Instruction for user,
Installation &
Servicing
890 HD
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
Video guides found at http://www.charltonandjenrick.co.uk/infinity-set-up-guides/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 890 HD and is the answer not in the manual?

Questions and answers

Related Manuals for Infinity 890 HD

Summary of Contents for Infinity 890 HD

  • Page 1 This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online. Video guides found at http://www.charltonandjenrick.co.uk/infinity-set-up-guides/...

  • Page 2: Table Of Contents

    Lighting the Appliance & General Operation Of Control ....................5 Auto (Thermostatic) Control ............................. 7 Menu features..................................8 Changing The Handset Batteries............................. 8 Cleaning the 890 HD Appliance ............................9 Fuel Bed Layout ................................10 WALNUT FUEL BED LAYOUT .............................. 12 SILVER BIRCH FUEL BED LAYOUT ............................16 Technical Specification ..............................

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance.

  • Page 4: Introduction

    890 HD USERS INSTRUCTIONS Introduction The 890 HD has been designed and tested to the requirements of EN 613 and is suitable for use in Great Britain & Republic of Ireland. 890 HD incorporates a single gas valve which selects ignition pilot, with variable setting between low and high setting and is operated via remote control hand device or optional smart app device.
  • Page 5 890 HD USERS INSTRUCTIONS Important Information The appliance is for use on Natural Gas (G20 @ 20mbar) only. The Chimney or flue (unless new or previously used with a gas appliance) should be swept before installation if been used for solid fuel.

  • Page 6: Lighting The Appliance & General Operation Of Control

    890 HD USERS INSTRUCTIONS Lighting the Appliance & General Operation Of Control Handset set up video http://www.charltonandjenrick.co.uk/handsetguide/ Display overview Press to awaken the handset from its dormant sleep mode at any time. Fig 1 shows the display neutral, ready to turn on.
  • Page 7 890 HD USERS INSTRUCTIONS Flame height adjustment Once the fire has been started (after a period of 10 minutes) the flame height can be decreased by moving your finger clock wise or decreased moving your finger anti-clock wise using the selector wheel. Once the desired flame level is set, remove your finger from the selector wheel to transmit your selection to the receiver.

  • Page 8: Auto (Thermostatic) Control

    890 HD USERS INSTRUCTIONS Note: The handset contains a sensitive temperature measurement device. To achieve the best thermostatic efficiency do not place the handset near the heat source, avoid covering, direct sunlight or near a draft or open window etc. Place the handset at a midpoint in the room or area being heated. Allow 5-10 minutes for the handset to stabilize if subjected to extremes of temperature.

  • Page 9: Menu Features

    890 HD USERS INSTRUCTIONS Menu features The menu can be accessed by pressing and holding the button (approx. 5 seconds) until the menu graphic completes (see fig 6). Use the selector wheel to highlight one of the available options. Press to enter the required option.

  • Page 10: Cleaning The 890 Hd Appliance

    890 HD USERS INSTRUCTIONS Cleaning the 890 HD Appliance Ensure the appliance is cold before proceeding. The outer metal work frame should be cleaned using a damp cloth. To clean the glass panel, remove the four M4 nuts fixing the glass clamp to the glass panel. (See Fig 8).

  • Page 11: Fuel Bed Layout

    890 HD USERS INSTRUCTIONS Fuel Bed Layout Fuel bed lay out video can been found at: http://www.charltonandjenrick.co.uk/890guide/ Firstly, place the air tray within the fire box shelf as shown, making sure both pieces of the air tray are sitting flat and met in the middle.
  • Page 12 890 HD USERS INSTRUCTIONS Push both sides of the air tray against the side of the fire box leaving a small gap in-between the two halves of the air tray as shown below LT7593 Issue No 1 (03/2017) P a g e...

