- Page 1 Owner’s Manual Keep with machine for reference MODELS AH/B/C/S INSTALLATION & OPERATION Rev 1.00 A C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E...
-
Page 2: Table Of Contents
3.3. DDENDUM FOR ACHINES 3.4. LECTRICAL IAGRAMS 3.4.1. Models AH/ C & B ...13 3.4.2. Solid Bowl...14 ABLE OF ONTENTS AH/B/C/S. ODEL ...5 YCLE AH, B ,C&” S” ..7 SERIES ...8 NSTALLED IN THE ITY OF HICAGO ...13 ...12... -
Page 3: Specifications
1. Specifications Electrical and plumbing connections must be made by a qualified service person who will comply with all available Federal, State, and Local Health, Electrical, Plumbing and Safety codes 1.1 Model AH/C WATER CONSUMPTION PER RACK PER HOUR OPERATING CYCLE WASH TIME-SEC. -
Page 4: Model B
Electrical and plumbing connections must be made by a qualified service person who will comply with all available Federal, State, and Local Health, Electrical, Plumbing and Safety codes 1.2 Model B WATER CONSUMPTION PER CYCLE PER HOUR OPERATING CYCLE WASH TIME-SEC. RINSE TIME-SEC. -
Page 5: Ah, B And C Operational Cycle
AH, B and C Operational Cycle The AH, B and C Operational Cycle have a total cycle time of 90 seconds. The Timing Diagram and the steps listed below detail the individual functions that are executed during each Operational Cycle. Seconds: Cam 1 Cam 2... - Page 6 The pump motor runs the pump for the 45-second wash cycle, then pumps the water out through the drain, turns off for about 8 seconds (allowing the machine to refill with clean rinse water) and then runs the pump for the 30-second rinse cycle. 3.
-
Page 7: Getting Started
2. Getting Started All sections of the manual address dishmachine models AH, B ,C & “S”series. Separate information on each machine is only provided where differences exist between the models. 2.1. Introduction to Models AH, B ,C&” S” series. The CMA AH, B ,C &”S”series.Dishmachines are safe and easy to operate with their “Auto Start/Stop”... -
Page 8: Receiving And Installation
2.2. Receiving and Installation The dishwasher is shipped from the factory in a corrugated box on a wooden pallet. The installation guidelines give a systematic procedure for setting up the machine. Start by removing the dishmachine from the box. Remove the packaging, unwrap the machine and check for the following components: Scrap Accumulator complete with lid and scrap tray. -
Page 9: Connecting The Scrap Accumulator And Drain
Drain pipe is installed with adequate air gap (must meet local codes) Dishmachine is properly grounded Dishmachine is properly leveled Machine circuit breaker is labeled “DISHWASHER” Machine has been connected with correctly sized wire MODEL AH, B & C INSTALLATION & OPERATION MANUAL Rev. 1.00A below. -
Page 10: Operation
3. Operation 3.1. Initial Setup All machines are equipped with switches to prime the peristaltic pumps at anytime the master switch is "ON". Following completion of the installation, always fill the machine with water before starting it. Caution: Do not operate the dishmachine without the drain screen in place. Debris getting into the pump impeller can damage the pump. -
Page 11: General
3.2. General Please follow the instructions given here before each shift to assure trouble free operation. Caution: Do not operate the dishmachine without the drain screen in place. Debris getting into the pump impeller can damage the pump. 1. Drain the water if it is cold by lifting the drain ball until all the water is out of the machine. 2. -
Page 12: Addendum For Machines Installed In The City Ofchicago
3.3. Addendum for Machines Installed in the City ofChicago "All food dispensing establishments using chlorine or other approved chemical sanitizers shall, at all times, maintain an adequate testing device." "Dishes and other eating and drinking utensils to be washed in a dishwashing machine shall be properly scraped and pre-rinsed and shall be stacked in racks or trays so as to avoid overcrowding, and so as to permit the wash and rinse waters to reach all surfaces of each utensil."... -
Page 13: Electrical Diagrams
3.4. Electrical Diagrams 3.4.1. Models AH/ C & B Page MODEL AH, B & C INSTALLATION & OPERATION MANUAL Rev. 1.00A... -
Page 14: Solid Bowl
3.4.2. Solid Bowl Page MODEL AH, B & C INSTALLATION & OPERATION MANUAL Rev. 1.00A...
