Commissioning
5. 1-30 Stator Resistance (Rs)
Enter line to common stator winding resistance
(Rs). If only line-line data are available, divide the
line-line value with 2 to achieve the line to
common (starpoint) value.
6. 1-37 d-axis Inductance (Ld)
Enter line to common direct axis inductance of
the PM motor.
If only line-line data are available, divide the line-
line value with 2 to achieve the line-common
(starpoint) value.
5 5
7. 1-40 Back EMF at 1000 RPM
Enter line to line back EMF of PM Motor at 1000
RPM mechanical speed (RMS value). Back EMF is
the voltage generated by a PM motor when no
drive is connected and the shaft is turned
externally. Back EMF is normally specified for
nominal motor speed or for 1000 RPM measured
between 2 lines. If the value is not available for a
motor speed of 1000 RPM, calculate the correct
value as follows: If back EMF is e.g. 320 V at 1800
RPM, it can be calculated at 1000 RPM as follows:
Back EMF = (Voltage / RPM)*1000 =
(320/1800)*1000 = 178. This is the value that
must be programmed for 1-40 Back EMF at 1000
RPM.
Test Motor Operation
1. Start the motor at low speed (100 to 200 RPM). If
the motor does not turn, check installation,
general programming and motor data.
2. Check if start function in 1-70 PM Start Mode fits
the application requirements.
Rotor detection
This function is the recommended choice for applications
where the motor starts from standstill, e.g. pumps or
conveyors. On some motors, an acoustic sound is heard
when the impulse is sent out. This does not harm the
motor.
Parking
This function is the recommended choice for applications
where the motor is rotating at slow speed eg. windmilling
in fan applications. 2-06 Parking Current and 2-07 Parking
Time can be adjusted. Increase the factory setting of these
parameters for applications with high inertia.
Start the motor at nominal speed. If the application does
not run well, check the VVC
dations in different applications can be seen in Table 5.6.
26
Operating Instructions
+
PM settings. Recommen-
Danfoss A/S © Rev. 2014-02-06 All rights reserved.
Application Settings
Low inertia applications 1-17 Voltage filter time const. to be
I /I <5 increased by factor 5 to 10
Load Motor
1-14 Damping Gain should be
reduced
1-66 Min. Current at Low Speed
should be reduced (<100%)
Low inertia applications Keep calculated values
50>I /I >5
Load Motor
High inertia applications 1-14 Damping Gain, 1-15 Low Speed
I /I > 50 Filter Time Const. and 1-16 High
Load Motor
Speed Filter Time Const. should be
increased
High load at low speed 1-17 Voltage filter time const. should
<30% (rated speed) be increased
1-66 Min. Current at Low Speed
should be increased (>100% for a
prolonged time can overheat the
motor)
Table 5.6 Recommendations in Different Applications
If the motor starts oscillating at a certain speed, increase
1-14 Damping Gain. Increase the value in small steps.
Depending on the motor, a good value for this parameter
can be 10% or 100% higher than the default value.
Starting torque can be adjusted in 1-66 Min. Current at Low
Speed. 100% provides nominal torque as starting torque.

5.4.5 Automatic Energy Optimisation (AEO)

NOTICE
AEO is not relevant for permanent magnet motors.
Automatic Energy Optimisation (AEO) is a procedure that
minimises voltage to the motor, reducing energy
consumption, heat, and noise.
To activate AEO, set parameter 1-03 Torque Characteristics
to [2] Auto Energy Optim. CT or [3] Auto Energy Optim. VT.

5.4.6 Automatic Motor Adaptation (AMA)

NOTICE
AMA is not relevant for PM motors.
Automatic motor adaptation (AMA) is a procedure that
optimises compatibility between the frequency converter
and the motor.
•
The frequency converter builds a mathematical
model of the motor for regulating output motor
current. The procedure also tests the input phase
balance of electrical power. It compares the