  • Page 13: Walnut Fuel Bed Layout

    890 HD USERS INSTRUCTIONS WALNUT FUEL BED LAYOUT Place a single layer of the forge embers across the burner spreading them out evenly Note: by applying more than one layer may result in excessive sooting and produce a poor flame picture...
  • Page 14 890 HD USERS INSTRUCTIONS These shapes that are placed at the back of the firebox and the rear surface of the log is a flat edge which needs to be placed against the rear liner. Rear log shape with flat...
  • Page 15 890 HD USERS INSTRUCTIONS Place the three rear shapes as shown touching the rear liner. Place the first log as shown Place the next log as shown Place the next log as shown LT7593 Issue No 1 (03/2017) P a g e...
  • Page 16 890 HD USERS INSTRUCTIONS Place the next log as shown Place the next log as shown Place the next log as shown Place the final log as shown LT7593 Issue No 1 (03/2017) P a g e | 15...

  • Page 17: Silver Birch Fuel Bed Layout

    890 HD USERS INSTRUCTIONS SILVER BIRCH FUEL BED LAYOUT Firstly, place the air tray within the fire box shelf as shown, making sure both pieces of the air tray are sitting flat and met in the middle. The Log & bark shapes must be positioned in accordance to the following instructions to give the correct flame picture &...
  • Page 18 890 HD USERS INSTRUCTIONS Place a single layer of the forge embers across the burner spreading them out evenly Note: by applying more than one layer may result in excessive sooting and produce a poor flame picture Stretch out the Embaglow fibers out so that they form a loose and thin network then lay the network across the back of the layer of forge embers, try and ensure that there is no clumps of the fibers to allow the gas to flow through.
  • Page 19 890 HD USERS INSTRUCTIONS These shapes that are placed at the back of the firebox and the rear surface of the log is a flat edge which needs to be placed against the rear liner. Rear log shape with flat...
  • Page 20 890 HD USERS INSTRUCTIONS Place the three rear shapes as shown touching the rear liner Place the first log as shown Place the next log as shown Place the next log as shown LT7593 Issue No 1 (03/2017) P a g e...
  • Page 21 890 HD USERS INSTRUCTIONS Place the next log as shown Place the next log as shown Place the next log as shown LT7593 Issue No 1 (03/2017) P a g e | 20...
  • Page 22 890 HD USERS INSTRUCTIONS Place the last log as shown LT7593 Issue No 1 (03/2017) P a g e | 21...

  • Page 23: Technical Specification

    890 HD INSTALLATION INSTRUCTIONS Technical Specification Model Working Country Type Pressure Injector Input Class Pilot 890 HD Natural 6.6 KW 2900 GB, IE mbar 460A Gross Note : The efficiency of the appliance has been measured as specified in BS7977-1 2009+ A1:2013 and the net efficiency rate is 73.44.

  • Page 24: Siting The Appliance

    890 HD INSTALLATION INSTRUCTIONS Packaging Check List 1 x Glass Panel 1 x Air Tray Assembly 1 x Boxed Fuel Bed 1 x Transformer Plug 1 x Battery Holder 1 x Emergency Power Battery Adaptor 1 x RF Handset 4 x AAA 1.5V Batteries...
  • Page 25 The 890 HD is designed to be fitted into a class one flue with a fire place which will require a 50mm rebate. The other option is hole in the wall which can be plastered up to the edge of the fire place frame or fitted with wall mounted non combustible slips.
  • Page 26 Fit the fire place frame to the fire box flange. The fireplace surround can now be constructed. The 890 HD can be installed using three different methods when going hole in the wall. A- Hole in the wall using none combustible slips.
  • Page 27 890 HD INSTALLATION INSTRUCTIONS A- B-C / Builder’s opening aperture size when fitting hole in the wall plaster edge, slips or Four sided trim. ( Please note that the 50mm clearance requirement only applies when fitted with the four sided trim option.)
  • Page 28 890 HD INSTALLATION INSTRUCTIONS Using rawl plugs and wood screws retain the fire box via the 6mm holes within the slip brackets. None combustible slips can now be fitted up to the edge of the fire place frame. B-Dry lined hole in the wall.
  • Page 29 890 HD INSTALLATION INSTRUCTIONS Open the aperture size to accommodate the fire box as out lined at the beginning of the section. With the height of the opening established and support for the fire box in place, take out a further area of the plaster board lining to expose the inner brick work face of the chimney breast as out lined in Fig 1.
  • Page 30 No combustible material should be fitted inside the fireplace opening. Installation with a flexible liner The 890 HD is designed for installation within the masonry chimney with or without a flexible line. If the flexible liner option is required the following two methods should be followed.
  • Page 31 890 HD INSTALLATION INSTRUCTIONS Offer the fire box assembly within the masonry aperture at the same time guiding the gather hood within the guides situated on the top of the fire box (Please see Fig 2). Engage the hood studs within the slotted holes and secure using the three M4 nuts provided within the gather hood kit.

