CMA Dishmachines CMA-GL-X Specifications

WARNING: Plumbing connections need to be made by a qualified service company who will comply with all available Federal, State, and Local Health,
Plumbing and Safety codes.
24"
34 / "
5 8
39"
Adj
40 / "
1 8
ELECTRICAL
HOOK UP
1/2" WATER INLET
Front View
Specifications:
MODEL GL-X USA METRIC
OPERATING CAPACITY
RACKS PER HOUR 30 -
OPERATING CYCLE
WASH TIME-SEC 57 57
RINSE TIME-SEC 48 48
DWELL/TIME-SEC 15 15
TOTAL CYCLE TIME 120 120
WASH TANK CAPACITY 1.7 GAL. (6.45 L)
WASH PUMP CAPACITY 35 GPM (132 LPM)
MINIMUM TEMPERATURE REQUIRED
° °
WASH TEMP. 120 F (50
WATER CONSUMPTION
PER RACK 1.7 GAL. (6.45 L)
PER HOUR 40.8 GPH (154.4 LPH)
WATER INLET 1/2" (1.27 cm)
DRAIN 1" (2.54cm)
Summary Specifications: Model GL-X
The GL-X glasswasher is designed to produce sparkling clean glassware utilizing our unique Hot Water Assurance System.
The GL-X is easy to use, fast and efficient, while conserving water, energy and chemicals. Built-in booster heater provides
continuous 130°F hot water every cycle. The GL-X is constructed entirely of stainless steel and is equipped with an integrated
chemical delivery system. The GL-X incorporates a pump purging system that improves results by
eliminating soil and chemical carryover during rinse cycle.
Available Options
■ Stainless Steel Pedestal
CMA Dishmachines 12700 Knott Avenue Garden Grove, CA 92841• 800-854-6417 • 714-898-8781 • Fax: 714-895-2141 • www.cmadishmachines.com
CMA reserves the right to modify specifications or discontinue models without prior notification.
Printed in the U.S.A.
GL-X
Chemical Sanitizing
Undercounter
Glasswasher
®
37 / "
7 8
24 3 / "
4
13 / "
7 8
1" DRAIN
Right View
Rear View
USA
WASH PUMP MOTOR HP 1
DIMENSIONS
DEPTH 24-3/4"
WIDTH 24"
HEIGHT 39"-40-1/8"
MAXIMUM CLEARANCE
HEIGHT FOR GLASSWARE 11-1/4"
STANDARD DISHRACK 1
DIMENSIONS 19-3/4"X19-3/4"
C) ELECTRICAL RATING VOLTS
115
SHIPPING WEIGHT
APPROXIMATE 244#
1 / "
1 2
Minimum
Clearance
METRIC
1
(63cm)
(61cm)
(99-102cm)
(28.57cm)
1
(50X50cm)
AMPS
16
(110.6kg)
Upper and lower rotating
w a s h a r m s g u a r a n t e e
excellent results.
"Built in" Hot Water Assurance
System provides hot water
every cycle.
CMA Dishmachines 12700 Knott Avenue Garden Grove, CA 92841• 800-854-6417 • 714-898-8781 • Fax: 714-895-2141 • www.cmadishmachines.com
© 2007 CMA, Inc. Printed in the U.S.A.
®
FEATURES:
■ 30 racks per hour.
■ Economical to operate. Uses only 1.7
gallons of water per cycle.
■ All stainless steel construction assures long
life and years of trouble free operation.
■ Unique spray arm system features upper
and lower stainless steel wash arms with
reinforced end caps.
■ Built-in chemical pumps and deliming
system assures proper chemical usage.
■ Convenient to service "Works-in-a-drawer".
All electrical components are attached to a
sliding drawer for easy access and service.
■ Instant start for simple operation.
■ Built-in Hot Water Assurance System
guarantees hot water every cycle.
■ Pumped drain allows for flexible installations.
No floor drain is required.
■ Wash tank sustainer heater. Keeps water at
proper temperature between loads.
U s e s s t a n d a r d 1 9 - 3 / 4 " X
1 9 - 3 / 4 " r a c k s . L a r g e
11-1/4" glass clearance.
" Wo r k s - i n - a - d r a w e r " . A l l
electrical components are
attached to a sliding drawer
for easy access and service.
CMA reserves the right to modify specifications or discontinue models without prior notification.
GL-X
Chemical Sanitizing
Undercounter
Glasswasher
© 2007 CMA, Inc.
