- Page 1 Owner’s Manual Keep with machine for reference MODEL GL-X INSTALLATION & OPERATION Rev. 1.01 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E...
-
Page 2: Table Of Contents
1. SPECIFICATIONS ...2 1.1. GL-X ... 2 1.2. GL-X O PERATIONAL YCLE 2. GETTING STARTED ...5 2.1. GL-X ... 5 NTRODUCTION TO THE 2.2. ECEIVING AND NSTALLATION 2.2.1. Electrical ... 6 2.2.2. Plumbing... 6 2.2.3. Post Instructions ... 6 2.2.4. -
Page 3: Specifications
WASH PUMP MOTOR *MUST CONNECT TO DEDICATED 20 AMP SUPPLY CIRCUIT. COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED. SHIPPING WEIGHT GL-X (Approximate) MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 METRIC EQUIVALENT 1.7 GAL. 6.44 L 40.8 GAL. -
Page 4: Gl-X Operational Cycle
1.2. GL-X Operational Cycle The GL-X Operational Cycle has a total cycle time of 2 minutes (120 seconds). The Timing Diagram and the steps listed below detail the individual functions that are executed during each Operational Cycle. Seconds: Instant Start Relay... - Page 5 7. Cam switch 8 operates the sustainer heater. This cam assures that the sustainer heater only turns on when the dishmachine is not in a cycle. This prevents the machine from drawing too much electrical current at any one time. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Cam Adjustment PAGE...
-
Page 6: Getting Started
130°F and 140°F when machine is not in operation. The supply water to the GL-X must be a minimum of 140°F. The pipe supplying the water must be ½” minimum. The plumbing connection is located at the back of the machine. The drain is a 1"... -
Page 7: Receiving And Installation
(VERY IMPORTANT). 2.2.1. Electrical A 20-amp, 115 volt, 60 Hz dedicated circuit must be used to supply electrical power to the GL-X machine (see specification sheet page 2). The power connection must be such that there is sufficient length of flexible conduit to permit the machine to be moved for cleaning. -
Page 8: Installers Checklist
Drain hose is installed with adequate air gap Glasswasher is properly grounded Glasswasher is properly leveled Machine circuit breaker is labeled “GLASSWASHER” Machine has been connected with correctly sized wire (To handle 20 amp) MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 PAGE... -
Page 9: Operation
It is essential that the operator thoroughly understand the importance of pre-scrapping the glasses before loading them. The GL-X is equipped with a removable drain screen. The drain screen can be easily removed for cleaning between Operational Cycles of the dishmachine. -
Page 10: Proper Filling
Cam 4 can be adjusted to increase the amount of water that is automatically fed into the machine during a cycle (see section 4.1.1 Cam Adjustment). MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 PAGE... -
Page 11: Maintenance
5. Adjust the trailing edge of the cam groove by rotating the appropriate side of the cam in the proper direction to either increase or decrease the cam’s groove; resulting in increasing or decreasing the total time that switch will be held ON. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Maintenance DRAIN FLUSH SANI. -
Page 12: Quick Service Guide
Water leaks out of Vacuum Breaker Wash Pump motor not running Timer does not rotate Machine does not fill Sanitizer pump does not run MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 CAUSE SOLUTION Delimer switch in delime position Flip to Faulty delimer switch Replace switch, P/N 00475.30... -
Page 13: Troubleshooting
(Cam 8) Defective heater relay *The timer assembly motor ( P/N: 00501.00 independently if that is the only component that has failed. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Maintenance SOLUTION Reset circuit breaker Replace power switch P/N: 00433.10 Replace timer assembly motor P/N: 00501.00... - Page 14 Rinse pump does not run Defective rinse pump motor Defective timer assembly (Cam 6) MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Maintenance SOLUTION Turn up supply water heater Insulate supply water pipe...
- Page 15 Defective pump motor *The timer assembly motor ( P/N: 00501.00 independently if that is the only component that has failed. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Maintenance SOLUTION Replace primer switch P/N: 03470.00 Replace pump motor P/N: 00416.00...
-
Page 16: Addendum For Machines Installed In The City Of Chicago
1. All low energy models must have low-level sani-alarms, both visual and audio. 2. All models must have a City of Chicago approval data label affixed to the machine. 3. Chlorine sanitizer must be a minimum of 100 PPM. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 Addendum PAGE... -
Page 17: Appendix A: Operator & Cleaning Instructions
Appendix A: Operator & Cleaning Instructions MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 PAGE... -
Page 18: Electrical Diagram
Electrical Diagram 6. Electrical Diagram BOOSTER HEATER BAND HEATER MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 PAGE... - Page 19 Electrical Diagram MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01 –08/04/05 PAGE...
