connected before proceeding with any soundness testing*  Turn on the gas supply to the appliance and check for soundness in accordance with current codes of practice.  Turn off the gas supply at the external Isolation valve. ...

  • Page 22: Section Ten Checking Operation Of Fire (Installation Instruction)

    In the event of replacing fuel bed components please use only the specified number of components as illustrated. Only use fuel bed component provided for this appliance. In the interest of safety and efficiency of your appliance when replacing the fuel bed it is essential that the existing fuel bed be removed and the new components are replaced correctly as a complete set.

  • Page 23: Section Eleven Maintenance (Maintenance Instructions)

    SECTION ELEVEN Maintenance (maintenance instructions) GENERAL  Servicing should be carried out annually by a competent person such as a Gas safe-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance.  Before commencing any service or replacement of parts, turn off the gas supply to the fire.

  • Page 24: Section Twelve Wiring Diagram (Maintenance Instructions)

     Re-assemble in reverse order. REPLACEMENT OF OXY-PILOT ASSEMBLY NOTE: If the pilot assembly is replaced it must be replaced by an identical unit from the same manufacturer and replaced as a complete unit.  Follow the burner tray removal sequence. ...
  • Page 25 www.charltonandjenrick.co.uk LT5845 (ISS 15)
  • Page 26 Register your appliance online today to active your warranty LT5845 (ISS 15)

  • Page 27: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 28: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 29 www.charltonandjenrick.co.uk LT5845 (ISS 15)
  • Page 30 LT5845 (ISS 15)
  • Page 31 www.charltonandjenrick.co.uk LT5845 (ISS 15)
  • Page 32 Serial No A-0382 Product Product Serial No (Lpg) Prefix A-0282 (Ng) ID Label ID Label Prefix Burner Tray / Box Assembly Burner Tray / Box Assembly Inlet Cover (5810) Inlet Cover (5810) 2 x Side cover (5815) 2 x Side cover (5815) Restrictor Plate (5833) Restrictor Plate (5833) Complete Log Fuel Bed (5825)
