CMA Dishmachines GL-X Parts Manual

Hide thumbs Also See for GL-X:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
MODEL GL-X
PARTS MANUAL
Rev. 1.04
C M A D I S H M A C H I N E S
1 2 7 0 0 K N O T T A V E N U E
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 1 4 1
www.cmadishmachines.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GL-X and is the answer not in the manual?

Questions and answers

Related Manuals for CMA Dishmachines GL-X

Summary of Contents for CMA Dishmachines GL-X

  • Page 1 MODEL GL-X PARTS MANUAL Rev. 1.04 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS CMA-GL-X ODEL 1. PARTS MANUAL ..................3 1.1. (P/N 4001.00) ....................3 NITIAL ARTS 1.2........................4 PTIONAL LARM 1.3......................5 XPLODED RAWINGS 1.3.1. Cabinet Assembly ........................5 1.3.2. GLX Door Assembly ....................... 6 1.3.3. Spray System Assembly ......................7 1.3.4.

  • Page 3: Parts Manual

    NOTE: CMA recommends that the initial parts kit be kept on hand as a back up supply of critical parts in the event your machine should require emergency service. All the parts included in this kit are unique to the GL-X glasswasher. Page...

  • Page 4: Optional Sani Alarm

    00435.00 Squeeze Tube, 8” 40126.10 #10 x 3/4" Sheet metal Screw 00521.00 Wire, 18 Gauge, Orange, 6 ft. 40127.00 Wall Anchors 00531.00 Wire, 18 Gauge, White, 6 ft. 00426.00 Y Hose Connector, 3/16” Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 5: Exploded View Drawings

    Liquid Level Switch 01572.64 GL-X Leg 03816.00 Nylon Retaining Washer 00941.00 10-32 X 5/8” Panhead Screw 03415.60 Chem. Tube Bulkhead 14506.50 Door Gasket 00912.00 ¼” SS Nut 14506.45 Gasket Bracket 00922.00 ¼” Lock Star Washer Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 6: Glx Door Assembly

    1/4"-20 x 5/8” Hex Head Bolt 04919.50 Door Support Rod Left 14518.00 Splash Guard 00557.80 Door Magnet 00924.00 1/4" SS Washer 00970.60 6 32 x 1/2" Flathead Screw 00605.00 Door Handle Button 14558.61 Door Magnet Holder Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 7: Spray System Assembly

    00929.00 1/4"-20 x 3/4" Truss Head Bolt 04306.00 Square Manifold Gasket 04305.10 Red Silicon Gasket 04303.00 Spray Arm Bearing 00304.03 Spray Arm “B” Series 00308.50 Spray Arm End Plug 04304.00 GL-X Spray Manifold Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 8: S/S Pump Assembly (Effective August 2009)

    00914.70 Socket Head Screw 10 mm 50302.10 1" MPT x 1" Barb Brass 00208.21 Slip Joint Nut Friction Ring 04206.75 SS Pump Cover Item not shown are the same as #20 in old assembly Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 9: Pump Assembly

    03226.00 Pump “O” Ring Gasket 00206.00 Pump Seal Kit 00238.00 3/8” Male Plug 03222.05 Impeller (universal) open 00214.50 1/2" Comp x 3/8” MIP Adapter 04206.00 Pump cover 00208.21 Slip Joint Nut Friction Ring Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 10: Plumbing System Assembly (Effective August 2012)

    3/4" F X 1" Barb Plastic Fitting 03603.20 1/2" Water Solenoid Bonnet 03101.00 Hose Clamp # 16 1" 00786.00 JE Solenoid Valve Plunger 41062.00 ^ 1/2 Ball Valve Strainer Only 00707.00 JE ½” Solenoid Rep. Kit Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 11: Plumbing System Assembly

    JE Solenoid Valve Plunger 41015.60 1/4 Water Solenoid Coil Only 110V 00707.00 JE ½” Solenoid Rep. Kit 03604.30 Dema Valve Repair Kit 1/2" 03603.10 JE ½” Solenoid Valve 41062.00 ^ 1/2 Ball Valve Strainer Only Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 12: Drain System Assembly

    Pump Hose 6.5” 03101.00 1” Hose Clamp #16 04113.00 Drain Valve 03108.51 1” Goose Neck Drain Hose 04110.00 Drain Sump Screen 50302.06 1” MIP X 1” Barb PVC 03109.00 Drain Hose 90 deg. 1” I.D. Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 13: Control Box

    Start/Fill Rocker Switch* 00965.00 6-32 Nylon Lock Nut 15524.00 Power Rocker Switch* 00470.10 Toggle Switch Rubber Boot 03202.66 Thermocouple 03485.00 Switch Guard (Undercounter Units) 00438.00 Snap bushing, Universal 06232.51 GL-X Drawer Label w/Window Page MODEL GL-X PARTS MANUAL Rev. 1.04...

  • Page 14: Power Box

    10-32 Nylon Lock Nut 13525.00 8-32 x 1” Pan Head Screw 15914.82 GL-X Peri-Pump Mount 00927.00 8-32 Nylon Lock Nut 03475.00 Primer Switches* 00941.00 10-32 Pan Head Screw 03476.00 Rubber Boots 03801.00 10-32 Nylon Lock Nut Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 15: Peristaltic Pump Assembly

    00415.00 Complete Peristaltic Pump 00458.00 Squeeze Tube – Black Detergent 03415.60 Bulk Head For Sanitizer 02257.00 Squeeze Tube 8" Norprene 02257.62 30” Squeeze Tube 00419.00 Peristaltic Rotor Assembly *Item 16 includes items 1-4, 6-10. Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 16: Drain Valve

    Drain Seal Washer (White) 04103.12 Drain Valve Housing 00941.00 #10-32 x 5/8” Pan Head Screw 04103.24 Drain Valve Housing Spacer 04103.16 Hinge/Seal 04103.15 Drain Housing Gasket 04103.13 Drain Valve Housing Cover 04103.18 #8 x 5/8” Self-Threading Screw Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 17: Drain Valve (Effective January 2011)

    Drain Seal Bearing (White Washer) 04103.13 Drain Valve Housing Cover 04113.18 Valve Cover Screw 04103.16 Drain Valve Hinge/Seal 04103.15 Drain Valve Housing Gasket 04113.12 Drain Valve Housing 04103.18 #8 X 5/8 Self Threading Screw Page MODEL GL-X PARTS MANUAL Rev.1.04...

  • Page 18: Glx Heater Assembly

    Parts Manual 1.3.14. GLX Heater Assembly ITEM DESCRIPTION REQ’D 15920.64 GL-X Heater Box 15417.30 1250 Watt Heater 04109.11 Sump Heater 13417.92 Thermostat Page MODEL GL-X PARTS MANUAL Rev. 1.04...
