SWAP
Swap Nibbles
Instruction Format:
SWAP dst
Operation:
↔
dst(7-4) dst(3-0)
The contents of the lower four bits and upper four bits of the destination operand are swapped.
Flags:
When the instruction is executed, the flags are set as follows:
C: The value set by the preceding instruction.
Z: 1 if the result is 0; otherwise, 0.
S: 1 if bit 7 of the result is 1; otherwise, 0.
V: The value set by the preceding instruction.
D: The value set by the preceding instruction.
H: The value set by the preceding instruction.
Example: Register BCH contains B3H (10110011B). The following statement leaves the value 3BH
(00111011B) in register BCH. The Z and S flags are set to 0.
SWAP B3H
Op Code: F0 B3
Example: Working register R5 contains BCH and register BCH contains B3H (10110011B). The following
statement leaves the value 3BH (00111011B) in register BCH. The Z and S flags are set to 0.
SWAP @R5H
Op Code: F1 E5
OPC dst
Address Mode
OPC (Hex)
F0
F1
dst
R
IR