  • Page 32: Installation Of The Appliance

    890 HD INSTALLATION INSTRUCTIONS Installation of the Appliance Optional Wi-Fi Kit Installation Set up video can be found at: Apple: Android: http://www.charltonandjenrick.co.uk/appleguide/ http://www.charltonandjenrick.co.uk/androidguide/ The Kit contains the following components:  1 x Wi-Fi Dongle.  5 x self adhesive aluminum clips.
  • Page 33 890 HD INSTALLATION INSTRUCTIONS With the dongle connected to the lead, locate the unit within the two M3 studs position on the left hand side of the fire box. When positioning the Wi-Fi unit it is important to have the cable socket facing the rear of the fire box.
  • Page 34 890 HD INSTALLATION INSTRUCTIONS Gas supply routing. Check the gas run to assess that the gas supply is capable of providing the required amount of gas and is in accordance with the rules in force. Soft copper pipe can be used to install the appliance. Soldered joints can be used only externally of the appliance.
  • Page 35 890 HD INSTALLATION INSTRUCTIONS Power lead routing The power supply for this appliance is provided via AC power adaptor 230 VAC. The main cable terminates the rear Right hand side of the fire box. The length of the cable provided with the appliance is 1.65 metres.
  • Page 36 890 HD INSTALLATION INSTRUCTIONS The battery manual override option is a back-up supply in case of a power failure / power cut to the property. The battery holder and adaptor lead are provided within the packing of the appliance. (Please note that the “C” cell batteries are not included). It is good practice to demonstrate the battery option to the customer during the commissioning process.
  • Page 37 890 HD INSTALLATION INSTRUCTIONS Hole in the wall. For hole in the wall installation, two additional fixing brackets will be needed that are attached to the fireplace frame LH and RH. Attached the two brackets using the 6 off fixing screws provided with the kit.
  • Page 38 890 HD INSTALLATION INSTRUCTIONS Four sided trim Please note when installing the appliance using this method it is very important to maintain a gap of 50mm from the underside of the fire box base to the floor. Failure to do this will result in damage to the operating components.

  • Page 39: Commissioning The Appliance

    890 HD INSTALLATION INSTRUCTIONS Commissioning the Appliance Checking gas soundness and running pressure. Turn on the supply to the appliance and check for soundness in accordance with the current codes of practice. Turn off the gas supply at the external isolation valve.
  • Page 40 890 HD INSTALLATION INSTRUCTIONS Fuel Bed Layout. Fuel bed layout should be fitted using the guidance stipulated on pages 11-16 of the User Instruction section. Fit Glass Panel. Due to transit protection, the glass panel is packed with a protective sleeve within the packed appliance.
  • Page 41 890 HD INSTALLATION INSTRUCTIONS Slide the glass in front of the frame and push in to place making sure that the glass is pushed in to the glass channel properly and sits in the bottom of it and that the inner frame is still central.
  • Page 42 890 HD INSTALLATION INSTRUCTIONS Run the match along the edge of the inlet air channel. All smoke must be drawn into the inlet channel if the spillage test is satisfactory. If spillage occurs wait a further five minutes and repeat the test.

