Parts Manual; Initial Parts Kit (P/N 4001.00) - CMA Dishmachines CMA-GL-X Parts Manual

1. Parts Manual

1.1.

Initial Parts Kit (P/N 4001.00)

P/N
00200.10
00206.00
00208.00
00304.03
00308.50
00404.82
00411.00
00415.00
03470.01
00425.51
00425.53
00425.54
00433.10
00435.00
00435.62
00458.00
00501.00
00557.55
00707.00
00715.00
00738.10
03202.00
03406.64
03415.00
03415.60
04103.00
04110.00
04303.00
04305.10
04517.15
NOTE: CMA recommends that the initial parts kit be kept on hand as a back up supply of critical
parts in the event your machine should require emergency service. All the parts
included in this kit are unique to the GL-X glasswasher.
MODEL GL-X PARTS MANUAL Rev. 1.01 –02/12/08
DESCRIPTION
Pump Assy, 110/220V 60 Hz, Open
Pump Seal Kit
Slip Joint Nut Gasket
Spray Arm B GL-X
Spray Arm End Plug SS
Motor Contactor Relay
Micro Switch
Peristaltic Pump Assembly, 120V/60Hz
Toggle Switch, momentary, (.25 flat terminal)
Chemical Tubing Blue
Chemical Tubing Red
Chemical Tubing White
Master Switch (20 Amp)
Squeeze Tube, 8", Silicone
Squeeze Tube, 24"
Squeeze Tube, Black (Detergent)
Timer Motor, 2-Minute
Kynar Reed Switch, 110/220V, 36"
1/2 Water Solenoid Repair Kit, JE
1/2 Ball Check Valve
Solenoid Coil, JE, 120V, (¾" & ½")
Thermometer, Capillary
Drain Toggle Switch
Chemical Tube Bulkhead
Chemical Bulkhead (Teflon) Assy
GL-X Drain Valve, 120V
SS L1-C/L-1X Drain Screen
GL-X Spray Arm Bearing
Red Silicone Gasket, 1/16 Thick
Door Stop (Parallel)
Parts Manual
Qty
1
1
1
1
1
1
1
1
1
50 ft.
50 ft.
50 ft.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Page
3
