Altronix eFlow102NV Installation Manual page 11

Enclosure Dimensions (BC300):
eFlow102NV, eFlow102N8V, eFlow102N8DV, eFlow102N16V, eFlow102N16DV
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
eFlow102NV Series
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
1.20"
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
- 11 -
