Altronix eFlow102NV Installation Manual page 16

Models Include:
Model
eFlow102NV,
eFlow102NV8, eFlow102N8DV,
eFlow102N16V, eFlow102N16DV
eFlow102NXV,
eFlow102NX8V, Flow102NX8DV,
eFlow102NX16V, eFlow102NX16DV
The eFlow102NV series power supply/chargers convert a 220VAC, 50/60Hz input to a 12VDC output.
Battery
7AH
12AH
40AH
65AH
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 1.54A.
• Automatic switch over to stand-by battery when AC fails.
Transfer to stand-by battery power is instantaneous with no interruption.
Red (DC) Green (AC/AC1)
ON ON
ON OFF
OFF ON
OFF OFF
Installing Company: ________________ Service Rep. Name: ______________________________________
Address: ___________________________________________________ Phone #: _____________________
Refer to the eFlow Power Supply/Chargers Installation Guide: IIeFlow102NV Series, Rev. 102NVRP052213 for
complete instructions. This sheet is to be removed, framed and posted next to the unit.
Rev. 102NVRP052213
Power Supply/Chargers Operating Guide
Input
220VAC,
50/60Hz
2.1A
Stand-by Specifications:
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
0.4A/10A
1A/10A
6A/10A
6A/10A
LED Diagnostics:
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Output
12VDC 24VDC
10A –
Overview:
Fire Applications
24 hr. Stand-by/
5 min. Alarm
N/A
0.3A/10A
1.2A/10A
1.5A/10A
Auxiliary Power-Limited
Output (unswitched)
1A
Access Control
Applications Stand-by
5 Mins./10A
15 Mins./10A
Over 2 Hours/10A
Over 4 Hours/10A
Ripple
Voltage
760mV
