Crestron Isys i/O
Operations Guide - DOC. 6344
TPMC-15/17 Tilt Series
CAT5 audio source). The CH version is also equipped with balanced output for
microphone audio that can be connected to a Crestron CNX-BIPAD8 or similar
Crestron CAT5 audio receiver.
With either a 15-inch (38.1 cm) (TPMC-15) or a 17-inch (43.2 cm) widescreen (15:9
aspect ratio) active matrix color display (TPMC-17), these media centers can display
up 16.7 million colors at up to 1280 x 768 resolution (TPMC-17 series only),
allowing all graphics to be displayed with incredible brightness and depth.
Multiple graphics can be displayed on the TPMC-15 & TPMC-17 without any shift
in color depth or quality. CH versions of the TPMC-15 & TPMC-17 series can
display two real-time video signals from any Crestron balanced video distribution
product or any balanced video, S-video or composite video source. QM versions can
display two real-time video/RGB signals from two QM transmitters.
For information on programming the TPMC-15 or TPMC-17 touchpanels, refer to
the latest version of the Crestron Isys i/O™ TPMC-15 & TPMC-17 Series
Programming Guide (Doc. 6350) which can be downloaded from the Crestron
website (http://www.crestron.com/manuals).
The purpose of these touchpanels is to provide a complete presentation solution
integrating conventional AV control with embedded PC applications for browsing
the Internet and presenting a full range of multimedia content.
Sound & Video
The TPMC-15 and TPMC-17 feature a built-in, biamplified speaker system and a
headphone jack. Sound can be generated by the touchpanel using downloaded wave
files (.WAV), a PC application, or can be mixed in from an external line level audio
source (CH versions) or a QM input (QM versions only). The audio amplifiers
output 5 Watts to a biamplified 2-way speaker system (mono). Refer to the latest
version of the Crestron Isys i/O™ TPMC-15 & TPMC-17 Series Programming
Guide (Doc. 6350) for WAV file details.
CH versions amplify the built-in microphone to produce a line level differential
output. QM versions transmit the microphone output and PC audio for transmission
through the QM output.
All versions of the TPMC-15 and TPMC-17 can display up to two scaleable video
windows, enabling the simultaneous display of any two full motion video. QM
versions can also send RGB computer images to the video windows. Discrete video
scalers are employed with motion adaptive deinterlacing to bring out the highest
detail by minimizing visible scan lines and motion artifacts. Automatic source
identification assigns the optimum deinterlacing algorithm and applies 3:2 (NTSC)
and 2:2 (PAL) reverse pulldown based upon the input signal.
Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series
Touchpanel Media Centers
3