  • Page 43: Annual Service Requirement

    890 HD SERVICE / FAULT FINDING INSTRUCTIONS Annual Service Requirement. General Servicing should be carried out annually by competent person whose name appears on the gas safe register. All Gas Safe engineers should possess an ID carrying the logo below.
  • Page 44 890 HD SERVICE / FAULT FINDING INSTRUCTIONS Remove the rear panel from within the fire box. Finally remove the eight screws from the inner and outer inspection covers. (Please see figure 1) With the covers removed. The catchment area at the rear of the fire box can now be inspected for debris.

  • Page 45: Fault Finding Charts

    890 HD SERVICE / FAULT FINDING INSTRUCTIONS Fault Finding Charts LT7593 Issue No 1 (03/2017) P a g e | 44...
  • Page 46 890 HD SERVICE / FAULT FINDING INSTRUCTIONS LT7593 Issue No 1 (03/2017) P a g e | 45...
  • Page 47 890 HD SERVICE / FAULT FINDING INSTRUCTIONS LT7593 Issue No 1 (03/2017) P a g e | 46...
  • Page 48 890 HD SERVICE / FAULT FINDING INSTRUCTIONS Wiring Diagram Attach to the oxy pilot LT7593 Issue No 1 (03/2017) P a g e | 47...

  • Page 49: Maintenance

    890 HD MAINTENANCE INSTRUCTIONS Maintenance To Remove the Burner Carrier Assembly Remove the glass panel as described on page 9 of the user’s instruction section. Remove the Loose shapes and the air tray assembly. Remove the four screws retaining the gas inlet plate and the ECU cover. (Please see Fig 1) Shut off the restrictor elbow and disconnect the 8mm inlet nut.
  • Page 50 890 HD MAINTENANCE INSTRUCTIONS Replacement of The Gas Valve Follow the sequence to remove the burner carrier assembly. Disconnect the thermocouple from the rear of the gas valve. Undo the three compression nuts securing the pipes to the gas valve and remove the two M4 nuts fixing the valve to the valve mounting brackets.
  • Page 51 890 HD MAINTENANCE INSTRUCTIONS Replacement of the burner Assembly Remove the glass panel as described on page 9 of the users instruction section. Remove the Loose shapes and the air tray assembly. Undo the two fixing screws retaining the burner assembly with the carrier.

  • Page 52: Short Spares List

    890 HD MAINTENANCE INSTRUCTIONS Short Spares List Component Part No Burner Bar 3057 Injector Mrk 460 A 2799 ODS Unit/ oxy pilot 7280 Control Valve 6590 Electrical Control Unit (ECU) 7150 Ignition Lead 6646 Handset RF 7144 HD Fuel Bed...

  • Page 53: Your Fire Years Parts Extended Warranty

    Charlton and Jenrick Ltd. The registration form must be returned within 1 months of purchase. For further information please contact the Infinity help desk on 0845 5195991 or visit our web site www.CharltonandJenrick.co.uk. Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase.

  • Page 54: Four Year Service Log Details

    The following information must be completed to support by receipts as part of the conditions of the extended five year parts warranty and the appliance must be registered by completing and return the registration document (last page of this booklet) to Infinity Fires. Date...

  • Page 55: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 56: Register Your 12 Month Warranty With Us Today

    Address Post Code Telephone No Product Details Model : 890 HD Serial No Date Of Purchase This information can be found on the label attached to the packaging and on the data badge. Where did you purchase this product :...
  • Page 57 LT7593 Issue No 1 (03/2017) P a g e | 56...
  • Page 58 LT7593 Issue No 1 (03/2017) P a g e | 57...
  • Page 59 LT7593 Issue No 1 (03/2017) P a g e | 58...
  • Page 60 Infinity 890 HD Packing List A-0626 – Glass liners fitted 890 HD Pre- Fix A-0678 – Brick liners fitted A-0679 – Vermiculite Liners fitted Data badge and plate added Burner tray / firebox assembly Air test completed Glass warning label (1409)
